GENERAL

The LAD4 alignment device is designed to contribute to a quick and easy installation of
Reer safety light curtains.
The device emits a visible (red) laser beam, thanks to which it is possible to correctly
align the emitter and the receiver, as well as the possible deflection mirrors.
The device is powered by two AAA batteries, included in the packaging.
THE FOLLOWING WARNINGS ARE FUNDAMENTAL FOR PEOPLE'S SAFETY. FOLLOW ALL THE
WARNINGS CAREFULLY, TO AVOID RISKS OF EYE INJURIES.
THE USE OF COMMANDS, ADJUSTMENTS, AS WELL AS THE CARRYING OUT OF
PROCEDURES DIFFERING FROM THE ONES HEREWITH EXPOSED MAY BE CAUSE OF
EXPOSURE TO DANGEROUS LEVELS OF RADIATION.
•
The device contains a laser source Class II, according to EN 60825 – 1.
•
LAD4 has been conceived as an aid for the alignment of optical light curtains. DO
NOT USE as a pointer on screens, posters, presentations, etc. For any other use,
consult Reer beforehand.
•
LAD4 is a working tool of exclusive professional use. See that the staff in charge
has read and understood these instructions and warnings thoroughly and is well
aware of the possible risks arising from a non – correct use. Never use outside the
working environment and don't let untrained personnel access it, children in
particular.
•
Always keep this notice together with the device.
User cautions:
Never aim the laser source directly at the eyes of others or to your own. Never look directly into
the source.
Keep the laser on only for the time which is strictly necessary to its professional use. Check that
the device is off before putting it away.
If you have to keep the LAD4 inactive for some time, take the batteries away from it and keep
them separately.
Guard the device and don't let any unauthorized person access it.
For more details check the European Standard EN 60825 – 1.
• •
8540746 01 Ottobre 2009 Rev.0
LAD4
LASER ALIGNMENT DEVICE
INSTALLATION, USE AND MAINTENANCE
