Page 1
Assembly and Operating Instructions Hand-held transmitter for wind control Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. 4033 630 277 0 14/07/2022 Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4 35764 Sinn/Germany www.becker-antriebe.com...
General With this transmitter you are able to control one or more sun protection sys- tems, and set the threshold value for wind monitoring with the setting tool in- cluded. This device is exceptionally easy to use. Please observe these Assembly and Operating Instructions when installing and setting up the equipment.
Safety instructions General information • Please keep the instruction manual safe! • Only use in dry rooms. • Only use unmodified original parts from the control unit manufacturer. • Keep children away from control units. • Observe all pertinent country-specific regulations. •...
Intended use The transmitter described in these instructions must only be used indoors for the operation of Centronic-compatible radio drives and radio control units for sun protection systems. Attention A safety-relevant function has been provided for the threshold controller. Setting the threshold value wrongly can cause damage to the sun protection system.
Explanation of functions Channel The channel of a transmitter can be programmed into one or more receivers. One receiver is operated through an individual command, several receivers through a group command. Channel indicator lamp A radio signal is indicated by the channel indicator lamp lighting up. When the battery starts to lose power, the channel indicator lamp flashes when transmit- ting.
Wind threshold regulator (in connection with a suitable sensor from the controller manufacturer) You set the wind threshold value with this regulator (between about 2 m/s and 22 m/s). The wind threshold value can be adjusted in 11 steps. When slowly turning the regulator, the tubular drive clicks to indicate the setting changes.
Programming the transmitter Caution Before programming the transmitter, check that the threshold controller is as set at the factory. Make sure when programming the transmitter that you are not in the travel re- gion of the sun protection system. 1) Programming the master transmitter a) Readying the receiver for programming The master transmitter refers to the very first transmitter programmed in a receiver.
Installing the wall bracket • Before installation in the de- sired installation position, Wall bracket check that the transmitter and receiver are functioning prop- erly. Wall bracket Unlocking mechanism mounting • Fix the bracket to the wall with plate the two screws enclosed. Changing batteries You will find the appropriate battery type in the "Technical data"...
Technical data Rated voltage 3 V DC Battery type CR 2430 Degree of protection IP 20 Permissible ambient temperature -10 °C to +55 °C Maximum emitted transmission output ≤ 3 mW Radio frequency 915.3 MHz The maximum transmitter range on and in the building is up to 15 m, and up to 150 m in the open.
