Summary of Contents for GARO LS4 MINI 43kW
- Page 1 LS4 MINI 43kW Assembly instructions / End User Instructions (EN) GARO AB Box 203, SE–335 25 Gnosjö Phone: +46 (0) 370 33 28 00 info@garo.se garo.se...
-
Page 2: Table Of Contents
TABLE OF CONTENT About this manual INFORMATION Warnings Cautions Notes Content INSTALLATION USER MANUAL Normal use LED indications Dimensional sketch Electrical diagram Technical specifications Service / Maintenance Service and maintenance form Installation Form... -
Page 3: About This Manual
However, because continuous LS4 MINI improvement is a goal at GARO, we reserve the right to make product and software modifications at any time. This range is This equipment should not be used by anyone (including subject to continual product development. -
Page 4: Cautions
INFORMATION Cautions Content Incorrect installation and testing of the LS4 MINI could potentially damage either the vehicle and/or the LS4 MINI itself. Poor quality electricity may harm the LS4 MINI and or the vehicle. An example of such source of poor quality electricity may be private power generators. -
Page 5: Installation
Note: Wall installation requires a minimum 20mm distance between the wall and the LS4 MINI to ensure correct cooling, (figure 4) Recommendation is to use the GARO wallbracket, E-number 2480331, Article number 353689 4. Install the electric supply cable L1, L2, L3 and N to the Main Switch and PE to PE terminal. - Page 6 INSTALLATION 0,5-2,0mm L1, L2, L3, N 6Nm L1, L2, L3, N 2,5-16mm² 5Nm, 2,5-10mm² 5Nm, 25-50mm² 10Nm 4x ALU-CU adapters 16-50mm² 10Nm 2,5-10mm² 5Nm 16-50mm² 10Nm (figure 3) (figure 4) 0,8Nm +-0,05 (figure 5) Pedestal = Accessory Article number 354386...
-
Page 7: User Manual
USER MANUAL USER MANUAL Normal use Connect the charging cable to the EV (Electric Vehicle). If authorization is activated, please hold a valid RFID-tag against the RFID reader on the side of the LS4 you want to use or use the operator app to authorize charging. - Page 8 If the charger is supposed to work without RFID/app without success? Contact your authentication, contact the backend operator and ask them to installer or GARO Support. verify that "Free charging" is set to ON. (please have M-number Connect the charging cable to the vehicle, or verify that cable is available) connected correctly.
- Page 9 15 minutes if cable is not Have you tried everything disconnected. without success? Contact your Reset circuit breaker. installer or GARO Support. Check internal wiring and components for possible reasons for (please have M-number short circuit. available)
- Page 10 DC powered without success? Contact your components (controllers, upper PCB, router/switch etc.) inside installer or GARO Support. the charging station. If LED-light [DC OK] remains turned off, NO LIGHT (please have M-number consider replacing the 12V power supply unit.
-
Page 11: Dimensional Sketch
USER MANUAL LED light indication Indication / fault code in Web UI OCPP fault code IDLE (available) - (A) Vehicle not connected IDLE (available) - (B) Vehicle connected not ready Firm green IDLE (available) - (C) Vehicle connected ready IDLE (available) - (A) Vehicle not connected Blinking green (3 blinks) AUTHORIZED (available) - (A) Vehicle not connected... -
Page 12: Electrical Diagram
ELECTRICAL DIAGRAM Electrical diagram Ant. Components Placement (Read from top to bottom) ANT = 4G antenna -KF1 KF1 = Led light Topcard -FAN DC Terminal FAN = Fan 12V AC Terminal -RFID 1 AC Terminal = AC Terminal Block 230V 230V DC Terminal = DC Terminal Block +12V/-12V CC1 = Charge Controller (Master) - Page 13 ELECTRICAL DIAGRAM Siemens 7KT1666 Lovato DME D301 CC1 - B Modbus CC1 - A Modbus GARO GNM3D-RS485 Carlo Gavazzi EM340 CC1 - B Modbus CC1 - A Modbus GMI3D-LP L1 i L1 o L2 i L2 o L3 i L3 o...
- Page 14 ELECTRICAL DIAGRAM -DC Terminal P1-A -DC Terminal Down side Up Side Eth 1 2 4 6 8 10/100 CC1 (4G) RJ45 -DC Terminal RFID P1-B Type 2 Charge cable HEAT -AC Terminal -QA1-A1 External Energy Meter...
-
Page 15: Technical Specifications
USER MANUAL Technical specifications Product type LS4 MINI 43kW Standards / Directives IEC 61851-1 and IEC 61439-7 EMC Classification: 2014/30/EU Installation method: Wall / Ground* Installation environment: Indoor / Outdoor Location type: Non-restricted Access Rated Voltage: 400V 50Hz Installation systems:... -
Page 16: Service / Maintenance
LS4 MINI, conditioning of components as well as functional tests. Specific service points can be found in the service form. If your LS4 MINI is connected to Backend Operator or other external supervised system, GARO recommends that you contact the operator, to plan the service in advance, in order to avoid unnecessary errors and warning messages that could lead to expensive emergency call outs from other service partners. -
Page 17: Installation Form
USER MANUAL Installation Form LS4 MINI Model: M nr: ELECTRICAL INSTALLATION DATA Group fuse (A): Supply cable dimension: FUNCTION TEST Testbox: Date: Sign Installer: Company Name: Owner/Customer Name: Installation address:... - Page 19 GARO AB Box 203, SE–335 25 Gnosjö Phone: +46 (0) 370 33 28 00 info@garo.se garo.se...
