Patent Pending
Model No. IMTL11997
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Serial Number Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
Customer Hot Line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
All manuals and user guides at all-guides.com
®
USER'S MANUAL
Visit our website at
www.imagefitness.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 10.2QL and is the answer not in the manual?

Questions and answers

Related Manuals for Image 10.2QL

Summary of Contents for Image 10.2QL

  • Page 1 All manuals and user guides at all-guides.com ® Patent Pending Model No. IMTL11997 USER'S MANUAL Serial No. Find the serial number in the location shown below. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if there are missing parts, we will guar- antee complete satisfaction...

  • Page 2: Table Of Contents

    LIMITED WARRANTY ............. . .Back Cover Note: An EXPLODED DRAWING is attached in the center of this manual. IMAGE is a registered trademark of ICON Health & Fitness, Inc.

  • Page 3: Important Precautions

    ASSEMBLY on page 6, and HOW TO FOLD page 8. To purchase a surge suppressor, see AND MOVE THE TREADMILL on page 22.) You your local IMAGE dealer or call 1-800-806-3651 must be able to safely lift 45 pounds (20 kg) in and order part number 146148.
  • Page 4 All manuals and user guides at all-guides.com 21. Do not change the incline of the treadmill by 25. Always remove iFIT.com CD’s and videos placing objects under the treadmill. from your CD player or VCR when you are not using them. 22.

  • Page 5: Before You Begin

    And when you’re not number and serial number before calling. The model exercising, the unique IMAGE 10.2QL can be folded number of the treadmill is IMTL11997. The serial num- up, requiring less than half the floor space of other ber can be found on a decal attached to the treadmill treadmills.

  • Page 6: Assembly

    All manuals and user guides at all-guides.com ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench and your own phillips screwdriver and wire cutters Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
  • Page 7 All manuals and user guides at all-guides.com 4. Slide the Grounding Bracket (64) onto one of the Handrail Spacers (65) in the location shown. Tabs See inset drawing A. Pinch the tabs on the Grounding Bracket (64) so that the tabs will fit into the hole in the Upright (69 [see inset drawing B]).

  • Page 8: Operation And Adjustment

    Adapter the right). To purchase a surge suppressor, see Surge Suppressor your local IMAGE dealer or call 1-800-806-3651 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS).
  • Page 9 All manuals and user guides at all-guides.com Program Display Pulse Pulse Sensor Sensor Note: If there is a thin sheet of clear plastic on the face Clip of the console, remove it. FEATURES OF THE CONSOLE Each CD features two programs designed by certified personal trainers.
  • Page 10 All manuals and user guides at all-guides.com Plug in the power cord. CAUTION: Before operating the See HOW TO PLUG IN THE POWER CORD on console, read the following precautions. page 8. • Do not stand on the walking belt when turn- ing on the power.
  • Page 11 All manuals and user guides at all-guides.com Follow your progress with the LED track and HOW TO USE THE MANUAL MODE the displays. The LED track—When Insert the key fully into the console. the manual mode or the iFIT.com mode is se- See GETTING STARTED on page 10.
  • Page 12 All manuals and user guides at all-guides.com Speed/Pace display— When you are finished exercising, stop the This display shows the walking belt and remove the key. speed of the walking belt and your current Step onto the foot pads, press the Stop button, pace (pace is mea- and adjust the incline of the treadmill to the lowest sured in minutes per...
  • Page 13 All manuals and user guides at all-guides.com Each program is divided into several time seg- override the setting by pressing the Speed or ments of different lengths. The Time/Laps display Incline buttons on the console. Every few times shows both the time remaining in the program and one of the Speed buttons is pressed, an additional the time remaining in the current segment.
  • Page 14 All manuals and user guides at all-guides.com adjust the speed and incline of the treadmill to the HOW TO CREATE CUSTOM PROGRAMS desired levels by pressing the Speed and Incline buttons. Every few times one of the Speed but- tons is pressed, an additional indicator will light or Insert the key fully into the console.
  • Page 15 All manuals and user guides at all-guides.com display will flash to alert you, and three tones will HOW TO USE CUSTOM PROGRAMS sound. When the first segment is completed, all speed settings will move one column to the left. The speed setting for the second segment will Insert the key fully into the console.
  • Page 16 All manuals and user guides at all-guides.com HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT THE TREADMILL TO YOUR CD PLAYER, VCR, OR COMPUTER Note: If your stereo has an RCA-type AUDIO OUT jack, see instruction A below. If your stereo has a 3.5mm LINE OUT jack, see instruction B.
  • Page 17 All manuals and user guides at all-guides.com HOW TO CONNECT YOUR HOME STEREO HOW TO CONNECT YOUR COMPUTER Note: If your stereo has an unused LINE OUT jack, Note: If your computer has a 3.5mm LINE OUT jack, see instruction A below. If the LINE OUT jack is see instruction A.
  • Page 18 All manuals and user guides at all-guides.com HOW TO CONNECT YOUR VCR HOW TO USE IFIT.COM CD AND VIDEO PROGRAMS Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B.
  • Page 19 All manuals and user guides at all-guides.com If the speed or incline settings are too high or too • Make sure that the audio cable is properly low, you can manually override the settings at any connected, that it is fully plugged in, and that time by pressing the Speed or Incline buttons on it is not wrapped around a power cord.
  • Page 20 All manuals and user guides at all-guides.com Return to the treadmill and stand on the foot HOW TO USE PROGRAMS DIRECTLY FROM pads. Find the clip attached to the key and OUR WEB SITE slide the clip onto the waistband of your clothes.
  • Page 21 All manuals and user guides at all-guides.com THE INFORMATION MODE/DEMO MODE THE OPTIONAL CHEST PULSE SENSOR The console features an information mode that keeps An optional chest pulse sensor adds even more track of the total number of hours that the treadmill has features to the console.

  • Page 22: How To Fold And Move The Treadmill

    All manuals and user guides at all-guides.com HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged.

  • Page 23: Trouble-Shooting

    All manuals and user guides at all-guides.com TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m.
  • Page 24 All manuals and user guides at all-guides.com PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 8. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- come damaged.

  • Page 25: Conditioning Guidelines

    All manuals and user guides at all-guides.com CONDITIONING GUIDELINES uses easily accessible carbohydrate calories for en- WARNING: ergy. Only after the first few minutes does your body Before beginning this begin to use stored fat calories for energy. If your goal or any exercise program, consult your physi- is to burn fat, adjust the speed and incline of the tread- cian.

  • Page 26: Part List

    All manuals and user guides at all-guides.com PART LIST—Model No. IMTL11997 R0202A To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Key No. Qty. Description Foot Rail Insert Walking Platform Foot Rail Platform Screw...

  • Page 27: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When ordering parts, please be prepared to give the following information: • the MODEL NUMBER OF THE PRODUCT (IMTL11997) • the NAME OF THE PRODUCT (IMAGE ® 10.2QL treadmill) • the SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual) •...

  • Page 28: Limited Warranty

    LIMITED WARRANTY WHAT IS COVERED—The entire IMAGE ® 10.2QL (“Product”) is warranted to be free of all defects in material and work- manship. WHO IS COVERED—The original purchaser or any person receiving the Product as a gift from the original purchaser.
  • Page 29 All manuals and user guides at all-guides.com EXPLODED DRAWING—Model No. IMTL11997 R0202A...
  • Page 30 All manuals and user guides at all-guides.com EXPLODED DRAWING—Model No. IMTL11997 R0202A...
