- Page 1 SIMP HOME ® L I F E B Y D E S I G N BURLINGTON / PORTLAND / BERKSHIRE TALL TV MEDIA STAND MODEL # AXCBUR17-LGB 1/21...
- Page 2 SIMP HOME ® L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...
-
Page 3: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 4: Care And Maintenance
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. -
Page 5: Pre-Assembly Information
PRE-ASSEMBLY INFORMATION MODEL # AXCBUR17-LGB PARTS DESCRIPTION LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF LEFT DIVIDER RIGHT DIVIDER QTY 1 QTY 1 QTY 1 CENTRE SHELF CABINET SHELF CABINET SHELF QTY 1 QTY 1 QTY 4 LEFT BACK PANEL BACK PANEL BACK PANEL... - Page 6 PRE-ASSEMBLY INFORMATION MODEL # AXCBUR17-LGB PARTS DESCRIPTION Warning Label RIGHT BACK PANEL LEFT DOOR RIGHT DOOR QTY 1 QTY 1 QTY 1 LEFT DRAWER SIDE RIGHT DRAWER SIDE DRAWER FRONT QTY 2 QTY 2 QTY 2 BOTTOM SUPPORT LEG DRAWER BOTTOM DRAWER BACK QTY 1 QTY 2...
-
Page 7: Hardware Description
PRE-ASSEMBLY INFORMATION MODEL # AXCBUR17-LGB HARDWARE DESCRIPTION ALLEN KEY SCREW CAM LOCK PIN WOOD DOWEL M6 X 30 mm CAM LOCK Ø8 X 30 mm QTY 20 QTY 26 SETS QTY 8 PHILLIPS SCREW ROUND HEAD ALLEN KEY SHELF SUPPORT M4 X 15 mm QTY 1 QTY 30... - Page 8 COMPONENTS – KEY DIAGRAM MODEL # AXCBUR17-LGB 8/21...
- Page 9 ASSEMBLY MODEL # AXCBUR17-LGB STEP 1 1. Attach four Cam Lock Pins 2 to back of Drawer Front L . 2. Align Cam Lock Pins with guide holes and attach Drawer Sides ML , MR . 3. Insert two Cam Locks 2 into guide holes on each Drawer Side ML , MR . 4.
- Page 10 ASSEMBLY MODEL # AXCBUR17-LGB STEP 3 1. Align Drawer Back N with Drawer Bottom O and press firmly into slot . 2. Attach Drawer Back N using two Allen Key Screws 1 through guide holes on each side ML , MR . 3.
- Page 11 ASSEMBLY MODEL # AXCBUR17-LGB STEP 5 1. Attach three Cam Lock Pins 2 into pre-drilled holes on each Divider DL , DR . 2. Align Cam Lock Pins with guide holes and attach Centre Shelf E . 3. Insert six Cam Locks 2 into guide holes on Centre Shelf E . 4.
- Page 12 ASSEMBLY MODEL # AXCBUR17-LGB STEP 7 1. Insert four Dowels 3 into guide holes on Bottom Shelf C . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3. Attach three Cam Lock Pins 2 into pre-drilled holes on each Side BL , BR . 4.
- Page 13 ASSEMBLY MODEL # AXCBUR17-LGB STEP 8 1. Insert two Dowels 3 into guide holes at top corners of each Side BL , BR . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 14 ASSEMBLY MODEL # AXCBUR17-LGB STEP 9 1. A ach Bo om Support Leg P align with pre-drilled holes at back of Bo om Shelf C . Phillips screwdriver to ghten four Phillips Screws 11 . 14/21...
-
Page 15: Warning Label
ASSEMBLY MODEL # AXCBUR17-LGB STEP 10 Note: The back of the TV frame does not have pre-drilled holes to attach the back panels. Warning Label 1. Use Phillips Screws Round Head 5 to attach Back Panels H I JL JR through guide holes from Back Panels to the back of TV Stand. - Page 16 ASSEMBLY MODEL # AXCBUR17-LGB STEP 11 Last Step ( after adjust the door ) First Step 1. Attach hinges on Doors KL , KR to Sides BL , BR using Phillips Screws 7 into pre-drill holes: - Using Phillips screwdriver to attach Screws 7 at middle hole of hinges for both top & bottom hinges.
- Page 17 ASSEMBLY MODEL # AXCBUR17-LGB STEP 12 shelf level 1 shelf support anti - tipping shelf level 2 shelf level 3 1. Use four Shelf Supports 6 for each Shelf F , G in desired location . 2. Two Shelf Supports 6 may be used on back top of each Shelf F , G as a tipping restraint.
- Page 18 ASSEMBLY MODEL # AXCBUR17-LGB STEP 13 1. Insert assembled drawers into glides on assembled TV 18/21...
- Page 19 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. STEP 14 NOTE: The screwdriver is not included in the hardware pack.
- Page 20 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
-
Page 21: Warranty
SIMP HOME ® L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.
