Model Number
070A100
Performance
Cable Style
Number of Conductors
Connector Model(sensor side)
Connector Style(sensor side)
Connection Type(sensor side)
Coupling Method(sensor side)
Connector Style(termination)
Connection Type(termination)
Coupling Method(termination)
Physical
Size (Length x Height x Width)(termination)
Cable Jacket Diameter
Cable Jacket Material
Cable Jacket Color
Weight
Size (Length)(Cable Assembly)
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
Aufgrund laufender Weiterentwicklungen sind Änderungen der Spezifikationen vorbehalten. Alle Angaben vorbehaltlich Satz- und Druckfehler.
nbn Austria GmbH
Riesstraße 146, 8010 Graz
686 SERIES USB PROGRAMMER
ENGLISH SI
Multi Conductor - Shielded Multi Conductor - Shielded
2 2
AE AE
MIL-C-5015 MIL-C-5015
2-socket 2-socket
Push-on Push-on
USB 2.0 - 5VDC USB 2.0 - 5VDC
USB Series A USB Series A
Push-on Push-on
2.0 in x 0.5 in x 1.0 in 50.8 mm x 12.7 mm x 25.4 mm
0.16 in 4.1 mm
Polyurethane Polyurethane
Black Black
0.15 lb 70 g
3 ft 0.91 m
Tel. +43 316 40 28 05 | Fax +43 316 40 25 06
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
Entered: LK Engineer: gs Sales: MC
Date: 1/24/2017 Date: 1/24/2017 Date: 1/24/2017
IMI Sensors
3425 Walden
Depew, NY 14043
UNITED STATES
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
Web site: http://www.imi-sensors.com
Revision: NR
ECN #: 46328
Approved: BAM Spec Number:
66334
Date: 1/24/2017
