- Page 1 Operating and Maintenance Manual Planetary Winch MUST This manual be kept with the winch at all times. New MUST winch operators read and understand the contents fully. Sel-0010(FOR PDF).doc REV-1 Sel-0010.doc REV-1...
- Page 2 Winch operators must be trained in the proper, safe operation of the winch. • Cable anchors on Tulsa Winches are not designed to hold the rated load of the winch. You must keep at least five (5) wraps of cable on the drum to insure that the cable doesn’t come loose.
-
Page 3: Table Of Contents
Because of the large number of models we manufacture, we are unable to show parts lists for every model in this booklet. If you want or need parts lists, please write Tulsa Winch, 11135 S. James, Jenks, OK 74037. Or call (918) 298- 8300 or fax us at (918) 298-8367. -
Page 4: General Operation
2. Tulsa Winch products are not to be used to lift, hoist, or move people. If your application requires moving persons, you must use the proper equipment for the task. -
Page 5: Theory Of Operation
THEORY OF OPERATION 1. The Tulsa Planetary Winches are composed of an input from either a high torque, low speed geroler motor or a high- speed gear or piston motor. Input drives through a multiple disc brake that is spring applied and hydraulically released, and then through planet gear sets to the cable drum. -
Page 6: Cable Considerations
707W 1/2” specific application. 1200W 9/16” 1500W 5/8” WARNING: CABLE ANCHORS ON TULSA WINCHES ARE 3541RL 3/4” NOT DESIGNED TO HOLD RN45P 3/4” THE RATED LOAD OF THE RN60P 7/8” WINCH. YOU MUST KEEP AT LEAST 5 WRAPS OF CABLE RN80P 1”... -
Page 7: The Importance Of A Proper Fleet Angle
THE IMPORTANCE OF A PROPER FLEET ANGLE Maintaining the proper fleet angle is important to the success of your winching operation, the life of your winch and the life of the cable you are using. The fleet angle can best be described by the following illustration. -
Page 8: Cable Installation
WARNING: CABLE ANCHORS ON TULSA WINCHES ARE NOT DESIGNED TO HOLD THE RATED LOAD OF THE WINCH. YOU MUST KEEP AT LEAST 5 WRAPS OF CABLE ON THE DRUM TO INSURE THAT THE CABLE DOESN’T... -
Page 9: Winch Mounting
If the winch being mounted is hydraulically driven, make sure the system is clean and that all components function properly, especially the relief valve. Model No. of Size Capscrews Capscrews 506W 707W (USE MOUNTING HOLES PROVIDED IN BASE OF WINCH) 1200W 1500W 3541RL 3/4" RN45P 7/8"... -
Page 10: General Maintenance & Lubrication
WINCH MAINTENANCE A winch, like any other type of machinery, needs periodic maintenance and inspection to maintain its performance capabilities, give lasting value, and insure safe mechanical workings. Good maintenance consists of three steps. 1. A daily inspection to insure that there are no oil leaks present, that all mounting bolts and other fasteners are tight, and that wire rope is in good condition. - Page 11 Tulsa planetary winches are shipped from factory with SAE 90 EP gear lube in the gearbox and SAE 20-20W motor oil in the brake section. This oil should be satisfactory for operation in ambient temperatures from -10° F to +110° F. If your work calls for operation in temperatures outside this range, contact Tulsa Winch for recommendations.
-
Page 12: Brake System
BRAKE SYSTEM The winch braking system is a multiple disc, spring applied hydraulically released setup that is activated via the port in the brake housing. During pay-in the brake is not released but bypassed through the one-way cam clutch. When the load comes to a stop, the cam clutch locks up and the load is prevented from slipping by the brake. -
Page 13: Model Codes
WINCH MODEL CODES (After 01-01-03) RN100 P H L X O A 1 Basic Model Gear Type W=Worm P=Planetary Drive Type H=Hydraulic M=Mechanical Gearbox Position L=Left R=Right (viewed from rear of truck) Input Shaft Location F=Front R=Rear X=Does not apply (viewed from rear of truck) Cable Spooling O=Over Drum... - Page 14 WINCH MODEL CODES (PRIOR TO 01-01-03) RN100 L O 2 1 Basic Model Gearbox Position L=Left R=Right (viewed from rear of truck) Cable Spooling O=Over Drum U=Under Drum (viewed from rear of truck) Motor Type 1=Single Speed Gear Motor 2=Two Speed Gear Motor 3=Single Speed Geroler Motor 5=Piston Motor 6=Vane...
- Page 15 ALL Tulsa Winches have the serial number, and assembly number stamped on the housing or side plate. Please take a few minutes to record these numbers for future use. The assembly number will be required when ordering parts. MODEL: SERIAL NO:...
- Page 16 Tulsa Winch Limited Warranty Effective 8/1/2008 UPERSEDES ALL PRIOR WARRANTIES Seller warrants that each article (whether Gear Drive Products, Brake Products and/or Winch Products, all of which are covered hereunder) sold under this order shall at the time of shipment (i) conform to applicable specifications, and (ii) be free from defects in material and workmanship during normal and ordinary use and service (the "W arranty").
