980 HDMI Protocol Analyzer Application Guide – Source Compliance Test Automation

3 Executing the Source Compliance Test

This section provides procedures for running the compliance test through the 980 command line.
3.1

Establishing a Telnet Session with the 980

Your Automated Test System runs the HDMI source compliance test through a telnet session. Use the steps below
to establish a telnet session to the 980.
1. Enter the telnet command at a terminal program to establish a telnet session request with the 980/9080B:
telnet <IP Address>
Where IP Address is the IP address of the 980/980B.
You will be prompted with the pscope login: prompt. Enter the user name and password shown:
Pscope login: qd
Password: qd
The pscope prompt appears.
pscope>
Note: The commands for test automation are executed at the pscope prompt. If you need to access the linux
bash shell enter the following:
p-scope> quit
qd@spcope:~$
2. Alternatively you can use a terminal emulator program such as Putty as shown below:
Page 15
// quits out of the pscope prompt to the bash shell where you
enter linux commands.
