- Page 1 S IMP HOME ® REDMOND / MANSFIELD / STANWICK TALL TV MEDIA STAND MODEL # AXCRED17-BL 1/19...
- Page 2 S IMP HOME ® Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –4 pm EST or go to www.simpli-home.com/parts request In order to assist you in a timely manner, please have the following...
- Page 3 IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product.
-
Page 4: Care And Maintenance
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. - Page 5 PRE-ASSEMBLY INFORMATION MODEL # AXCRED17-BL PART DESCRIPTION LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF LEFT DIVIDER RIGHT DIVIDER QTY 1 QTY 1 QTY 1 Warning Label DOOR (L&R Same) TOP BACK PANEL CABINET SHELF QTY 2 QTY 2 QTY 1 NEED HELP? For help with assembly or if you are missing a part,...
-
Page 6: Pre-Assembly Information
PRE-ASSEMBLY INFORMATION MODEL # AXCRED17-BL PART DESCRIPTION BOTTOM BACK PANEL TOP SHELF DRAWER FRONT QTY 1 QTY 1 QTY 2 LEFT DRAWER SIDE RIGHT DRAWER SIDE DRAWER BACK QTY 2 QTY 2 QTY 2 DRAWER BOTTOM MIDDLE SHELF QTY 2 QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext. - Page 7 PRE-ASSEMBLY INFORMATION MODEL # AXCRED17-BL HARDWARE DESCRIPTION ALLEN KEY SCREW M6 X 30mm ALLEN KEY SHELF SUPPORT QTY 26 QTY 1 QTY 12 PHILLIPS SCREW PHILLIPS SCREW PHILLIPS SCREW ROUND HEAD M3 X 12mm M3 X 15mm M4 X 15mm QTY 12 QTY 8 QTY 25...
- Page 8 COMPONENTS-KEY DIAGRAM MODEL # AXCRED17-BL 8/19...
- Page 9 ASSEMBLY MODEL # AXCRED17-BL STEP-1 1. Attach four Cam Lock Pins 9 to back of Drawer Front I . 2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides JL , JR . 3. Insert two Cam Locks 9 into pre-drilled holes on each Drawer Side JL , JR . 4.
- Page 10 ASSEMBLY MODEL # AXCRED17-BL STEP-3 1. Align Drawer Back K with Drawer Bottom L and press firmly into slot. 2. Attach Drawer Back K using two Allen Key Screws 1 through pre-drilled holes on each Side JL , JR . 3.
- Page 11 ASSEMBLY MODEL # AXCRED17-BL STEP-5 1. Attach three Cam Lock Pins 9 to back of each Divider DL , DR . 2. Align Cam Lock Pins with pre-drilled holes and attach Middle Shelf M . 3. Insert six Cam Locks 9 into pre-drilled holes on Middle Shelf M . 4.
- Page 12 ASSEMBLY MODEL # AXCRED17-BL STEP-6 1. Attach six Cam Lock Pins 9 to underneath of Top Shelf H . 2. Align Cam Lock Pins with pre-drilled holes and attach Dividers DL , DR . 3. Insert three Cam Locks 9 into pre-drilled holes on each Divider DL , DR . 4.
- Page 13 ASSEMBLY MODEL # AXCRED17-BL STEP-7 1. Attach three Cam Lock Pins 9 to back of each Side AL , AR . 2. Align Cam Lock Pins with pre-drilled holes and attach Top Shelf H . 3. Insert six Cam Locks 9 into pre-drilled holes on Top Shelf H . 4.
- Page 14 ASSEMBLY MODEL # AXCRED17-BL STEP-8 1. Attach Top B to Sides AL , AR using six Allen Key Screws 1 . (three screws on each Side). 2. Use Allen Key 2 to tighten Screws. Do not over-tighten. STEP-9 NOTE: The screwdriver is not included in the hardware pack.
- Page 15 ASSEMBLY MODEL # AXCRED17-BL STEP-10 NOTE: The screwdriver is not included in the hardware pack. 1. Attach hinges on Doors E to Sides AL , AR using Phillips Screws 4 into guide holes. 2. Attach Magnet Plates 7 to bottom corner of Doors E using Phillips Screws 5 into guide holes on Doors E .
- Page 16 ASSEMBLY MODEL # AXCRED17-BL STEP-11 1. Use four Shelf Supports 3 for each Cabinet Shelf F in desired location. 2. Two Shelf Supports 3 may be used on back top of each Cabinet Shelf F as a tipping restraint. 3. Insert assembled drawers into glides on assembled TV stand. 16/19...
- Page 17 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. STEP-12 NOTE: The screwdriver is not included in the hardware pack.
- Page 18 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
-
Page 19: Warranty
S IMP HOME ® WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase. This warranty does not affect your statutory rights.
