9500 Series
Installation Instructions
ASSA ABLOY
Multi-Sized 1 thru 6
with Heavy Duty Parallel Arms:
ASSA ABLOY
H.O. without Backstop, N.H.O. with Backstop, H.O. with Backstop
*This application requires an
auxiliary door stop "by others"
Hold Open Only
Non-Hold Open with Backstop
Hold Open with Backstop
(No Stop Feature)
Copyright © 2013, 2018, 2024, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights
reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY
80- 9395-9512-020 Rev 3 (05-24)
Accessories and Door Controls Group, Inc. is prohibited.
Approved 2024-05-14
