Quantum Data 980 Application Manual page 23

980 HDMI Protocol Analyzer Application Guide – Source Compliance Test Automation
.
.
.
Video Format: N/A
Colorimetry: N/A
Extended Colorimetry: N/A
RGB YCC Indicator: N/A
Color Depth: N/A
Pixel Packing Phase: N/A
Performing the Capture
p-scope> clean
p-scope> pcap vchk enable
p-scope> pcap size 6.483
Capture buffer size 116.17MB
Note: Setting the proper capture buffer is very important and varies per test. The following table will help you
determine what capture buffer setting to use for each test. Please note that the percentages shown in the table to
achieve a required buffer size assume the 980 Protocol Analyzer module has 2GB memory. Recently the 980
Protocol Analyzer module has been enhanced to support 4GB of memory.
Test ID
7-16 – Legal Codes
7-17 – Protocol Test
7-18 – Extended Control Period
7-19 – Packet Types
7-21 – Minimum Format Support
7-22 – Additional Format Support
7-23 – Pixel Encoding RGB
7-24 – Pixel Encoding YcbCr
7-25 – Video Format Timing
7-26 – Pixel Repetition
7-27 – AVI Infoframe
7-28 – IEC 60958 / 61937
7-29 – ACR
7-30 – Audio Sample Packet Jitter
7-31 – Audio Infoframe
7-32 – Audio Sample Packet Layout
Page 23
// clean out extraneous log files.
// check video so that the 980 will not initiate a
capture unless video is present.
// set capture buffer size to 6.483% (116.17MB).
% of full buffer (2GB)
41.492
41.492
41.492
41.492
6.483
6.483
6.483
6.483
6.483
6.483
6.483
2.360
22.654
15.103
1.573
1.573
Resulting/Required buffer size
743MB
743MB
743MB
743MB
116.17MB
116.17MB
116.17MB
116.17MB
116.17MB
116.17MB
116.17MB
42MB
405MB
270MB
28MB
28MB
Rev. A1
Feb 14, 2013
