CONNECTION DIAGRAM

Connect the unit as in the diagram below.
4
DA
1
DB
5
DG
2
SLD
3
FG
6
24VDC
7
0V
■ Output Connection Example
10
+24V
1
0V
2
Y0
18
YF
10
+24V
2
Y0
3
Y2
4
Y4
5
Y6
6
Y8
7
YA
8
YC
9
YE
11
Y1
12
Y3
13
Y5
14
Y7
15
Y9
16
YB
17
YD
18
YF
1
0V
+
–

WIRING INSTRUCTIONS

■ SOLDERLESS TERMINAL mm (inch)
Refer to the drawing below for recommended ring tongue
terminal size. Spade tongue type is also applicable. Solder-
less terminals with insulation sleeve do not fit. Applicable
wire size: 0.3 – 0.75 mm
2
3 (.12) max.
R7C-DC16A
4 min.
(.16)
3.2 (.13) dia.
12 (.47) max.
