Bulaşık Makinesi
Kullanma Kılavuzu
Dishwasher
User's Manual
6566 I
EN
Document Number :
1728767063_AD_ARCELIK_6566 I_EN/ 18-03-19.(11:36)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6566 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for arcelik 6566

Summary of Contents for arcelik 6566

  • Page 1 Bulaşık Makinesi Kullanma Kılavuzu Dishwasher User’s Manual 6566 I Document Number : 1728767063_AD_ARCELIK_6566 I_EN/ 18-03-19.(11:36)
  • Page 2 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
  • Page 3 Dishwasher User’s Manual 6566 I Document Number : Document Number : 1 728767063_AD_ARCELIK_6566 I_EN/ 18-03-19.(11:36)
  • Page 4 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.

  • Page 5: Table Of Contents

    CONTENTS 1 INSTRUCTIONS FOR SAFETY Collapsible lower basket tines ..26 Collapsible lower basket tines ..27 AND ENVIRONMENT Lower basket bottle wire ....27 General safety ........4 SoftTouch Accessory ......28 Intended use ........5 Lower Basket Glass Holder ....28 Children’s safety .........5 Tray Wash Supports ......28 Disposing of packaging material..5 Lower basket multipurpose / height Transportation of the product .....6...
  • Page 6 CONTENTS 5 OPERATING THE PRODUCT Keys..........41 Preparing the machine .....41 Programme selection......41 Auxiliary functions......44 Programming the washing time ..47 Starting the programme ....47 Programme step follow-up ....48 Child (Key) Lock .......49 Cancelling the programme ....49 Changing a programme ....49 Adjusting the amount of rinse aid ..50 Water Cut-off Indicator ( ) ....50 End of programme ......50...

  • Page 7: Instructions For Safety And Environment

    INSTRUCTIONS FOR SAFETY AND ENVIRONMENT This section contains safety onto it! There is the risk of instructions that will help to electric shock! get protected from risk of • Never touch the plug personal injury or property with wet hands! Never damage.

  • Page 8: Intended Use

    instructions for safety and environment Be careful for the rush of hazards involved. Children hot steam when you open shall not play with the the door. appliance. Cleaning and user maintenance shall Intended use not be made by children without supervision. •...

  • Page 9: Transportation Of The Product

    instructions for safety and environment Transportation of the collection center for the recycling of electrical and product electronic equipment. Please If you need to move consult your local authorities the product, do it to learn about these collection in upright position centers.

  • Page 10: Dishwasher Overview

    DISHWASHER Overview Upper basket Cutlery basket Lower basket Automatic Liquid/Gel Detergent and Rinse Aid Dosing System Type Label Control panel Door Lower impeller Salt reservoir lid 10. Filters 11. Upper impeller 12. Upper basket rail 13. Upper cutlery basket ( depends on model ) 14.

  • Page 11: Fan Drying System

    Data required for performance tests shall be provided upon request. Requests can be e-mailed to the following address: standard.test@arcelik.com Do not forget to provide the code, stock and serial numbers of the product to be tested in your request e-mail along with your contact information. Code, stock and serial numbers of the product may be found on the type label attached to the side wall of the door.

  • Page 12: Installation

    INSTALLATION Refer to the nearest Authorised When placing the product, pay Service Agent for installation of your attention not to damage the floor, walls, product. To make the product ready piping, etc. Do not hold the product by for use, make sure that the electricity, its door or panel to move it.

  • Page 13: Connecting Water Supply

    Installation Connecting water supply Use a screw-on hose connector to connect the We recommend attaching water inlet hose to a water a filter on the house/ tap with a ¾ inch external apartment supply water thread. If required, use a inlet to protect the machine filter insert to filter deposits from damages that may...

  • Page 14: Adjusting The Feet

    Installation the fuse or breaker in the house Drainpipe must be is less than 16 Amps, have a connected to the sewage qualified electrician install a 16 system and it should not be Amp fuse. connected to any surface • The specified voltage must be water.

  • Page 15: Preparation Tips For Energy Saving

    PREPARATION Tips for energy saving Adjusting the water softening system Following information will help you use the product in an ecological and Cleaning, rinsing and drying energy-efficient manner. performance of your dishwasher will Wipe away any coarse food remnants increase when water softening system on the dishes before putting them in is adjusted properly.
  • Page 16 PreparatIon After determining hardness level of the supply water: 1. Press and hold the settings key after switching on your machine. Settings menu is opened at the end of the 3, 2, 1 countdown on the display. 2. Go to the (r..) position on the display by pressing the programme key. 3.

  • Page 17: Detergent

    PreparatIon you use salt under this condition, salt 5. Replace the lid and tighten it when will not be consumed and the Salt the reservoir is full. indicator will not illuminate. You need to add salt right If you move your house, before starting the machine.

  • Page 18: Adding Liquid/Gel Detergent And Rinse Aid

    PreparatIon programme is adjusted automatically. In addition to liquid/gel detergents that function Please read the information only as a detergent, given in section “Operating there are also liquid/gel the Product” to activate or detergents that act as rinse deactivate the Automatic aid and/or soften water.
  • Page 19 PreparatIon After fully opening the door of the Using the Automatic Liquid/Gel dishwasher, open the decorative cover Detergent Dosing System as shown with arrows 1 and In order to use the Automatic Liquid/ Gel Detergent Dosing function, select Automatic Liquid/Gel Detergent Dosing function on the control panel.
  • Page 20 PreparatIon Liquid/gel detergents If a different brand or type of that lost their fluidity and liquid/gel detergent will be became firm must not be used, make sure previous used in automatic liquid/gel detergent is depleted detergent dosing system. completely and then remove and clean the liquid/gel Liquid/gel detergents must be used detergent tank under tap...

  • Page 21: Powder Detergents

    PreparatIon direction of the arrow (1) and lift to special-purpose washing chemicals remove (2). Once the cleaning or filling such as glass and stainless steel procedure is complete, follow the protectors. above steps in reverse order to re- Tablet detergents give install the detergent and rinse aid satisfying results only boxes.
  • Page 22 PreparatIon steel protectors in addition to Decorative prints of detergent, rinse aid and water chinaware as well as softening salt aluminum and silver items When using tablet may get discoloured or detergents, follow the tarnished after washing in manufacturer's instructions the dishwasher just as it on the packaging.
  • Page 23 PreparatIon To prevent possible injuries, always place the sharp and pointed dishes such as service fork, bread knife, etc. upside down so as their pointed ends will face down or they will lie horizontally in the dish basket. Unload dishes in the lower basket first and then the dishes in the upper basket.
  • Page 24 PreparatIon Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Improper Loading Of Dishware Dishwasher / User’s Manual 21 / 62 EN...

  • Page 25: Silverware Basket Piece

    PreparatIon Silverware basket piece Silverware basket (depends on model) (depends on model) You can place your forks, spoons and Silverware basket is designed to wash etc. to upper basket with the additional your dishes such as fork, spoon and piece in the figure.. etc.

  • Page 26: Cutlery Basket

    PreparatIon Cutlery basket Cutlery basket (depends on model) (depends on model) Cutlery basket is designed to wash Cutlery basket is designed to wash your dishes such as knife, fork, spoon, your dishes such as knife, fork, spoon, etc. in an efficient manner. etc.

  • Page 27: Collapsible Lower Basket Wires (6 Pieces)

    PreparatIon Collapsible lower basket wires Bringing the wires to (6 pieces) the horizontal position byholding them from the (depends on model) tips may cause them to The foldable wires (A) located at bend. Therefore, it will the lower basket of the machine are be appropriate to bring designed for an easier placement of the wires in the middle to...

  • Page 28: Collapsible Lower Basket Wires (4 Pieces)

    PreparatIon Collapsible lower basket wires Collapsible lower basket wires (4 pieces) (2 pieces) (depends on model) (depends on model) The four piece foldable wires located The two piece foldable wires located at the lower basket of the machine at the lower basket of the machine are are designed for an easier placement designed for an easier placement of of large pieces such as pans, bowls,...

  • Page 29: Collapsible Lower Basket Tines

    PreparatIon Collapsible lower basket tines (depends on model) There are foldable tines (A) located at the lower basket of the machine are designed for an easier placement of large pieces such as pans, bowls, etc. You can create larger spaces by folding each tines individually or all of them at once.

  • Page 30: Collapsible Lower Basket Tines

    PreparatIon Collapsible lower basket tines (depends on model) There are foldable tines (A) located at the lower basket of the machine are designed for an easier placement of large pieces such as pans, bowls, etc. You can create larger spaces by folding each tines individually or all of them at once.

  • Page 31: Softtouch Accessory

    PreparatIon SoftTouch Accessory Tray Wash Supports (depends on model) (depends on model) The SoftTouch Accessory found in the Use the supports to wash trays in the lower basket of your machine enables bottom basket. a safe washing for your fragile glasses. See the Auxiliary functions section for appropriate programme and function selection.

  • Page 32: Lower Basket Multipurpose / Height Adjustable Service Rack

    PreparatIon Lower basket multipurpose / Make sure that the impeller height adjustable service rack does not touch the dishes (depends on model) you placed on the racks. This accessory located at the lower To close the racks: basket of your machine allows you 1.

  • Page 33: Upper Basket Multipurpose Service Rack

    PreparatIon Upper basket multipurpose multipurpose service rack again, you service rack can easily attach it to the side section of your upper basket. (depends on model) This accessory located at the upper basket of your machine allows you to easily wash pieces such as extra long ladles and bread knives.

  • Page 34: Upper Basket Height Adjustable Rack

    PreparatIon Upper basket height Upper basket glass support adjustable rack piece (depends on model) (depends on the model) Use the lower and upper parts of the When placing long stemmed glasses or height adjustable racks in the upper wine glasses, do not lean them against basket of the machine by sliding them other pieces but to the edge of the down or up according to the heights of...

  • Page 35: Upper Basket Glass Support Piece

    PreparatIon Upper basket glass support Collapsable upper basket piece wires (depends on the model) (depends on the model) When placing long stemmed glasses or To bring the collapsable wires on the wine glasses, do not lean them against upper basket of the machine into other pieces but to the edge of the horizontal position, press on the latch basket or to the rack (1).

  • Page 36: Collapsible Upper Basket Tines

    PreparatIon Collapsible upper basket tines Collapsible upper basket tines (depends on model) (depends on model) There are foldable tines on the upper Upper basket of the machine is basket of the machine that you can lay equipped with tines with gradual folding down when you need larger space for system (A) that you can lay down big dishes.

  • Page 37: Collapsible Upper Basket Wires

    PreparatIon Collapsible upper basket Adjusting the height of the wires upper basket (depends on model) (depends on model) You can use collapsible wires when Basket adjustment mechanism on the you need a larger space for your loaded upper basket of the machine dishes in the upper basket of your is designed to allow you create taller machine.

  • Page 38: Adjusting The Height Of Loaded Upper Basket

    PreparatIon To lower the basket: 1. Press the latch on the basket adjustment mechanism (right or left) to lower the basket (B). 2. Repeat the same process to lower the other side of the basket. 3. Make sure that both sides of the basket height adjustment mechanism are at the same level (down or up).

  • Page 39: Adjusting The Height Of The Upper Basket

    PreparatIon Adjusting the height of the To lower the basket, while it is in the uppermost position; upper basket 1. Hold the upper basket wires with (depends on model) both hands, slightly lift up the The upper basket height adjustment basket and simultaneously push mechanism has been designed for and release the latches shown in...

  • Page 40: Height Setting With Empty Basket

    PreparatIon Height setting with empty Ceiling cutlery basket basket (depends on model) Ceiling cutlery basket is designed (depends on model) to wash your cutlery items such as In this model, the height setting of the forks, spoons and etc. by placing them upper basket may be changed using between the bars on the basket.

  • Page 41: Ceiling Cutlery Basket

    PreparatIon Ceiling cutlery basket (depends on model) Ceiling cutlery basket is designed to wash your cutlery items such as forks, spoons and etc. by placing them between the bars on the basket. When the central tray is in the lower position, you can load long/high items such as coffee cups, ladles, etc.

  • Page 42: Upper Cutlery Basket

    PreparatIon Upper cutlery basket (depends on model) The upper cutlery basket is designed for small dishes, or long items that cannot fit into the lower cutlery basket. After taking out the basket by lifting it up, remove the carrier part from the rails by pulling it towards yourself (C).

  • Page 43: Operating The Product

    OPERATING THE PRODUCT 1. On/Off key 2. Programme Selection keys 3. Function keys RemoteStart Key Fast+ Function c) Child lock / Extra Drying Function d) Settings Menu / TrayMaster Function 4. Time Delay key 5. Start/Pause/Cancel key 6. Display 7. Programme indicator 8.

  • Page 44: Keys

    Operating the product Keys Same function keys are used for Child (Key) Lock and On/Off key Volume Setting. It is used to switch on or off the machine. Time Delay key Press the On/Off key for 1 second to It should be pressed to make the time switch on.
  • Page 45 Operating the product /62 EN Dishwasher / User’s Manual...
  • Page 46 Operating the product . You can download the programs in the table instead of the downloaded program. . At the factory, the program shown as (*) is set as Downloaded Program. Programme Table Programme number Prewash Hygiene+ Delicate Mix Wash+ Programme name (Ön Ykama) (Ekstra Hijyen)

  • Page 47: Auxiliary Functions

    Operating the product Auxiliary functions Fast+ Function It shortens the time of the washing Washing programmes of your cycle selected and decreases water dishwasher are designed to obtain the consumption by enabling washing best cleaning effect, considering the under higher pressure. type of the soiling, soiling degree and Extra Drying Function properties of the dishes to be washed.
  • Page 48 Operating the product Functions Under the Settings Menu Automatic Liquid/Gel Detergent (depends on the model) function Off/On Under the settings menu of your product, there are some additional functions that depend on the model. Press and hold the Menu key for 3 seconds to access these functions.
  • Page 49 Operating the product Changing Warning Sound Volume Automatic Detergent Dosing function Automatic Detergent Dosing Your machine is equipped with an Function audio signal to inform warnings audibly. The Automatic Detergent Dosing 1. After switching your machine on, function automatically adjusts the press the settings key until the liquid/gel detergent use according to countdown 3, 2, 1 is completed on...

  • Page 50: Programming The Washing Time

    Operating the product Programming the washing Programme and auxiliary time functions cannot be set/changed after the Time Delay programme has started. If an economical electricity tariff is applied in your region, you can use the To cancel the time delay function time delay function to wash your dishes 1.

  • Page 51: Programme Step Follow-Up

    Operating the product Programme step follow-up Your machine performs water softening depending You can follow-up the washing step on the hardness level of the in which the current programme is in mains water. Remaining from the Programme Steps Follow-up time displayed towards the indicator on the display.

  • Page 52: Child (Key) Lock

    Operating the product Child (Key) Lock You can select and operate a new programme after You can prevent other people from the cancellation of the affecting and changing the programme programme. flow and time delay while the machine is running. There might be residues of To activate the child lock: detergent or rinse aid left...

  • Page 53: Adjusting The Amount Of Rinse Aid

    Operating the product Water Cut-off Indicator ( Adjusting the water hardness level is explained in Water 1 Water Cut-off warning indicator will Softening System section. light when the machine cannot take in water. When the water is supplied Rinse aid indicator ( ) again, warning light will be turned off Please check the no rinse aid indicator automatically.

  • Page 54: Homewhiz Function

    HOMEWHIZ FUNCTION You can check your dishwasher and internet to use the application. learn about its status via your smart If you are using the application for the device with the HomeWhiz function. first time, complete the registration process with your e-mail address on HomeWhiz only runs on a the application.
  • Page 55 HomeWhiz Function 7. While the dishwasher is connecting If the account you have to the selected network, you logged on is the one to will see the Wireless icon ( which you have added flashing. Once the connection has appliance(s) before, you can been established, the said icon will start using your dishwasher become on permanently.
  • Page 56 HomeWhiz Function Wireless connection on/off You can tap "Add/Remove While your machine is on, press the Appliance" under the “Settings” key for 3 second to enter "Appliances" section to the settings menu. Follow the screen see the appliances paired and press program selection keys on with your account.
  • Page 57 HomeWhiz Function 4. Check the wireless connection • While the program is being status of your dishwasher. If downloaded, you will see an you see "WLAN: Off", switch it animation on the program and to "WLAN: On" and wait for the HomeWhiz application.

  • Page 58: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Cleaning the filters Service life of the product extends and frequently faced problems decrease if Clean the filters at least once a week it is cleaned at regular intervals. in order for the machine operates Unplug the product and turn efficiently.

  • Page 59: Cleaning The Hose Filter

    HomeWhiz Function Cleaning the hose filter Damages on the machine that may be caused by impurities coming from the urban supply water or your own water installation (such as sand, dirt, rust, etc.) can be prevented by means of the filter attached to the water inlet hose.

  • Page 60: Upper Impeller

    HomeWhiz Function Cleaning the impellers Upper impeller Clean the impellers for the machine to Check if the holes on the upper work efficiently. impeller (1) are clogged. If they are clogged, remove and clean the impeller. Turn its nut to left to remove the upper impeller.

  • Page 61: Troubleshooting

    TROUBLESHOOTING Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •...
  • Page 62 Troubleshooting • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine. • Machine is unloaded right after the programme is over. >>> Do not unload your machine right after washing process is completed.
  • Page 63 Troubleshooting • Salt leakage exists. >>> Pay attention not to spill salt around the salt filling hole while adding salt. Make sure that the salt reservoir lid is tightly closed after finishing the filling process. Run the prewash programme to remove the salt that spilled inside the machine.
  • Page 64 Troubleshooting • Cutlery are made of low quality stainless steel. >>> Corrosion on such items is inevitable; they should not be washed in dishwashers. • Kitchen utensils that are already corroded are washed in dishwasher. >>> Rust on a corroded item can migrate to other stainless steel surfaces and cause corrosion on those surfaces as well.
  • Page 65 Troubleshooting • Dishes are not placed orderly in the machine. >>> When placing the glasses and other glassware into the basket lean them not against other dishes but the edges or racks of the basket or the glass support tines. Striking of the glasses to each other or to other dishes due to the impact of water during washing can cause breaks, or scratches on their surfaces.
