Model No. IMTL41205.0
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT DI-
RECTLY.
CALL TOLL-FREE:
1-800-753-4645
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.iconservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.imagefitness.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Image IMTL41205.0
Summary of Contents for Image IMTL41205.0
- Page 1 Model No. IMTL41205.0 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT DI- RECTLY.
-
Page 2: Table Of Contents
HOW TO FOLD AND MOVE THE TREADMILL ........ - Page 3 SAVE THESE INSTRUCTIONS The decal shown here has been placed on the treadmill. If the decal is missing, or if it is not legible, call the toll-free telephone number on the front cover of this manual and order a free replacement decal.
-
Page 4: Before You Begin
FREESTRIDE number and serial number before contacting us. The model number of the treadmill is IMTL41205.0. The se- rial number can be found on a decal attached to the treadmill (see the front cover of this manual for the lo- cation). -
Page 5: Assembly
During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner. - Page 6 3. With the help of a second person, position the treadmill with the Uprights (62, 76) in a vertical position as shown. Route the Wire Harness (21) up through the bracket on the Right Handrail (47) and out the large hole in the side of the Right Handrail.
- Page 7 3/4” Screws (13). Be careful not to overtighten the Screws. 9. Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may be in- cluded. Keep the included allen wrenches in a secure place; the large allen wrench is used to adjust the walk- ing belt (see page 14).
-
Page 8: Operation And Adjustment
(see drawing 1 at the right). To purchase a surge suppressor, see your local IMAGE dealer or call the toll-free tele- phone number on the front cover of this manual and order part number 146148, or see your local electronics store. - Page 9 During each workout, you can change the speed and incline of the treadmill with the touch of a button. As you exercise, the console will display continuous exer- cise feedback; you can even measure your heart rate using the built-in pulse sensor.
- Page 10 Change the incline of the treadmill as desired. To change the incline of the treadmill, press the Incline increase or decrease button until the de- sired incline level is reached. Follow your progress with the displays. The left display—The left display will show...
- Page 11 THE INFORMATION MODE The console features an information mode that keeps track of treadmill usage information. The information mode also allows you to select a unit of measurement for the console and to turn on and turn off the demo mode.
-
Page 12: How To Fold And Move The Treadmill
HOW TO LOWER THE TREADMILL FOR USE 1. See drawing 2 above. Hold the upper end of the treadmill with your right hand. Using your left thumb, press the storage latch to the left. Pivot the frame down until the frame and the foot rail are past the storage latch. -
Page 13: Troubleshooting
PROBLEM: The power turns off during use SOLUTION: a. Check the reset/off circuit breaker on the treadmill frame near the power cord (see the drawing above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in. - Page 14 1/2 of a turn. Be careful not to overtighten the walking belt. Then, plug in the power cord, insert the key, and run the treadmill for a few minutes. Repeat until the walking belt is centered. b. If the walking belt slips when walked on, first remove the key and UNPLUG THE POWER CORD.
-
Page 15: Conditioning Guidelines
For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be “aerobic.”... -
Page 16: Part Identification Chart
PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. Silver Ground Crossbar Screw 1/2” Screw (97)–4 3/4” Screw (13)–8 Screw (91)–1 (53)–2 1” Bolt (8)–4 1”... - Page 17 PART LIST—Model No. IMTL41205.0 Qty. Description Left Handrail Key/Clip Incline Leg Pivot Bolt Cover Left Foot Rail Lift Motor Rear Roller 1” Bolt 1/4” Star Washer Console Base Motor Belt 3/4” Screw Storage Latch Frame Spacer 8” Cable Tie Motor Nut...
-
Page 19: Limited Warranty
• the MODEL NUMBER of the product (IMTL41205.0) • the NAME of the product (IMAGE FREESTRIDE 16.0 treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) • the KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and the EXPLODED DRAWING in the center of this manual) ICON Health &...
