- Page 1 Bulaşık Makinesi Kullanma Kılavuzu Dishwasher User’s Manual 6555 X 6555 B Document Number : 1728767140_AC_ARCELIK_B5_6555 X_6555 B_EN/ 20-02-19.(14:46)
- Page 2 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
- Page 3 Dishwasher User’s Manual 6555 X 6555 B Document Number : Document Number : 1 728767140_AC_ARCELIK_B5_6555 X_6555 B_EN/ 20-02-19.(14:46)
- Page 4 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 5: Table Of Contents
CONTENTS 1 INSTRUCTIONS FOR SAFETY Collapsible lower basket tines ..23 Collapsible lower basket tines ..24 AND ENVIRONMENT Lower basket bottle wire ....24 General safety ........4 SoftTouch Accessory ......25 Intended use ........5 Lower Basket Glass Holder ....25 Children’s safety .........5 Tray Wash Supports ......25 Disposing of packaging material..5 Lower basket multipurpose / height Transportation of the product .....6... -
Page 6: Instructions For Safety And Environment
INSTRUCTIONS FOR SAFETY AND ENVIRONMENT This section contains safety onto it! There is the risk of instructions that will help to electric shock! get protected from risk of • Never touch the plug personal injury or property with wet hands! Never damage. -
Page 7: Intended Use
instructions for safety and environment Intended use not be made by children without supervision. • This product has been designed for domestic Children’s safety use. • Electrical products are • It must be used to do the dangerous for the children. domestic type dishes only. -
Page 8: Transportation Of The Product
instructions for safety and environment Transportation of the collection center for the recycling of electrical and product electronic equipment. Please If you need to move consult your local authorities the product, do it to learn about these collection in upright position centers. -
Page 9: Dishwasher
DISHWASHER Overview 1. Upper basket 2. Upper impeller 3. Lower impeller 4. Silverware basket 5. Door 6. Rating Label 7. Control panel 8. Detergent dispenser 9. Lower basket 10. Filters 11. Salt reservoir lid 12. Upper basket rail 13. Upper cutlery basket (depends on model) 14. -
Page 10: Technical Specifications
Data required for performance tests shall be provided upon request. Requests can be e-mailed to the following address: standard.test@arcelik.com Do not forget to provide the code, stock and serial numbers of the product to be tested in your request e-mail along with your contact information. Code, stock and serial numbers of the product may be found on the type label attached to the side wall of the door. -
Page 11: Installation
INSTALLATION Refer to the nearest Authorised When placing the product, pay Service Agent for installation of your attention not to damage the floor, walls, product. To make the product ready piping, etc. Do not hold the product by for use, make sure that the electricity, its door or panel to move it. -
Page 12: Connecting Water Supply
Installation Connecting water supply Use a screw-on hose connector to connect the We recommend attaching water inlet hose to a water a filter on the house/ tap with a ¾ inch external apartment supply water thread. If required, use a inlet to protect the machine filter insert to filter deposits from damages that may... -
Page 13: Adjusting The Feet
Installation than 16 Amps, have a qualified Drainpipe must be electrician install a 16 Amp fuse. connected to the sewage • The specified voltage must be system and it should not be equal to your mains voltage. connected to any surface •... -
Page 14: Preparation Tips For Energy Saving
PREPARATION Tips for energy saving Adding salt Following information will help you use Water softening system needs to be the product in an ecological and energy- regenerated in order for the product efficient manner. operates with the same performance Wipe away any coarse food remnants continuously. -
Page 15: Detergent
Preparation Detergent 3. Add 1 litre of water to salt reservoir of your machine only in initial use. You can use powder, liquid/gel or tablet 4. Fill the salt reservoir with salt by detergents in the machine. using the salt funnel (D). To speed Only use in the machine up dissolution rate of salt in water, the detergents produced... -
Page 16: Tablet Detergents
Preparation Inside the detergent dispenser there are level markings that help you use appropriate amount of powder detergent. When brimful, detergent dispenser will contain 45 cm³ of detergent. Fill detergent up to 15 cm³ or 25 cm³ level marks in the detergent dispenser according to fullness of the machine and/ or soiling degree of the... -
Page 17: Rinse Aid
Preparation Rinse aid The best washing performance in dishwashers The rinse aid used in is obtained by using dishwashers is a special detergent, rinse aid and combination that aims to water softening salt increase drying efficiency individually. and prevent water or lime stains on the washed items. - Page 18 Preparation Adjusting the amount of rinse 4. If there are stains on tableware items after washing, level must be increased and if there is a blue When the product is off, press trace after wiping them by hand, it Time Delay and On/Off keys must be decreased.
-
Page 19: Items Not Suitable For Washing In The Dishwasher
Preparation Items not suitable for washing Placing the dishes into the in the dishwasher dishwasher • Never wash dishes soiled by You can use your dishwasher in the cigarette ash, candle remnants, optimum way with respect to energy polish, dyestuff, chemicals, etc. in consumption and washing and drying your dishwasher. - Page 20 Preparation Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Improper Loading Of Dishware /43 EN Dishwasher / User’s Manual...
-
Page 21: Silverware Basket Piece
Preparation Silverware basket piece Silverware basket (depends on model) (depends on model) You can place your forks, spoons and Silverware basket is designed to wash etc. to upper basket with the additional your dishes such as fork, spoon and piece in the figure.. etc. -
Page 22: Cutlery Basket
Preparation Cutlery basket Cutlery basket (depends on model) (depends on model) Cutlery basket is designed to wash Cutlery basket is designed to wash your dishes such as knife, fork, spoon, your dishes such as knife, fork, spoon, etc. in an efficient manner. etc. -
Page 23: Collapsible Lower Basket Wires (6 Pieces)
Preparation Collapsible lower basket wires Bringing the wires to (6 pieces) the horizontal position byholding them from the (depends on model) tips may cause them to The foldable wires (A) located at bend. Therefore, it will the lower basket of the machine are be appropriate to bring designed for an easier placement of the wires in the middle to... -
Page 24: Collapsible Lower Basket Wires (4 Pieces)
Preparation Collapsible lower basket wires Collapsible lower basket wires (4 pieces) (2 pieces) (depends on model) (depends on model) The four piece foldable wires located The two piece foldable wires located at the lower basket of the machine at the lower basket of the machine are are designed for an easier placement designed for an easier placement of of large pieces such as pans, bowls,... -
Page 25: Collapsible Lower Basket Tines
Preparation Collapsible lower basket tines (depends on model) There are foldable tines (A) located at the lower basket of the machine are designed for an easier placement of large pieces such as pans, bowls, etc. You can create larger spaces by folding each tines individually or all of them at once. -
Page 26: Collapsible Lower Basket Tines
Preparation Collapsible lower basket tines (depends on model) There are foldable tines (A) located at the lower basket of the machine are designed for an easier placement of large pieces such as pans, bowls, etc. You can create larger spaces by folding each tines individually or all of them at once. -
Page 27: Softtouch Accessory
Preparation SoftTouch Accessory Tray Wash Supports (depends on model) (depends on model) The SoftTouch Accessory found in the Use the supports to wash trays in the lower basket of your machine enables bottom basket. a safe washing for your fragile glasses. See the Auxiliary functions section for appropriate programme and function selection. -
Page 28: Lower Basket Multipurpose / Height Adjustable Service Rack
Preparation Lower basket multipurpose / Make sure that the impeller height adjustable service rack does not touch the dishes (depends on model) you placed on the racks. This accessory located at the lower To close the racks: basket of your machine allows you 1. -
Page 29: Upper Basket Height Adjustable Rack
Preparation Upper basket glass support Upper basket height piece adjustable rack (depends on the model) (depends on model) When placing long stemmed glasses or Use the lower and upper parts of the wine glasses, do not lean them against height adjustable racks in the upper other pieces but to the edge of the basket of the machine by sliding them basket or to the rack (1). -
Page 30: Upper Basket Glass Support Piece
Preparation Upper basket glass support Collapsable upper basket piece wires (depends on the model) (depends on the model) When placing long stemmed glasses or To bring the collapsable wires on the wine glasses, do not lean them against upper basket of the machine into other pieces but to the edge of the horizontal position, press on the latch basket or to the rack (1). -
Page 31: Collapsible Upper Basket Tines
Preparation Collapsible upper basket tines Collapsible upper basket tines (depends on model) (depends on model) There are foldable tines on the upper Upper basket of the machine is basket of the machine that you can lay equipped with tines with gradual folding down when you need larger space for system (A) that you can lay down big dishes. -
Page 32: Collapsible Upper Basket Wires
Preparation Collapsible upper basket Adjusting the height of the wires upper basket (depends on model) (depends on model) You can use collapsible wires when Basket adjustment mechanism on the you need a larger space for your loaded upper basket of the machine dishes in the upper basket of your is designed to allow you create taller machine. -
Page 33: Adjusting The Height Of Loaded Upper Basket
Preparation 2. Repeat the same process to lower the other side of the basket. 3. Make sure that both sides of the basket height adjustment mechanism are at the same level (down or up). Repeat the same process to lower the other side of the basket. -
Page 34: Height Setting With Empty Basket
Preparation Height setting with empty Adjusting the height of the basket upper basket (depends on model) (depends on model) In this model, the height setting of the The upper basket height adjustment upper basket may be changed using mechanism has been designed for the wheels which are mounted at two you to create large spaces in the lower different heights. -
Page 35: Upper Basket Multipurpose Service Rack
Preparation Upper basket multipurpose basket and simultaneously push and release the latches shown in service rack the figure (B). (depends on model) 2. Lower the basket from its current This accessory located at the upper position to the lower one. basket of your machine allows you to 3. -
Page 36: Ceiling Cutlery Basket
Preparation Ceiling cutlery basket (depends on model) Ceiling cutlery basket is designed to wash your cutlery items such as forks, spoons and etc. by placing them between the bars on the basket. When the central tray is in the lower position, you can load long/high items such as coffee cups, ladles, etc. -
Page 37: Upper Cutlery Basket
Preparation Upper cutlery basket (depends on model) The upper cutlery basket is designed for small dishes, or long items that cannot fit into the lower cutlery basket. After taking out the basket by lifting it up, remove the carrier part from the rails by pulling it towards yourself (C). -
Page 38: Maintenance And Cleaning
MAINTENANCE AND CLEANING Cleaning the filters Service life of the product extends and frequently faced problems decrease if Clean the filters at least once a week it is cleaned at regular intervals. in order for the machine operates Unplug the product and turn efficiently. -
Page 39: Cleaning The Hose Filter
Maintenance and cleaning Cleaning the hose filter Damages on the machine that may be caused by impurities coming from the urban supply water or your own water installation (such as sand, dirt, rust, etc.) can be prevented by means of the filter attached to the water inlet hose. -
Page 40: Cleaning The Impellers
Maintenance and cleaning Cleaning the impellers Upper impeller Clean the impellers at least once a Check if the holes on the upper week in order for the machine operates impeller (1) are clogged. If they efficiently. are clogged, remove and clean the impeller. -
Page 41: Troubleshooting
TROUBLESHOOTING Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •... - Page 42 Troubleshooting • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine. • Machine is unloaded right after the programme is over. >>> Do not unload your machine right after washing process is completed.
- Page 43 Troubleshooting • Salt leakage exists. >>> Pay attention not to spill salt around the salt filling hole while adding salt. Make sure that the salt reservoir lid is tightly closed after finishing the filling process. Run the prewash programme to remove the salt that spilled inside the machine.
- Page 44 Troubleshooting • Cutlery are made of low quality stainless steel. >>> Corrosion on such items is inevitable; they should not be washed in dishwashers. • Kitchen utensils that are already corroded are washed in dishwasher. >>> Rust on a corroded item can migrate to other stainless steel surfaces and cause corrosion on those surfaces as well.
- Page 45 Troubleshooting • Dishes are not placed orderly in the machine. >>> When placing the glasses and other glassware into the basket lean them not against other dishes but the edges or racks of the basket or the glass support tines. Striking of the glasses to each other or to other dishes due to the impact of water during washing can cause breaks, or scratches on their surfaces.
