User manual for your
BYO600.5SS
60 cm Fan oven
NOTE
:
This
User
Instruction
Manual
contains
important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
GS 24/05/12
1
Advertisement
Table of Contents
Related Manuals for Baumatic BYO600.5SS
Summary of Contents for Baumatic BYO600.5SS
- Page 1 User manual for your BYO600.5SS 60 cm Fan oven NOTE This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for you or any person not familiar with the operation of the appliance.
-
Page 2: Table Of Contents
Contents Environmental note Important safety information 4 - 6 Specifications 7 – 8 Product and aperture dimensions Product specifications Standard accessories Optional extra Electrical details Cooling fan Control panel Using your oven 9 –13 Before first use Using the minute minder Selecting an oven function Oven functions Thermostat control knob... -
Page 3: Environmental Note
Environmental note o The packaging materials that we use are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Advice Line. - Page 5 Child Safety o We strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. o If it is necessary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
- Page 6 Installation This appliance must be correctly installed by a suitably qualified person, strictly in accordance with the manufacturer’s instructions. o The manufacturer declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance. o Heat, steam and moisture will be created during use of the appliance, take care to avoid injury and ensure that the room is adequately ventilated.
-
Page 7: Specifications
Specifications Product Dimensions Height: 594 mm Width: 594 mm Depth: 556 mm Aperture Dimensions Height: 595 mm Width: 560 mm Depth: 560 mm Product specifications o 4 oven functions o Energy efficiency class: A o Oven gross capacity: 67 litres o Oven net capacity: 58 litres o Minute minder o Cooling fan... -
Page 8: Cooling Fan
Cooling fan o A tangential cooling fan is fitted inside of this appliance, to make the internal temperature of the oven stable and the external surface temperature lower. o After you have finished cooking and switched off the oven, the cooling fan will continue to run for a period of time afterwards. -
Page 9: Using Your Oven
Using your oven Before first use o To remove any residue from the oven that may have been left from the manufacturing process, you should select the fan oven function and set the thermostat to its maximum temperature setting. o It is perfectly normal for a smell to be produced during this process. -
Page 10: Using The Minute Minder
Using the minute minder You are able to set the minute minder at any time, regardless of whether an oven function has been selected. You can set a period of time using the minute minder function and a buzzer will sound when that period of time has elapsed. o The minute minder can be set for any length of time between 0 and 60 minutes. -
Page 11: Selecting An Oven Function
Selecting an oven function The oven function selector knob should be used to select the particular mode of cooking that you require. The appliance will utilise different elements within the oven cavity, depending on the oven function that you select. When a function is selected, the power indicator light will come on and the oven light. -
Page 12: Oven Operating Light
Oven operating light o This light will come on to indicate that the oven’s heating elements are in operation. The light will turn off when the temperature set on the thermostat control knob has been reached. It will cycle on and off throughout the cooking time. -
Page 13: Warnings
Warnings o Keep the oven door closed when using ALL oven functions, including the grill function. o Do not use aluminium foil to cover the enamelled baking tray or heat items wrapped in aluminium foil under the grill. The high reflectivity of the foil could potentially damage the grill element. -
Page 14: Cleaning And Maintenance
Cleaning and maintenance Cleaning operations must only be carried out when the oven is cool. The appliance should be disconnected from your mains supply before commencing any cleaning process. o The oven should be thoroughly cleaned before it is operated for the first time and after each use. -
Page 15: Replacing The Oven Bulb
Replacing the oven bulb IMPORTANT: The oven must be disconnected from your mains supply before you attempt to either remove or replace the oven bulb. o Remove the oven shelf and the baking tray. o It is recommended to line the base of the oven with a tea towel during this process to prevent damage if any parts are dropped. -
Page 16: Installation
o You should grip the sides of the door at the centre and then incline it slightly towards the oven cavity and then pull the door gently away from the oven cavity. o IMPORTANT: You should make sure that the door is supported at all times and that you place door some... -
Page 17: Electrical Connection
Electrical connection Before connecting the appliance, make sure that the supply voltage marked on the rating plate corresponds with your mains supply voltage. WARNING: THIS APPLIANCE MUST BE EARTHED. o This appliance should be wired into a 16 A double pole switched fused spur outlet, having 3 mm contact separation and placed in an easily accessible position adjacent to the appliance. -
Page 18: Installing The Oven Into The Kitchen Cabinet
o If the mains supply cable is damaged, then it must be replaced by an appropriate replacement which can be obtained from the Spares Department. Installing the oven into the kitchen cabinet Positioning the appliance o Ensure that the aperture that you will be fitting the oven into is of the size given in the diagram above. -
Page 19: Ventilation Requirements
Ventilation requirements (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a standard kitchen unit). (Figure shows ventilation and cut- out requirements for the installation of the appliance into a tall housing unit). -
Page 20: My Appliance Isn't Working Correctly
My appliance isn’t working correctly o The oven isn’t coming on. * Check that you have selected a cooking function and a cooking temperature. o There appears to be no power to the oven and grill. * Check that the appliance has been connected to the electrical mains supply correctly. - Page 21 o I am getting condensation in my oven * Steam and condensation is a natural by product of cooking any food with high water content, such as frozen food, chicken etc. * You may get condensation in the oven cavity and forming between the oven door glasses.
-
Page 24: Contact Details
United Kingdom 6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom Customer Care (0118) 933 6918...
