Soundstream PICASSO PCX2.180 Owner's Manual

Soundstream picasso series

Hide thumbs Also See for PICASSO PCX2.180:

Owner's manual (21 pages)

Table Of Contents

Quick Links

Download this manual

OWNER'S MANUAL

PCX2.180 / 2.270/ 2.350 / 2.440 / 2.540 / 2.700

PCX4.240 / 4.360 / 4.540

PCX5.600

Table of Contents

Need help?

Do you have a question about the PICASSO PCX2.180 and is the answer not in the manual?

Questions and answers

Summary of Contents for Soundstream PICASSO PCX2.180

Page 1 OWNER'S MANUAL PCX2.180 / 2.270/ 2.350 / 2.440 / 2.540 / 2.700 PCX4.240 / 4.360 / 4.540 PCX5.600...
Page 3 TABLE OF CONTENTS INTRODUCTION... FEATURES & SPECIFICATIONS... CONTROLS & FUNCTIONS... PLANNING & MOUNTING YOUR SYSTEM... WIRING DIAGRAM... ADJUSTING & TUNING... TROUBLE SHOOTING... 4 ~ 8 9 ~10...
Page 4 INTRODUCTION Amplifier's provide high-performance sound reinforcement for you'r mobile audio equipment. The Multi-Mode bridging capabilities allow flexibility in hosting several different speaker configurations. To achieve optimum performance, it is highly recommended that you read this Owners Manual before beginning installation.
Page 5: Specifications
FEATURES (Intelligent Distress Indicator)gives a visual indication of the amplifier's protection status Fully regulated MOSFET power supply PWM circuitry Tri-guard amplifier protection Platinum RCA inputs and outputs Bi-linear selectable crossovers for inputs and outputs (Hi/Full/Low) Continuously variable high and low-pass crossovers Subwoofer equalizer control switch Viable phase shift control (0 - 180 degree) OEM floating ground input...
Page 6: Controls And Functions
Controls & Functions PCX2.180 / 2.270 / 2.350 / 2.440 / 2.540 / 2.700 PCX4.240 / 4.360 / 4.540 REMOTE CH3/4 PHASE CROSS HIGH REMOTE BASS OVER PASS BOOST FULL (Hz) HIGH 2 Channel High Power Mosfet Amplifier 2 Channel High Power Mosfet Amplifier POWER FUSES BATT...
Page 7 Controls & Functions PCX5.600 HIGH INPUTS INPUTS PASS (Hz) MIN MAX LEVEL 1/2 1/2 FUSES BATT HIGH INPUTS LEVEL FREQ PASS PASS (Hz) (Hz) (Hz) MODE MIN MAX MIN MAX LEVEL LEVEL PHASE SPEAKER POWER 5 Channel High Power 5 Channel High Power Mosfet Amplifier Mosfet Amplifier PROT...
Page 8 Controls & Functions 1. Input Level Adjustment This control adjusts the amplifier's input sensitivity. Input sensitivity is variable from 200 Millivolts to 8 volts. Clockwise increases sensitivity. Counterclockwise decreases sensitivity. The amplifier can be driven to full power with a wide range of signal levels. A lower signal level will require increased sensitivity for full power.
Page 9: Cross Over Switch
Controls & Functions 5. Subsonic Filter Control Variable Subsonic Filter (15Hz - 40Hz) : The Subsonic filter will roll off all of the unwanted frequencies below 15Hz - 40Hz. This will allow the amplifier to use that wasted power on the audible bandwidth. 6.
Page 10: Remote Power On
Controls & Functions 9. LED Indicator PWR(Power): This GREEN LED will illuminate when the amplifier is turned "ON". If it fails to illuminate, check the power connections to the Amplifier and fuses. PROT(Protection): The amplifier protection circuitry will disable the amplifier if input overload, short circuit or extremely high temperature conditions are detected.
Page 11: Speaker Terminals
Controls & Functions 12. B- Terminal (Chassis ground) POWER BATT PCX2.180/2.270/2.350/2.440/ PCX2.540/2.700 To avoid unwanted ignition noise caused by ground loops, it is essential that the Amplifier be grounded to a clean, bare, metal surface of the vehicles chassis. Note : GROUND WIRE SHOULD NOT BE EXTENDED MORE THAN 3 FT (1 METER). 13.
Page 12 Planning and Mounting Your System The mounting position of your Amplifier will have a great effect on its ability to dissipate the heat generated during normal operation. Under normal conditions, the heatsink will dissipate sufficient heat to avoid thermal shutdown. However please do not install the amplifier in a wooden box or similar device as this will prevent heat dissipation into the atmosphere.
Page 13 Planning and Mounting Your System PULL PULL...
Page 14: Stereo Mode
PCX2.180 / 2.270 / 2.350 / 2.440 / 2.540 / 2.700 Mono mode Stereo mode Tri mode SPEAKER IMPEDANCE FREQUENCY 60 Hz 11.8 mH 6OO uF 80 Hz 8.2 mH 5OO uF 100 Hz 6.2 mH 4OO uF 120 Hz 4.2 mH 3OO uF 6 dB/Octive High Pass and Low Pass Filter...
Page 15: Channel Mode
PCX4.240 / 4.360 / 4.540 2Channel mode 3Channel mode 4Channel mode SPEAKER IMPEDANCE FREQUENCY 11.8 mH 6OO uF 60 Hz 8.2 mH 5OO uF 80 Hz 6.2 mH 4OO uF 100 Hz 4.2 mH 3OO uF 120 Hz 6 dB/Octive High Pass and Low Pass Filter POWER FUSES BATT...
Page 16 PCX5.600 3Channel mode 5Channel mode TRI mode SPEAKER IMPEDANCE FREQUENCY 11.8 mH 6OO uF 60 Hz 8.2 mH 5OO uF 80 Hz 6.2 mH 4OO uF 100 Hz 4.2 mH 3OO uF 120 Hz 6 dB/Octive High Pass and Low Pass Filter POWER FUSES BATT...
Page 17: Adjusting The Audio Level
Tuning on the Amplifier The amplifier automatically turns on a few seconds after you turn your vehicle's ignition switch to ACC or ON or turn on your auto sound system, depending on how you wired the system. The POWER indicator on the top of the amplifier lights when the amplifier is on.
Page 18: Trouble Shooting
Trouble Shooting SYMPTOMS Is the power NO SOUND LED illuminated? (NO) Is the Diagnostic LED illuminated? (YES) No power to power wire AMP NOT SWITCHING No power to remote wire with receiver on Burnt or broken fuse NO SOUND Check Speaker Leads IN ONE CHANNEL Check Audio Leads...
Page 20 www.soundstream.com...
