STEP 2
INSTALL HOOD TO WALL
Mount Wood Support to Wall
below the 16" marked line. Use the center hole in the
wood support as guidance.
16"
30"
to
36"
Centerline of
Installation
match stud locations.
using 2 long, square drive screws.
IMPORTANT: Screws must penetrate at least 1" into
vertical studs. Countersink screws in support.
NOTE: The two supplied mounting screws must remain
in their original shipping location. These screws are
positioned to engage the keyhole slots in the back of the
hood.
1/4"
Gap
will provide clearance to hang the hood.
6
Installation Preparation
Wood Support
Space
Mounting Screws
as Shipped
IMPORTANT: Framing must be capable of
supporting up to 150 lbs.
mounting screws engage the keyhole slots in the
back of the hood. Tighten the screws. Confirm hood
position is correct.
30"
to
36"
Keyhole Slots
the wood support.
hood into studs. Chose the appropriate holes that line
up with studs.
choose screw holes that line up with studs
hood into studs. Choose the appropriate holes that
line up with studs.
choose screw holes that line up with studs
Centerline of
Installation
Space
31-2001216 Rev. 0
