EDV225MPC-2L-N1-VT
Parts List:
-
2 Line LED Display with Power Cable
-
IR Remote with Battery
-
Photo-eye with Reflective Plate
EDV Production Scoreboard Quick Setup
The EDV production scoreboard is a 2 line model that displays "GOAL" (top line) and
"ACTUAL" (bottom line). Both lines are preset and reset through the supplied IR remote.
The ACTUAL (bottom line) can be configured using a supplied photo-eye and reflective
plate or a momentary contact closure.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EDI EDV225MPC-2L-N1-VT
Summary of Contents for EDI EDV225MPC-2L-N1-VT
- Page 1 ELECTRONIC DISPLAYS INC. 135 S. CHURCH STREET ADDISON, ILL. 60101 www.electronicdisplays.com EDV225MPC-2L-N1-VT Parts List: 2 Line LED Display with Power Cable IR Remote with Battery Photo-eye with Reflective Plate EDV Production Scoreboard Quick Setup The EDV production scoreboard is a 2 line model that displays “GOAL” (top line) and “ACTUAL”...
- Page 2 To configure the display using the IR remote follow these instructions: Preset Top Line Enter the EDIT mode 1. To edit the top line, point the IR remote toward the center of the display. Press / Hold the “TIME” button until the LED dot in the lower right corner of the least significant digit flashes.
