USER'S MANUAL
Model No. IMTL39606.5
Serial No.
Write the serial number in the
space above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
1-800-753-4645
CALL TOLL-FREE:
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.imagefitness.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 15.5 S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Image 15.5 S

Summary of Contents for Image 15.5 S

  • Page 1 All manuals and user guides at all-guides.com www.imagefitness.com USER'S MANUAL Model No. IMTL39606.5 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE;...

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. IMAGE is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    3. Use the treadmill only as described. on page 11. To purchase a surge suppressor, see your local IMAGE dealer or call the tele- 4. Place the treadmill on a level surface, with at phone number on the front cover of this man- least 8 ft.
  • Page 4 All manuals and user guides at all-guides.com 19. Never leave the treadmill unattended while it 23. Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. the power cord, and switch the reset/off cir- cuit breaker to the off position when the 24.

  • Page 5: Before You Begin

    ® mill. The 15.5 S treadmill offers a selection of features ual. To help us assist you, note the product model designed to make your workouts at home more effec- number and serial number before contacting us.

  • Page 6: Assembly

    All manuals and user guides at all-guides.com ASSEMBLY To hire an authorized service technician to assemble the treadmill, call toll-free 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove the packing materials; do not dispose of the packing materials until assembly is completed.
  • Page 7 All manuals and user guides at all-guides.com 2. Orient the Left Upright (31) as shown, and at- tach it to the Base (48) with two Upright Bolts Latch (40) and two Upright Star Washers (39); do not Holes tighten the Upright Bolts yet. 3.
  • Page 8 All manuals and user guides at all-guides.com 5. Raise the Uprights (31, 36). See the left inset drawing. Identify the two Frame Spacers (34). Open the included packet of grease, and apply grease to both sides of both Frame Spacers. Then, identify the outer side of each Frame Spacer.
  • Page 9 All manuals and user guides at all-guides.com 7. Route the Upright Wire (28) through one of the Handrails (18) as shown, and remove the wire tie from the Upright Wire. Wire Tie Attach the Handrail (18) to the Right Upright (36) with two Handrail Bolts (20) and two Handrail Star Washers (19).
  • Page 10 All manuals and user guides at all-guides.com 10. Lower the Uprights (31, 36). Side View See the inset drawing. Position the Uprights (31, 36) so that the treadmill Frame (74) is cen- tered between the Uprights. Firmly tighten the Frame Bolts (32) and then the 31, 36 Upright Bolts (40) on each side of the treadmill.

  • Page 11: Operation And Adjustment

    Grounded Outlet Box ing 1 at the right). To purchase a surge suppres- Adapter sor, see your local IMAGE dealer or call the tele- Surge Suppressor phone number on the front cover of this manual and order part number 146148, or see your local electronics store.
  • Page 12 All manuals and user guides at all-guides.com CONSOLE DIAGRAM Clip Note: If there are sheets of clear plastic on the console, remove the plastic. FEATURES OF THE CONSOLE To use the manual mode, see page 13. To use a step program, see page 15. To use a calorie goal program, see page 16.
  • Page 13 All manuals and user guides at all-guides.com HOW TO USE THE MANUAL MODE To stop the walking belt, press the Stop button. The time will begin to flash in the display. To 1. Insert the key into the console. restart the walking belt, press the Start button, the Speed increase button, or one of the ten numbered See HOW TO TURN ON THE POWER on page 12.
  • Page 14 All manuals and user guides at all-guides.com avoid moving The upper left corner of your hands. the display can show the elapsed time, the When your pulse speed of the walking is detected, the belt, the approximate heart symbol in number of calories that the display will you have burned, the number of steps you have...
  • Page 15 All manuals and user guides at all-guides.com HOW TO USE A STEP PROGRAM As you exercise, adjust the speed and incline of the treadmill as desired by pressing the Speed and 1. Insert the key into the console. Incline buttons. See HOW TO TURN ON THE POWER on page 12.
  • Page 16 All manuals and user guides at all-guides.com HOW TO USE A CALORIE GOAL PROGRAM When the first segment is completed, all speed set- tings will move one column to the left. The speed 1. Insert the key into the console. setting for the second segment will then be shown in the flashing current segment column and the See HOW TO TURN ON THE POWER on page 12.
  • Page 17 All manuals and user guides at all-guides.com THE INFORMATION MODE the key into the console. However, when you remove the key, the displays will remain lit, although the but- The console features an information mode that keeps tons will not function. If the demo mode is turned on, a track of treadmill usage information.

  • Page 18: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL All manuals and user guides at all-guides.com HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If you do not do this, you may damage the treadmill when you fold it.
  • Page 19 All manuals and user guides at all-guides.com HOW TO LOWER THE TREADMILL FOR USE 1. Hold the treadmill with your right hand as shown. Pull the latch knob to the left and hold it. Pivot the frame down until it is past the latch pin.

  • Page 20: Troubleshooting

    All manuals and user guides at all-guides.com TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 21 All manuals and user guides at all-guides.com PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 11. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 2–3 in.

  • Page 22: Exercise Guidelines

    All manuals and user guides at all-guides.com EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 23 All manuals and user guides at all-guides.com SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips.

  • Page 24: Part List

    PART LIST—Model No. IMTL39606.5 All manuals and user guides at all-guides.com R0909A Key No. Qty. Description Key No. Qty. Description Hood Belly Pan 3/4" Screw Controller Left Foot Rail Lift Frame Washer Foot Rail Screw Lift Frame Bolt Motor Tension Bolt 3/8"...

  • Page 25: Exploded Drawing

    All manuals and user guides at all-guides.com EXPLODED DRAWING—Model No. IMTL39606.5 R0909A...

  • Page 26: Limited Warranty

    All manuals and user guides at all-guides.com ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
