Model Number
686C01
Performance
Alarm Threshold(± 10 %)
Frequency Range(± 3 dB)
Hysteresis(% < Alarm Threshold)
Residual Vibration Level(Reference)
Residual Vibration
Level(% Alarm
Threshold)
MAVT(Sets Alarm Threshold to 2X actual
vibration)
Transverse Sensitivity
Power On Delay(± 1 sec)
Startup Delay(± 1 sec or 1 min)(Time)
Startup
Delay(x Alarm Threshold)
Startup
Delay(Active)
Operational Delay(± 1 sec)
Relay(Type)
Relay(Latching)
Relay(Contacts)
Environmental
Temperature Range(Operating)
Temperature
Range(Storage)
Overload Limit(Shock)
Enclosure Rating
Electrical
Power Required
24 to 240 V DC/AC 50/60 Hz 24 to 240 V DC/AC 50/60 Hz
Current Rating(Relay Closed)
Leak Current(Relay Open)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight
Mounting Torque
Mounting Thread
Sensing Element(Internal)
Piezoelectric Accelerometer Piezoelectric Accelerometer
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
[2]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
Aufgrund laufender Weiterentwicklungen sind Änderungen der Spezifikationen vorbehalten. Alle Angaben vorbehaltlich Satz- und Druckfehler.
nbn Austria GmbH
Riesstraße 146, 8010 Graz
VIBRATION SWITCH
EN GLISH
SI
0.25 to 5 in/sec pk
4.5 to 90 mm/s rms
120 to 60 kcpm
2 to 1,000 Hz
3; 6; or 10 %
3; 6; or 10 %
Dependent or Independent
Dependent or Independent [1]
1 to 40 %
1 to 40 %
Enabled or Disabled
Enabled or Disabled
< 7 %
< 7 %
3 or 20 sec
3 or 20 sec
1 to 60 sec or 1 to 30 min
1 to 60 sec or 1 to 30 min [1]
x2; x4; x8; Blocked
x2; x4; x8; Blocked
Enabled or Disabled
Enabled or Disabled
1 to 60 sec
1 to 60 sec
SPST, Form A or B MOSFET
SPST, Form A or B MOSFET
Latching / Non-Latching
Latching / Non-Latching [1]
Normally Open / Closed
Normally Open / Closed [1]
-40 to 185 °F
-40 to 85 °C
-40 to 257 °F
-40 to 125 °C
5,000 g pk
49,050 m/s² pk
IP68
IP68
500 mA
500 mA
≤ 1 mA
≤ 1 mA
8
8
> 10
Ohm
> 10
Ohm
1.25 in x 2.6 in
1.25 in x 66 mm
5.2 oz
148 gm
3 to 5 ft-lb
4 to 7 Nm
1/4-28 Female
1/4-28 Female
Stainless Steel
Stainless Steel
Welded Hermetic
Welded Hermetic
2-Pin MIL-C-5015
2-Pin MIL-C-5015
Top
Top
Tel. +43 316 40 28 05 | Fax +43 316 40 25 06
Optional versions have identical specifications and accessories as listed for the standard model except
[1]
where noted below. More than one option may be used.
[1]
- Hazardous Area Approval- contact factory for
EX
specific approvals
[1]
- Metric Mount
M
Supplied Accessory: Model M081A61 Mounting Stud 1/4-28 to M6 X 1 (1)
[1]
[1]
[1]
[1]
[1]
N OTES:
[1]USB Programmable - See configuration sheet supplied with switch for exact setting.
[2]See PCB Declaration of Conformance PS096 for details.
SUPPLIED ACCESSORIES:
Model 081A41 Mounting stud 1/4-28 socket head set screw brass tip stainless steel 5/8" long (1)
Model M081A61 Mounting Stud 1/4-28 to M6 X 1 (1)
Entered: ND
Engineer: gs
Date: 07/28/2023 Date: 07/28/2023 Date: 07/28/2023 Date: 07/28/2023 55110
3425 Walden Avenue, Depew, NY 14043
Revision: B
ECN #: 50106
OPTION AL VERSION S
Sales: JL
Approved: BAM
Spec Number:
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
nbn@nbn.at | www.nbn.at
