Baumatic BY9006SS User Manual

Baumatic BY9006SS User Manual

90 cm built-in electric double oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual for your
BY906SS 90 cm
Built-in electric double oven
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
GS 18/05/12
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BY9006SS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Baumatic BY9006SS

Summary of Contents for Baumatic BY9006SS

  • Page 1 User Manual for your BY906SS 90 cm Built-in electric double oven NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...

  • Page 2: Table Of Contents

    Contents Environmental note Important safety information 4 – 7 Specifications 8 - 10 Product and aperture dimensions Product specifications Standard accessories Optional extra Electrical details Cooling fans Control panel Oven programmer/timer display Setting and using the oven programmer/timer 11 - 15 Selecting manual operation mode Setting the time of day Before first use...

  • Page 3: Environmental Note

    Environmental note o The packaging materials that we use are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment.

  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Advice Line.
  • Page 5 Warning and safety instructions o This appliance complies with all current European safety legislation. We do wish to emphasise that this compliance does not remove the fact that the appliance surfaces will become hot during use and retain heat after operation. Child Safety o We strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to...
  • Page 6 o Do not place heavy objects on the oven door or lean on the oven door when it is open, as this can cause damage to the oven door hinges. Nobody should be allowed to sit or stand on any part of the oven.
  • Page 7 Cleaning o Cleaning of the oven should be carried out on a regular basis. o Great care should be taken whilst using this appliance and when following the cleaning procedure. o IMPORTANT: The appliance must be disconnected from the mains before following the cleaning procedure. Installation This appliance must be correctly installed by a suitably qualified person, strictly in accordance...

  • Page 8: Specifications

    Specifications Product Dimensions Aperture dimensions Height: 888 mm Height: 880 mm Width: 594 mm Width: 560 mm Depth: 540 mm Depth: 500 mm Product specifications o Energy efficiency class: B/A o LED full programmer o Cooling fan o Double glazed removable doors o Mark-resistant coating o Top oven: conventional oven o 3 functions...

  • Page 9: Standard Accessories

    Standard accessories o 2 x Safety shelves o Trivet o Wipe-clean enamelled baking tray with handle o Removable side racks Optional extra o BPS2 Pizza stone Electrical details Rated Voltage: 220 - 240 Vac 50 Hz Supply Connection: 20 A (double pole switched fused outlet with 3mm contact gap) Max Rated Inputs: 3.90 kW...

  • Page 10: Control Panel

    Control Panel Oven programmer/timer Minute minder button Auto cooking button End of cooking button Manual operation button Minus button Plus button Timer symbol Cooking in progress symbol LED display 10) AUTO cooking symbol...

  • Page 11: Setting And Using The Oven Programmer/Timer

    Setting and using the oven programmer/timer Selecting manual operation mode After your appliance is connected to your mains supply for the first time, the numbers on the timer display will flash. Before you can select a cooking function or set a temperature, you must set the appliance into manual operation mode.

  • Page 12: Cooking Without A Timer Function

    o After the oven cavity has cooled, it should then be cleaned with warm soapy water, using either a sponge or soft cloth. No abrasive cleaners should be used. o Outer parts of the oven should be cleaned with warm soapy water, using either a sponge or soft cloth.

  • Page 13: Setting The Duration Function (Bottom Oven Only)

    Setting the duration function (bottom oven only) This function will allow you to set a countdown time similar to the minute minder function. However the oven will no longer continue to heat, once the countdown period has elapsed. o Use the oven function and temperature control knob to select the fan oven function as well as the temperature.

  • Page 14: Setting The End Cook Function (Bottom Oven Only)

    Setting the end cook function (bottom oven only) This function is similar to the duration function, however instead of selecting a period of time that you wish the oven to switch off after. You select the time of day that you wish the oven to switch off at. o Use the oven function and temperature control knob to select the fan oven function as well as the temperature.

  • Page 15: Setting The Start And End Time Function (Bottom Oven Only)

    Setting the start and end time function (bottom oven only) This function will allow you to set a time in the future that the oven switches on at and a time that the oven will switch off at. o Use the oven function and temperature control knob to select the fan oven function as well as the temperature.

  • Page 16: Selecting A Cooking Function And Temperature

    Selecting a cooking function and temperature IMPORTANT: Before attempting to select an oven function for the first time, you must set the time of day. Selecting a top oven function and temperature o The top oven control knob can be used select particular...

  • Page 17: Using The Grill

    FULL GRILL: This method of cooking utilises the inner and outer parts of the top element, which directs heat downwards onto the food. This function is suitable for grilling medium or large portions of sausages, bacon, steaks, fish etc. Using the grill IMPORTANT: The oven door should always be closed when using the grill function.

  • Page 18: Selecting A Bottom Oven Function And Temperature

    Selecting a bottom oven function and temperature o The bottom oven control knob can be used to select the particular mode of cooking that you require, as well as the temperature. o The appliance will utilise different elements within the oven cavity, depending on the oven function that you select.

  • Page 19: Oven Operating Lights (Main And Secondary Oven)

    Oven operating lights (main and secondary oven) This light will come on to indicate that the oven’s heating elements are in operation. The light will switch off when the temperature set has been reached. It will cycle on and off throughout the cooking time. You should not place food inside the cavity, until the correct cooking temperature has been reached.

  • Page 20: Warnings

    Warnings o Keep the oven door closed when using any of the cooking functions, including all grill functions. o Do not use aluminium foil to cover the enamelled baking tray or heat items wrapped in aluminium foil under the grill. The high reflectivity of the foil could potentially damage the grill element.

  • Page 21: Cleaning And Maintenance

    Cleaning and maintenance Cleaning operations must only be carried out when the oven is cool. The appliance should be disconnected from your mains supply before commencing any cleaning process. o The oven should be thoroughly cleaned before it is operated for the first time and after each use.

  • Page 22: Removing The Side Racks

    Removing the side racks Remove the shelves and push this runner bar down to release the runners from the fixing Fixing To properly clean the oven cavity, it is necessary to remove all of the oven furniture, including the side racks. To remove the side racks you should follow the instructions shown in the picture above.

  • Page 23: Removing The Oven Door For Cleaning (Both Ovens)

    o Unscrew the lamp from the lamp holder and replace the bulb with a 25 W/300°C, screw type pygmy. o Do not use any other type of bulb. o Replace the diffuser by screwing it back into its original position. Removing the oven door for cleaning (both ovens) IMPORTANT: Ensure that the oven door is cool before cleaning.

  • Page 24: Installation

    o Check that the weight of the door is fully supported on the hinges. o Lower the door and raise the hinge clips, then return them away from you and back to their starting positions. o Check that the seal is in place then close the door. Make sure that the inner face of the door meets and shuts against the seal all around.

  • Page 25: Connecting The Mains Supply Cable

    o To connect the oven power cord, loosen and remove the cover on the terminal block, in order to gain access to the contacts inside. Make the connection, securing the cord in place with the cable clamp provided and then immediately close the terminal block cover again.

  • Page 26: Replacing The Mains Supply Cable

    o The brass links must be positioned as marked in the diagram above and once established ALL terminal screws must be tightened down firmly. o If when the oven is first switched on, it does not function correctly, you should recheck that the terminal screws are all fully tightened between the links.

  • Page 27: Built In Installation

    Built-in installation Positioning the appliance o Ensure that the aperture that you will be fitting the oven into is of the size given in the above diagram. o The oven must be fitted into an oven housing with the ventilation cut-outs shown in the drawing above.

  • Page 28: My Appliance Isn't Working Correctly

    My appliance isn’t working correctly o The oven isn’t coming on. * Check that you have selected a cooking function and a cooking temperature. * Check that the auto cooking symbol (10) isn’t lit on the LED display. o There appears to be no power to the oven and grill. * Check that the appliance has been connected to the electrical mains supply correctly.
  • Page 29 o I am getting condensation in my oven. * Steam and condensation is a natural by product of cooking any food with high water content, such as frozen food, chicken etc. * You may get condensation in the oven cavity and forming between the oven door glasses.

  • Page 32: Contact Details

    United Kingdom 6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom Customer Care (0118) 933 6918...
