2" J-FORCE™ | QUICK START GUIDE
! ! DANGER
THIS PRODUCT CAN BE DANGEROUS IF NOT USED PROPERLY! Always wear appropriate
Personal Protective Equipment (PPE). Detailed PPE information can be found at: www.fsesgsafety.
com and clicking on the JETSTREAM name or by referring to the yellow JETSTREAM SAFETY
WARNING pamphlet (PI-082).
The following Quick-Start Guide is intended to provide the customer with an
expedient reference for 2" J-Force installation and operation. It does not replace
the complete product instructions (PI-176).
This product is sold with the understanding that the purchaser agrees to
thoroughly train all operators and maintenance personnel in the correct and
safe installation, operation, and maintenance of the product and to provide
adequate supervision of personnel at all times. JETSTREAM urges customers to
make complete instructions available to all personnel and ensure they are read
thoroughly before installing, connecting or using the 2" J-Force. Retain these
instructions for future reference. If this product is resold or otherwise conveyed,
the purchaser must pass on these instructions to the new user. If any questions
remain, or to request additional copies, call JETSTREAM at (800) 231-8192 or
(832) 590-1300.
Read the yellow JETSTREAM SAFETY WARNING pamphlet (PI-082) included with
the shipment of the product.
CONNECTING 2" J-FORCE
Prior to the start of any job, make sure only high pressure rated fittings and
hoses are used in the waterblasting system.
Prior to installing the 2" J-Force onto the hose, flush the system to clear any
debris.
15K PSI RATED CONNECTION (1/4" BSPP)
1. BSPP flat seal connections require a copper crush washer between the male
and female connections.
2. Seat copper crush washer in female BSPP connection on mandrel
3. Apply anti-seize compound to male threads of mating hose end.
4. Install the JF2X15 by using an appropriate open-ended wrench on flats found
on the body and tighten to 20 lbs. ft.
22K PSI RATED CONNECTION (9/16" & 3/8" LH/RH FEMALE INLET)
1. Apply anti-seize compound to the male threads of the connection.
NOTE: DO NOT use Teflon tape on 22K PSI connections.
2. Install the JF3X22 by using an appropriate open-ended wrench on flats found
on the body and tighten until firmly snug.
NOTE: DO NOT OVERTIGHTEN. Damage to coned sealing surface could result.
22K PSI RATED CONNECTION (1/2" NPT FEMALE INLET)
1. Apply 3-4 wraps of Teflon thread sealant tape to the available male threads of
the connection.
2. Apply anti-seize compound over the sealant tape for additional protection
against galling.
Jetstream of Houston LLP • 5905 Thomas Road Houston, TX 77041
3. Install the JF2X22 by using an appropriate open-ended wrench on flats found
on the body and tighten 1-2 turns past hand-tight. All NPT pipe connections
should have a minimum thread engagement of (4) threads.
OPERATION
As per the WJTA-IMCA Recommended Practices, all operators shall follow the
OSHA regulations for personal protective equipment. (OSHA guidelines for
Personal Protective Equipment are available in document number 3151-12R 2004,
which can be obtained from www.osha.gov.) All operators shall be issued suitable
head protection, eye protection,hearing protection, body protection, hand and
foot protection and respiratory protection (if needed). For detailed specifications
on all protections required, refer to the WJTA-IMCA 'Recommended Practices
for the Use of High Pressure Waterjetting Equipment' Section 6, Protective
Equipment For Personnel.
! !
CAUTION
The 2" J-Force™ can be used at a minimum service temperature of -20°C (-4°F) and a
maximum service temperature of 115°C (240°F). Use at temperatures lower or higher than these
recommended temperatures may result in premature tool failure.
1. Start by slowly increasing pressure to 500 psi and check the entire system,
including all connections, for leaks. Increase pressure in increments,
pausing at each to inspect the system for leaks, proper rotation of tool,
temperature, and other operational anomalies. If any problems are
discovered, lower pressure back to zero and turn off source of power before
making any adjustments.
2. During operation, it is normal for water to leak out of the front of the head
from around the front nozzle (or front plug). This leak-by water comes from
the water-bearing that the tool operates on.
! !
WARNING
Remove the nozzle from service if:
a. The rotor or mandrel shows signs of cracking or other damage.
b. The wall thickness of these parts is reduced by 25% at any point.
c. The nozzles can no longer hold pressure at water flow rate for which it was sized.
NOTE: For improved reliability and longer life, it is recommended that
a filter of at least 10 microns be used on the water supply inlet. A
strainer (100 mesh minimum) must also be used in the water tank
(if equipped with tank).
QSG-176
! !
DANGER
Failure to follow the following instructions will cause unsafe conditions, severe injury can result.
• DO NOT operate the 2" J-Force above its specified pressure.
• Operator must wear ear protection due to the noise generated by the spinning nozzle.
• NEVER stand in the plane of blasting.
• A Lance Safety Grip is recommended to minimize the risk of a live nozzle unexpectedly exiting
the tube back at the lance operator.
• At high-pressure, the water can be hot. Wear gloves and use caution to prevent scalding.
• Place barricades with warning signs or barricade tape around the work area. This includes
the waterblast unit and all high-pressure hoses.
• Operator must be outfitted with proper safety apparel (refer to yellow JETSTREAM SAFETY
WARNING pamphlet). Body armor is strongly recommended.
! !
CAUTION
DO NOT use the 2" J-Force if it has not been cleaned and inspected prior to starting the working
shift.
FOR FURTHER INFORMATION SEE:
https://www.youtube.com/user/JetstreamWaterblast
and the
Jetstream Safety Manual
