6 Menu scheme in PX277................17 7 Connection scheme.................18 8 Dimensions....................19 9 Technical data..................20 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-3 BDO register number 000005972 www.pxm.pl...
Description The PX385 module is used to process DMX-512 signal to analogue control 1 – 10V or 1 – 10V with a relay (Relay Mode). The DMX/0-10 Interface 1ch has a DMX connector and 1 output voltage channel. PX385 can be controlled using a DMX signal (the device has a built-in DMX-512 signal receiver), and it can operate independently.
Safety conditions The PX385 is a device powered directly from power grid 230V, what may result in electric shock in case of not following safety rules. During its installation and use the following rules must be strictly observed: 1. The device should be installed as described in the manual. 2.
Connectors and control elements LED indicator 230V AC input analogue output DMX IN DMX OUT 230V AC output switched by a relay PX277 programmer connector DIP switch...
DIP switch – principle of operation : ON position 9 10 OFF position NOTE! When the device receives a DMX signal, the diode blinks every ~1s, if there is no DMX signal, it blinks every ~3s. DMX signal connecting PX385 have to be connected to DMX line in serial mode, with no branches on DMX control cable.
Device configuration 5.1 Configuration using a DIP switch 1. Set the tenth DIP switch up (to the ON position) to enter the operating mode setup and no signal. ON position 1 2 3 4 5 6 7 8 9 10 2.
3. Set the ninth DIP switch to OFF when you want the driver to work in the 0 – 10V mode or ON for the 1 – 10V (Relay). 4. Save your settings by switching the tenth DIP switch to OFF which will take you to the addressing mode.
NOTE! To change PX385 setting using the PxArt+ Settings Controller, set all DIP switches to OFF. 5.2.1 Description of information parameters Px277 controller allows to read important information concerning lamp to which it has been connected. They are: model, control time, total device operation time, serial number and version of the installed software.
5.2.2 Brightness address PX277 allows for changing the DMX address which controls the output of the converter. DMX channel can be set between 1 to 512. To change the DMX channel (responsible for output control), select the [Bright. address] in the PX277 menu, confirm Model PX385 0-10V NEXT...
5.2.3 Scene brightness The device can work without DMX control. In such case, the PxArt+ Settings Controller enables the value of the scene brightness. This value can be set in the range from 0 up to 255. [Scene bright.] set to value 0 turns off the stage and turns the value 255 to Model Scene bright.
5.2.4 Output modes The PX385 device can operate in two output modes: • 0 – 10V 1 – 10V – Relay mode • Using the PX277 configurator enter the submenu [Out mode] and using Model the next and previous buttons select the PX385 0-10V 3 x NEXT output mode according to the wiring...
Page 13
Below is a graph describing the operation of the 1 – 10V + Relay mode. 1 - 10V controll Relay A DMX value of 0 corresponds to a voltage of 1V, with a DMX value of 25 starting to increase linearly to a value of 255. Relay switch is turned on by hysteresis, with DMX value 7 (and more), while DMX 3 value (or less) turns Relay off.
5.2.5 Restore default settings The device comes with the option to restore default settings. To use this option, select the [Default sett.] menu and press enter. A window informing about the need to press previous and next buttons will appear for 2 seconds simultaneously. Next, the device will display [Reset OK], displaying this message means that the factory settings have been Model restored.
5.3 RDM – description of available parameters PX385 supports the DMX-RDM protocol. DMX protocol in its assumption enables one-way data flow while its extension, the RDM protocol, can transmit information in two ways. This makes the simultaneously receiving and sending of information possible and allows for monitoring the operation of devices compatible with the RDM protocol as well as possibly changing the configuration of their parameters.
Page 16
Parameter name Description DMX_PERSONALITY_ description of individual operation 0x00E1 DESCRIPTION modes information concerning the working DEVICE_HOURS 0x00E0 time of the device counted in hours information concerning lamp LAMP_HOURS 0x00E1 lighting time device identification; two states are possible: IDENTIFY_DEVICE * 0x1000 identification is off (value 0x00) and identification is on (value 0x01) brightness settings;...
Menu scheme in PX277 Standard version L0 version Model PX385L0 PX385 0-10V PX385L0 0-10V NEXT NEXT ENTER ENTER Bright. address Bright. address DMX Start Addr. DMX Start Addr. 001 * 001 * NEXT NEXT NEXT NEXT Bright. address Scene bright. DMX Start Addr.
Technical data PX385 type PX385-L0 power supply 230V AC number of output channels 0 – 10V output load capacity max. 10mA resistive load max. 2A, 250V AC relay output load capacity inductive load max 0.5A, 250V AC output sockets screw terminals weight 0.2kg...
Page 21
Podłęże, 22.11.2021 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: DMX/0-10 Interface 1ch Product code: PX385 PX385-L0 meets the requirements of the following standards, as well as harmonised standards:...
