The illustrations in this manual are using the GP-540 as an example for explanation. Note that your printer may look different from these
ENGLISH
illustrations in some cases.
Overview of Setup
Set up the printer using the following procedure. Note that if an error
message appears during setup or other problems occur, refer to "Responding
to Messages" on p. 16.
1
Removing the Packaging Material
2
Assembling the Printer Stand
3
Attaching the Roll Unit
4
Installing the Printer
5
Turning On the Printer
6
Installing the Ink Tanks
7
Installing the Print Head
8
Performing Print Head Adjustment
Selecting the Method of Connecting
9
to Your Computer
Installing the Software on Your
10
Computer
Loading Paper
Performing Color Calibration
Storing Accessories
Printing From a Smartphone or Tablet
Displaying the Online Manual
Sending Information To Canon
Trademarks
Responding to Messages
Installation Space
When installing the printer, it is recommended that you secure the following
space around the printer.
Important
4 ● The printer stand and roll unit may be options depending on the model
Page
you purchased. Please note that the required space differs depending
on whether the options are used or not.
● The space required in front of the printer varies depending on how the
4
Page
basket is used.
■
4
GP-540
Page
Required space (W x D x H)
1,993 × 1,684 × 1,560 mm
4
Page
5
Page
7
Page
■
GP-520
9
Page
Required space* (W x D x H)
1,510 × 1,684 × 1,560 mm
Required space** (W x D x H)
11
1,510 × 1,434 × 1,021 mm
Page
13
Page
14
Page
* When using the SD-21 printer stand
15
Page
** When not using the printer stand
15
Page
15
Page
15
Page
15
Page
15
Page
16
Page
16
Page
1
200 mm
600 mm
150 mm
200 mm
600 mm**
100 mm*
600 mm*
150 mm
200 mm
100 mm
100 mm**
200 mm
