Summary of Contents for Teka LI2 1260-LI2 1060
- Page 1 Technical Note LI2 1260-LI2 1060 Service test and Errors Technical Note: NT-WM-0214-00-0314 (March 2014) Subject: Washing Machines LI2 1260-LI2 1060 Service test and Errors Technical Note: NT-WM-0214-00-0314...
-
Page 2: Table Of Contents
Technical Note LI2 1260-LI2 1060 Service test and Errors Contents Introduction......................- 2 - Service test ......................- 2 - Model Selection ....................- 2 - Errors ........................- 3 - Electric Diagram ....................- 4 - Technical Note: NT-WM-0214-00-0314... -
Page 3: Introduction
Technical Note LI2 1260-LI2 1060 Service test and Errors Introduction This Technical note explains how to perform the service test, providing in addition a guide with the errors that could be found on it. Service test In order to enter into the service test, follow the next steps: 1. -
Page 4: Errors
Technical Note LI2 1260-LI2 1060 Service test and Errors Errors Error Cause Solution Lock Automatic door lock It will disappear when the lock is closed. Door is not closed properly or there is a Err1 Door lock error failure in the door lock. -
Page 5: Electric Diagram
Technical Note LI2 1260-LI2 1060 Service test and Errors Electric Diagram Technical Note: NT-WM-0214-00-0314 - 4 -...
Need help?
Do you have a question about the LI2 1260-LI2 1060 and is the answer not in the manual?
Questions and answers
Comment faire fonctionner la machine à laver
To operate the Teka LI2 1260 or LI2 1060 washing machine in service test mode:
1. Press the Delay and Intense buttons.
2. Turn the selector knob to start the machine.
3. The display will blink “TEST” and the model name alternately.
4. Press the Start/Pause button to begin the service test.
The service test follows these steps:
1. Display shows 88:88 – The door closes in 3 seconds.
2. Display shows 77:77 – Water is loaded for 3 seconds through the main wash, prewash, and softener valves.
3. Display shows 66:66 – Heater turns on for 10 seconds.
4. Display shows 33:33 – Drain pump runs for 2 minutes.
5. Display shows 44:44 – Motor spins at 400 rpm, then 800 rpm, each for 10 seconds.
6. Display shows “End” – Test is complete.
For model selection after PCB replacement:
1. Press the Rinse button and plug in the machine at the same time – display shows 850.
2. Press the Speed button to continue configuration.
For normal operation, no specific instructions are provided in the context.
