8.
FEET / METERS button: In cable length mode, press the FEET / METERS button to select
units of Meter (M) or Feet (FT).
LED:
9.
the light is off, measurements are for resistive materials only.
10. Power error LED: If the light is on, measurement errors may be caused by one of the
following reasons:
Low battery voltage
Blown fuse
Measuring a device with electrical potential (voltage).
(Note: the electrical potential (voltage) could cause damage to the meter.)
11. Output error LED: If the light is on, measurement errors may be caused by one of the
following reasons:
Test leads or the measured cable is not properly connected.
Resistance is too high (higher than the measurement range)
Output current is less than needed for the load.
12. Rotary Switch: The Switch provides selections of: OFF, 6 measurement ranges (6000Ω,
600Ω, 60Ω, 6Ω, 600mΩ and 60mΩ) and SETUP.
13.
button: Press this button to enable/disable the backlight.
14.
button: (for 600mΩ (1A) and 60mΩ (10A) ranges) Press to measure inductive
materials when the
15.
button: Press the Beep button to turn on/off the alarm function (HI and LO). When the
alarm function is enabled, the
the HI-LO range, a "PASS" will be displayed. If the value of resistance is out of HI-LO range,
the beeper will sound. But if the value of resistance is out of the measuring range (LCD
displays "OL"), the alarm function is disabled.
16. Range x10 button: In each rotary switch position, three sub-range can be selected by
pressing this button. Press the Range x10 button for over 2 seconds to return to Auto Range.
In the auto range, a symbol of AUTO will be displayed in LCD.
In the SETUP mode, press this button to move the decimal point of a number.
17. Ω / LENGTH button: Press Ω / LENGTH button to select measurement mode or length mode.
Press Ω / LENGTH button for over 2 seconds to store the present value of resistance as the
resistance per foot or meter.
If the light is on, measurements are for both inductive and resistive materials. If
LED is off.
icon will be shown in LCD. If the value of resistance is within
4
UM200-en-GB_V1.6 10/19
