Summary of Contents for Tulsa 354IRL
- Page 1 Operating and Maintenance Manual Planetary Winch MUST This manual be kept with the winch at all times. New MUST winch operators read and understand the contents fully. Sel-0010(FOR PDF).doc REV-1...
- Page 2 Winch operators must be trained in the proper, safe operation of the winch. • Cable anchors on Tulsa Winches are not designed to hold the rated load of the winch. You must keep at least five (5) wraps of cable on the drum to insure that the cable doesn’t come loose.
- Page 3 Because of the large number of models we manufacture, we are unable to show parts lists for every model in this booklet. If you want or need parts lists, please write Tulsa Winch, 11135 S. James, Jenks, OK 74037. Or call (918) 298- 8300 or fax us at (918) 298-8367.
- Page 4 2. Tulsa Winch products are not to be used to lift, hoist, or move people. If your application requires moving persons, you must use the proper equipment for the task.
- Page 5 THEORY OF OPERATION 1. The Tulsa Planetary Winches are composed of an input from either a high torque, low speed geroler motor or a high- speed gear or piston motor. Input drives through a multiple disc brake that is spring applied and hydraulically released, and then through planet gear sets to the cable drum.
- Page 6 Buy now Tulsa Winch 354IRL Operator Manual PDF With Instant Download...
