Quantum Data 980 Application Manual page 26

980 HDMI Protocol Analyzer Application Guide – Source Compliance Test Automation
Test ID
7-16 – Legal Codes
7-17 – Protocol Test
7-18 – Extended Control Period
7-19 – Packet Types
7-21 – Minimum Format Support
7-22 – Additional Format Support
7-23 – Pixel Encoding RGB
7-24 – Pixel Encoding YcbCr
7-25 – Video Format Timing
7-26 – Pixel Repetition
7-27 – AVI Infoframe
7-28 – IEC 60958 / 61937
7-29 – ACR
7-30 – Audio Sample Packet Jitter
7-31 – Audio Infoframe
7-32 – Audio Sample Packet Layout
7-33 – Interoperability with DVI
7-34 – Deep Color
7-35 – Gamut Metadata Transmission
7-36 – High Bitrate Audio
7-37 – One Bit Audio
7-38 – 3D Video Format Timing
7-39 – 4K x 2K Video Format Timing
7-40 – Extended Colorimetry Transmission
p-scope> pcap mode all
Pre-Capture Filter set to: No filtering
p-scope> pcap trig vsync 0
cap_trig: trigger basic type=0x1 position=0%
p-scope> pcap start
Waiting for the capture trigger event to occur...
Vsync Asserted
INFO: Capture Trigger condition is satisfied
END: pcap_capture_start
Page 26
% of full buffer (2GB)
41.492
41.492
41.492
41.492
6.483
6.483
6.483
6.483
6.483
6.483
6.483
2.360
22.654
15.103
1.573
1.573
2.360
2.360
2.360
41.492
4.48
4.322
4.322
4.322
// captures all data types (video, data islands)
// sets the capture trigger to vsync
// 980 initiates capture
Resulting/Required buffer size
743MB
743MB
743MB
743MB
116.17MB
116.17MB
116.17MB
116.17MB
116.17MB
116.17MB
116.17MB
42MB
405MB
270MB
28MB
28MB
42MB
42MB
42MB
743MB
88MB
77MB
77MB
77MB
Rev. A1
Feb 14, 2013
