Assa Abloy h.e.s. 9100 Series Installation & Operating Instructions

9100 Series
Electric Strikes
Installation & Operating Instructions
Product Components
A 9100 Strike Body
B 9100 Cover
• Product Components
C 9100 1/8" Spacer
• Product Components
D 5/16"–18 x 3/4"
Mounting Screws
E #12 Self Drilling
Lockdown Screws
F #6-32 x 1/4"
Cover Screws
Specifications
Recommended Wire Gage For Distance
200 Feet
Voltage Current
or Less
12 VDC 240 mA 22
16 VDC 320 mA 20
24 VDC 120 mA 26
UL1034
• Static Strength:
1500 lbs
• Dynamic Strength:
70 ft–lbs
UL294 Performance Levels
• Destructive
Attack: Level I
• Line Security: Level I
• Endurance: Level IV
• Standby Power: Level I
• Outdoor Use
ANSI BHMA A156.31*
• Grade 1
NOTE Installation wiring for the product and wiring
methods shall be in accordance ANSI/NFPA70 National
Electrical Code, Canadian Electrical Code, part 1 and
Local Authority Having Jurisdiction (AHJ). For ULC60839-
11-11 and UL294 complaint systems, DC power shall
be provided through a UL/cUL listed access control, or
burglar alarm power supply with class 2 limited output.
G Door Stop/Rubber
Bumper Kit
H Blind Nut
I Power Pigtail
J LM/LMS Pigtail
(included with LM
and LMS only)
K LMS In-Line Adapter
200–300 300–400
Feet Feet
8
22 20
18 18
26 24
D
• Endurance:
250,000 cycles
C
• Outdoor Use
• CAN/ULC 60839-11-1
B
• Listed for use with
Grade 1 and Grade 2
Access Control
• Humidity: 93 %
• Temperature:
A
-40° to 66° C
8
• Function #: E09361
B
A
C
• Product Components
F
6 5
7
I
J
K
• 9100L LH/RHR
• 9100L LH/RHR
7 6 5
• 9100R RH/LHR
• 9100R RH/LHR
• Product Components
G
4
3
Diagram 1
4 Default
CONFIGURATION
H
D
2
1
E
D
C
B
A
DATE CREATED DRAWN BY DESIGNED BY
DOCUMENT ID SIZE
B
DRAWING NUMBER (ALT ID) REV
1 1
SHEET OF
LEGACY ID
1 of 4
