- Page 1 SETUP INSTRUCTIONS 2020 350 SX‑F 350 XC‑F Art. no. 3214141en...
- Page 3 KTM accepts no liability for delivery options, deviations from fig- ures and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that does not belong to the regular scope of supply.
-
Page 4: Means Of Representation
1 MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips. - Page 5 To operate the vehicle, the vehicle electronics must be enabled. This process is conducted during initial setup in KTM Dealer.net. Enabling ensures that the initial setup in KTM Dealer.net is docu- mented. Enabling can be performed either temporarily, e.g. for a test ride, or permanently for vehicle handover.
- Page 6 2 SETUP Info An assistant prevents the motorcycle from falling over. – Together with an assistant, take the vehicle off the pallet. – Position the vehicle on a lift stand. – Check the vehicle for transport damage. Info The procedure in the event of transport damage is described in the customer service manual.
- Page 7 SETUP 2 – Remove the cardboard from around the shock absorber. – Position the angle lever and linkage lever. – Mount and tighten fitting Guideline Nut, linkage lever M14x1.5 60 Nm on angle lever (44.3 lbf ft) – Mount and tighten screw Guideline F01629-10 Screw, bottom...
- Page 8 2 SETUP – Remove screws . Take off handlebar supports – Position rubber bushings and push through nuts from below. – Place handlebar supports in required position. Info The handlebar supports are longer and higher on one side. Position the left and right handlebar supports evenly. –...
- Page 9 SETUP 2 – Position the controls on the right half of the handlebar. Guideline Screw, throttle grip 5 Nm (3.7 lbf ft) K00645-10 – Position the controls on the left handlebar half. Guideline Screw, fixed 5 Nm (3.7 lbf ft) Loctite ®...
- Page 10 2 SETUP – Mount the left hand guard. – Mount the right hand guard. F01068-01 (All SX‑F models) – Join plug-in connector – Attach cable in the indicator lamp bracket – Route the cables without tension and secure with the cable ties.
- Page 11 SETUP 2 Condition Target market excluding USA – Apply WARNING sticker to the rear fender. Info The WARNING sticker must not be applied together with the COMPETITION ONLY sticker. Condition USA target market F01628-10 – Do not apply the WARNING sticker. Left and right footrest (All SX‑F models) –...
- Page 12 2 SETUP – Mount the washer and split pin – Repeat these steps on the opposite side. F01631-10 Right footrest (XC‑F US) – Position the right footrest and pin. Info Only insert the pin to the extent that the spring can still be mounted.
- Page 13 SETUP 2 – Mount the washer and split pin F01631-10 Left footrest (XC‑F US) – Position the left footrest and pin. Info Only insert the pin to the extent that the spring can still be mounted. R00757-10 – Position spring as shown. Spring engages in area K00688-10...
- Page 14 – Slide positive terminal cover over the positive terminal. – Charge the 12-V battery. ( p. 19) – Unpack and mount the KTM PowerParts included in the deliv- ery (optional). F01636-10...
- Page 15 SETUP 2 Info Read the accompanying KTM PowerParts fitting instruc- tions. – Attach the stickers included in the scope of supply (optional). – Refuel. ( p. 23) – Position all controls in their exact positions on the handlebar. Tighten all screws.
- Page 16 3 WORK Raising the motorcycle with a lift stand Note Material damage The vehicle may be damaged by incorrect procedure when parking. Significant damage may be caused if the vehicle rolls away or falls over. The components for parking the vehicle are designed only for the weight of the vehicle. –...
- Page 17 WORK 3 Installing the front wheel Warning Danger of accidents Oil or grease on the brake discs reduces the braking effect. – Always keep the brake discs free of oil and grease. – Clean the brake discs with brake cleaner when necessary. –...
- Page 18 3 WORK Installing front fender Main work – Position front fender. Mount and tighten screws Guideline Remaining screws, 10 Nm (7.4 lbf ft) chassis F01526-10 Finishing work – Install the start number plate. ( p. 16) Installing the start number plate –...
- Page 19 WORK 3 – Remove screw F01533-10 – Raise the rear of the seat, pull the seat back, and lift it off. H02218-10 Mounting the seat – Mount the front of the seat on the collar bushing of the fuel tank, lower the seat at the rear, and push the seat forward. H02218-11 –...
- Page 20 3 WORK – Remove screw F01588-10 – Pull off the air filter box cover in area sideways and take off toward the front. F01588-11 Condition The air filter box cover is not secured. – Pull off the air filter box cover in area sideways and take off toward the front.
- Page 21 WORK 3 Condition The air filter box cover is not secured. – Insert the air filter box cover in area and clip it into area F01589-11 3.10 Charging the 12-V battery Warning Risk of injury 12 V batteries contain harmful substances. –...
- Page 22 3 WORK Main work – Connect a battery charger to the 12-V battery. Adjust the bat- tery charger. EU battery charger XCharge‑professional (00029095050) Alternative 1 US battery charger XCharge‑professional (00029095051) Alternative 2 311910-10 UK battery charger XCharge‑professional (00029095052) Alternative 3 CH battery charger XCharge‑professional (00029095053) Info...
- Page 23 WORK 3 3.12 Connecting the negative cable of the 12-V battery Main work – Connect negative cable of the 12-V battery. Guideline Screw, battery termi- 2.5 Nm (1.84 lbf ft) Contact disk must be mounted under screw cable lug with the claws toward the battery terminal. T02638-10 Finishing work –...
- Page 24 3 WORK (All SX‑F models) – Turn fuel tank filler cap counterclockwise and lift it off. F01518-10 (XC‑F US) – Press release button , turn the fuel tank filler cap coun- terclockwise, and lift it off. F01557-10 3.14 Closing the fuel tank filler cap (All SX‑F models) –...
- Page 25 WORK 3 3.15 Refueling Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not refuel the vehicle in the vicinity of open flames or lit cigarettes. – Switch off the engine for refueling.
-
Page 26: Technical Data
4 TECHNICAL DATA Chassis tightening torques EJOT PT Screw, air filter box cover ® K60x20-Z 3 Nm (2.2 lbf ft) EJOT PT Screw, combination switch ® K50x18 T20 2 Nm (1.5 lbf ft) EJOT DELTA PT ® Screw, intake air temperature sen- 45x12‑Z 0.7 Nm (0.52 lbf ft) Fitting, start button... - Page 27 TECHNICAL DATA 4 Screw, front brake caliper 25 Nm (18.4 lbf ft) Loctite ® 243™ Screw, handlebar clamp 20 Nm (14.8 lbf ft) Screw, manifold on cylinder head 15 Nm (11.1 lbf ft) brace Screw, side stand attachment 33 Nm (24.3 lbf ft) Loctite ®...
- Page 28 5 SUBSTANCES Super unleaded (ROZ 95/RON 95/PON 91) Standard/classification – DIN EN 228 (ROZ 95/RON 95/PON 91) Guideline – Only use unleaded super fuel that matches or is equivalent to the specified fuel grade. – Fuel with an ethanol content of up to 10 % (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.
-
Page 29: Auxiliary Substances
AUXILIARY SUBSTANCES 6 Long-life grease Recommended supplier MOTOREX ® – Bike Grease 2000... - Page 30 *3214141en* 3214141en 08/2019 KTM Sportmotorcycle GmbH 5230 Mattighofen/Austria Photo: Mitterbauer/KISKA/KTM http://www.ktm.com...
