Summary of Contents for FRIGOGLASS Flex 35 HC

  • Page 1     Flex 35 HC Flex 45 HC Flex 60 HC                    ...
  • Page 2 User Manual This User Manual was originally written in English. Before using this ICM please read the instructions below carefully. Please see below the interpretation of the symbols used throughout the manual, for your better understanding. WARNING INFORMATION CAUTION FIRST AID...

  • Page 3: Table Of Contents

    Table of Contents Foreword ..........4 Technical description ......4 2.1 General ..........4 2.2 Climate classification ......4 2.3 Technical specifications ...... 4 2.4 Physical dimensions ......4 2.5 Maximum weight per shelf ....4 Installation & Operation ....... 5 3.1 ICM placement instructions ....

  • Page 4: Foreword

    Climate classification According to climate specifications, models Flex 35 HC, Flex 45 HC and Flex 60 HC are Class "4" (as per ISO23953-2), which means ambient temperature of 30°C and 55% humidity for Flex 35 HC and Flex 45 HC and 32,2°C and 65% humidity for Flex 60 HC.

  • Page 5: Installation & Operation

    Models Flex 35 HC, Flex 45 HC and Flex 60 HC are equipped with HC refrigerant, and have been tested and proven to be safe according to related standards. All necessary actions for safe usage & maintenance of this appliance are described in this manual and need to be followed carefully.

  • Page 6: Connection To The Mains Supply

    Please, adjust until the ICM levels and check using a spirit level, if available. Take the necessary precautions if lifting is required during installation. Do not allow the access of unauthorized individuals during the cooler installation. The merchandiser must stand upright for at least 1 hour after transportation and prior to start-up. This provides sufficient time for the oil to run back to the compressor after transit and installation.

  • Page 7: Care & Cleaning

    Do not operate the appliance while any of the cover sheets and guards is open. Energy saving tips: For energy saving and ICM’s better performance: • Load your ICM at night-time so that the drinks are cold once you get there in the morning. •...
  • Page 8 Models Flex 35 HC, Flex 45 HC and Flex 60 HC are equipped with HC refrigerant. All service operations on cooling mechanism & gas charging should be performed in a well ventilated environment or in open air. Do not smoke during maintenance.

  • Page 9: First Aid

    FAULT POSSIBLE REASONS HANDLING Intense metallic noise. Call a Service technician. The ICM makes Level the ICM properly by adjusting its noise. Inclined or curved floor. feet. Placing a spirit level on the top of the ICM will assist you in leveling it. The drainage hole for the Unblock the drainage hole.

  • Page 10: Recycling Information

    8. Recycling Information Based on the objectives of environmental policy according to the European Community (EC) directives of Waste Electrical and Electronic Equipment (WEEE) which aim to preserve, protect and improve the quality of the environment, protect human health and utilize natural resources prudently and rationally, as an end user, you are kindly requested to do the following: •...

  • Page 11: Appendix Ahandling & Transportation Guidelines

    FOR AUTHORIZED SERVICE PERSONNEL ONLY APPENDIX A HANDLING & TRANSPORTATION GUIDELINES The merchandiser should always be transported:  in upright position (unless otherwise authorized by the supplier)  with the doors closed and stoppers for the sliding door models  in its original packaging or similar one.

  • Page 12: Appendix Cguidelines To Prevent Corrosion Of The Cabinet

     Check that components that might have been replaced during servicing are original. 3. Refrigeration System:  Check that the compressor is functioning properly.  Check the starting relay, the overload and the capacitor. The Supplier recommends that the compressor's starting relays and overloads be replaced every 3-4 years. ...
  • Page 13 PRODUCTION FACILITIES Address Switchboard GREECE FRIGOGLASS S.A.I.C. 252 00 Kato Achaia +30 2610 633000 FRIGOGLASS INDIA PRIVATE Plot no. 26 - A, sector 3 INDIA +91 124 4320800 LIMITED IMT Manesar, Gurgaon 122050, Haryana Jababeka Industrial Estate JL.Jababeka VI INDONESIA FRIGOREX INDONESIA P.T...
