CONGRATULATIONS!
You now own the REFERENCE405s
uncompromising design and
Soundstream REFERENCE405s amplifier will outperform any other
amplifier in the world.
To maximize the performance of your system, we recommend that you
thoroughly acquaint yourself with its capabilities and features. Please
retain this manual and your sales and installation receipts for future
reference.
Soundstream amplifiers are the result of American craftsmanship and
the highest quality control standards, and when properly installed, will
provide you with many years of listening pleasure. Should your
amplifier ever need service or replacement due to theft, please record
the following information, which will help protect your investment.
Model and Serial # ____________________________________
Dealer's Name _______________________________________
Date of Purchase _____________________________________
Installation Shop ______________________________________
Installation Date ______________________________________
CAUTION!
Prolonged listening at high levels may result in hearing loss. Even
though your new Soundstream REFERENCE405s amplifier sounds
better than anything you've ever heard, exercise caution to prevent
hearing damage.
Amplifier, the product of an
engineering philosophy.
2
Your
POWER
Watts
POWER
High Power
High Current
THD
Signal to Noise
Frequency Response (Ch's 1-4):
Frequency Response (Sub Ch):
Stereo Separation
Damping
Input Sensitivity (Ch 1-4):
Input Sensitivity (Subwoofer Ch): 80 mV - 5.0 V
Input Impedance
Crossover Specifications
High Pass (Channels 1 - 4):
Low Pass (Subwoofer Channel): 24 dB/octave, continuously vari-
Dimensions
W x D x H:

SPECIFICATIONS

REFERENCE405s - - Channels 1 & 2, 3 & 4
4 Stereo
(8 Bridged)
(12 Volts)
25 Watts x 4
REFERENCE405s - - Subwoofer Channel
4 2
(12 Volts)
100 Watts 200 Watts 240 Watts
50 Watts 100 Watts 200 Watts
<0.1%
>100 dB
20 Hz to 20 kHz ± 0.5 dB
20 Hz to 400 Hz ± 0.5 dB
>90 dB
>200
200 mV - 5.0 V
12 k
12 dB/octave, continuously vari-
able from 60 to 240 Hz
able from 30 to 120 Hz
15.0" x 9.8" x 2.25"
19
2 Stereo
(4 Bridged)
50 Watts x 4
1 1/2
n/a
240 Watts
