Summary of Contents for Baumatic B721-A
- Page 1 ������������������������...
- Page 3 Models covered by this manual: B721BL-A B721W-A B722SS-A B723SS-A USER AND INSTALLATION INSTRUCTIONS...
-
Page 4: Serial Number
For future reference please record the following information which can be found on the Rating Plate and the date of purchase which can be found in the invoice: Model Number Serial Number Date of Purchase ……………………. Supplier ……………………. ……………………. ……………………. -
Page 5: Table Of Contents
CONTENTS General Information Warning and Safety Instructions Installation Instructions Timer Instructions Before the first use Operating Instructions Cooking Guide Cleaning and Maintenance Fault Finding Technical Data Conditions of Guarantee Pages 3-4 Pages 5-6 Pages 7-10 Pages 11-13 Page 14 Pages 15-19 Page 20 Pages 21 Page 22... -
Page 7: General Information Pages
Installation Instructions. The use for any other purpose or in any other environment without the express agreement of Baumatic Ltd, would invalidate any warranty or liability claim. Your new appliance is guaranteed against electrical or mechanical defects subject to certain exclusions noted in Baumatic Ltd Conditions of Guarantee. - Page 8 CE Marking – 93/68 Low Voltage – 73/23 Safety Standards – EN 60 335-1, EN 60 335 – 2 – 6. As Baumatic have a policy of continued product improvement, the right is reserved to adjust and make any modifications deemed necessary without notification.
-
Page 9: Warning And Safety Instructions Pages
Baumatic therefore strongly advise that babies, young children and unable people are prevented from being near or touching the appliance at any time. - Page 10 N O T E : T h i s a p p l i a n c e m u s t b e c o r r e c t l y i n s t a l l e d b y a s u i t a b l y q u a l i f i e d p e r s o n , s t r i c t l y i n a c c o r d a n c e w i t h t h e m a n u f a c t u r e r ’...
-
Page 11: Installation Instructions Pages
INSTALLATION INSTRUCTIONS This appliance must be correctly installed by a suitable qualified person strictly in accordance with the manufacturer's instructions. The manufacturer's declines any responsibility for injury or damage to persons or property as a result of improper installation of this appliance. The housing, adjacent furniture and all materials used in installation must be able to withstand a minimum temperature of 85°C plus ambient during periods of operation. -
Page 12: Ventilation Requirements
Note: in both of the above cases you must measure 717 mm from the underside of the worktop and mark the correct position of the lower support brackets before fixing them to the sides. With reference to (fig.3-page 9), ensure the side support brackets are positioned 40 mm from the front of the cabinet door exterior surface, as illustrated, before securing them to the cabinet sides. -
Page 13: Installation
INSTALLATION Rear Wall Oven lways remove the rear panel of the housing unit 50-80 mm Front of oven ACK EDGE OF SUPPORT SHELF (WHEN APPLICA LE) -
Page 14: Electrical Requirements
ELECTRICAL REQUIREMENTS WARNING: THIS APPLIANCE MUST BE EARTHED Electrical installation must comply with all relevant local and national regulations. Make sure that the voltage supply is the same as the rating given on the data plate positioned on the lower part of the front of the oven. This appliance must be connected to an a.c. -
Page 15: Timer Instructions Pages
PROGRAMMING YOUR OVEN WITH MECHANICAL 60 MINUTES TIMER (only B721BL-A, B721W-A, B722SS-A) The regulating knob must be turned in a clockwise direction until it reaches the 60 minutes position and then turned to the desired time by turning the knob in a counter clockwise direction. - Page 16 USING THE 5 BUTTON ELECTRONIC TIMER (only B723SS-A) Description of button functions: 1. Minute Minder 2. Cooking on auto-function (duration) 3. End of Cooking time (end time) 4. Reducing numbers in all programs 5. Increasing numbers in all programs (please note the buttons have been numbered for illustration only) The timer only operates when the appliance is connected to the electricity supply.
- Page 17 5) MINUTE MINDER MODE: Briefly press the ‘Minute Minder’ button (1). Set the required time by pressing the + or – buttons. The ‘bell’ symbol is displayed. When the set time has elapsed, an audible signal is emitted, to cancel the alarm mode press the ‘end time’...
-
Page 18: Before The First Use
BEFORE THE FIRST USE Remove any packaging and the accessories from the oven. Wipe the oven interior using hot water and mild detergent. Rinse carefully using damp cloth. Wash the oven shelves and accessories in a dishwasher or using hot water and a mild detergent, and dry thorouhgly. -
Page 19: Interior Light
OPERATING INSTRUCTIONS Conventional oven (Top oven) - all models Main functions Conventional cooking Variable control grilling Interior light Convection mode (outer section only on top element). This traditional cooking mode is achieved by selecting the desired cooking temperature within the given 50°C to 230°C. - Page 20 T o p h e a t i n g e l e m e n t o n l y ( o u t e r s e c t i o n o n l y ) . T h i s c o o k i n g m o d e i s p a r t i c u l a r l y s u i t e d f o r d e l i c a t e f o o d , f o r b r o w n i n g a n d k e e p i n g d i s h e s...
- Page 21 Main fan oven (Lower cavity) - only B721BL-A, B721W-A, B722SS-A M a i n F u n c t i o n Fan oven cooking S e l e c t t h e d e s i r e d t e m p e r a - t u r e b e t w e e n 5 0 °...
-
Page 22: Convection Mode
LOWER CAVITY FUNCTIONS (only B723SS-A) Temperature selector knob: select the desired temperature between 50°C and 230°C. Selector knob: OVEN LIGHT The oven light remains on whilst the oven is in use. FAN ASSISTED LOWER ELEMENT MODE This provides semi-convection heating with lower element for delicate dishes. -
Page 23: Defrost Mode
GRILL MODE This is for grilling smaller items of food. Keep the oven door closed. DOUBLE GRILL MODE To cook meat and for making toast. Preheat the oven for 5 min. with the door closed. When cooking, keep the oven door closed. FAN ASSISTED GRILL MODE This provides quick browning to seal juices in the food. -
Page 24: Cooking Guide
COOKING GUIDE TOP OVEN COOKING TABLE FOR GRILL FUNCTION LOWER OVEN... -
Page 25: Cleaning And Maintenance
CLEANING AND MAINTENANCE Important: do not use water pressure cleaners or steam cleaners. Exterior of the oven Clean with a damp cloth. If it is very dirty, add a few drops of washing up detergent to the water. Wipe with a dry cloth. Do not use corrosive or abrasive detergents, which dull the surface. -
Page 26: What To Do In The Event Of A Fault
The light bulb is faulty and needs replacing (see page 21). NOTE: THE LIGHT BULB IS NOT COVERED BY THE MANUFAC- TURER'S WARRANTY. If the above solutions do not rectify your fault please contact Baumatic After Sales Service on 0118 933 6911 . -
Page 27: Technical Data
TECHNICAL DATA This fitting conforms with laws regarding radio interfence. ELEMENT RATING LOWER OVEN: FAN MOTOR CIRCULAR HEATING UPPER OVEN: LOWER HEATING UPPER HEATING GRILL HEATING 2 OVEN LIGHTS 2 COOLING MOTORS ELECTRICAL SUPPLY: MAXIMUM LOAD: STATIC + FAN CABLE CROSS SECTION: 3x2.5 mm²... -
Page 29: Conditions Of Guarantee
All ‘Work’ in relation to the Guarantee must be carried out by Baumatic Ltd or an approved service agent of Baumatic Ltd. Any claims made under the terms of the guarantee must be supported by the original invoice / bill of sale issued at the time of purchase. - Page 30 For ROI (Republic of Ireland), please contact one of the numbers as below: Tel: 01 – 4030501 FAX: 01 – 4030503 Thank you for buying Baumatic. SERVICE SPARES TEL 0118 933 6911 TEL 0118 933 6922 FAX 0118 986 9124...
- Page 32 � � � � � � � � � � � � � � � �...
