Summary of Contents for Cylinda DM 3343 D
- Page 1 User manual DM 3343 D DM3238C DM 3343 RFD DM3238RFC DM3234D DM3434C DM3205E DM3434RFC DM3205RFE 15 8729 0100_AB_CYLINDA_D1_EN/ 03-02-23.(10:26)
- Page 2 Dear Customer, Please read this user manual before using the product. Thank you for choosing this product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents before using the product.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY INSTRUCTIONS Adjusting the height of the upper basket ..27 Upper basket multi-function service rack..28 Intended Use ............. 4 Collapsible upper basket wires ......29 Safety for children, vulnerable persons and pets 4 Height setting with empty basket ..... 29 Electrical safety .......... -
Page 4: Safety Instructions
This product must be used to Safety Instructions do the domestic type dishes • This section contains safety only. instructions that will help get This product is not suitable for protected against risks of commercial or collective use. personal injury or property damage. -
Page 5: Electrical Safety
possible, the electrical Keep packaging materials installation where the product away from children. There is connected must contain is the risk of injury and a device which conforms to suffocation. the electrical regulations and Store all detergents and disconnects all poles from the additives used with the grid. -
Page 6: Installation Safety
Installation Safety stove and etc.) or under the cooking area of a hob. • To make the product ready for use, review the information • If the product is going to in the user manual and be used inside a wardrobe/ installation instructions and cabinet/module, keep the make sure that the electricity,... -
Page 7: Operational Safety
Pressure coming from the tap Maximum washing capacity should be 0.03 MPa (0.3 bars) of the product is stated in the minimum and 1MPa (10 bars) section called “Technical maximum. If the water pressure Specifications”. exceeds 1 MPa (10 Bars), a To prevent possible injuries, pressure relief valve should be always place the sharp and... -
Page 8: Maintenance And Cleaning Safety
Environmental Maintenance and cleaning safety Instructions Do not wash the product by Compliance with WEEE spreading or pouring water Directive and Disposing of onto it. the Waste Product Do not use sharp or abrasive This product complies with tools when cleaning the EU WEEE Directive (2012/19/ product. -
Page 9: Package Information
Package information Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities. -
Page 10: Technical Specifications
Technical specifications Note for test institutions: Data required for performance tests shall be provided upon request. Requests can Maximum washing capacity (check the be e-mailed to the following address: energy label and Programme data and dishwasher@standardloading.com average consumption values table given Do not forget to provide the code, stock on Quick Guide. -
Page 11: Your Dishwasher
Your dishwasher Overview 1. Upper basket 2. Upper impeller 3. Lower impeller 4. Cutlery basket (depends on model) 5. Door 6. Rating Label 7. Control panel 8. Detergent dispenser 9. Lower basket 10. Filters 11. Salt reservoir lid 12. Upper basket rail 13. -
Page 12: Installation
Installation Appropriate installation location In the area where this product is Read “Safety Instructions” section first! installed, there must not be a lockable, Installation procedures must always be sliding or hinged door that will restrict performed by the manufacturer, authorised full opening of the product’s door. -
Page 13: Aquasafe
Aquasafe+ Permitted water temperature: up to 25°C ( 60°C for products equipped (depends on the model) with Aquasafe+; please refer to The Aquasafe+ system protects against Aquasafe+ section ) water leaks that may occur at the hose The dishwasher may not be connected to inlet.Water contact with the valve box of open warm water devices or flow-through the system must be avoided to prevent... -
Page 14: Connection To The Drain
Connection to the drain Electrical connection Water discharge hose can directly be Connect the product to a grounded connected to the drain hole or sink’s outlet protected by a fuse complying drainage. See the installation manual with the values in the "Technical supplied with your machine for detailed specifications"... -
Page 15: Preparation
Preparation Read “Quick Guide - Adjusting Water Softening System” before this section! The regeneration of the water softening Read “Safety Instructions” section first! system can be done in all programmes Tips for energy saving during drying step. When regeneration occurs, duration, energy and water Following information will help you use the consumption of the programme increase. -
Page 16: Adding Salt
Adding salt Water softening system needs to be regenerated in order for the product to operate with the same performance continuously. Dishwasher salt is used for this purpose. Use only special softening salts produced particularly for the dishwashers in your machine. You can put about 2 kg of softening It is recommended to use granule- or salt into the salt reservoir. - Page 17 Adding detergent Pay attention to the warnings on the detergent packaging to get better washing and drying results. Contact the manufacturer of the detergent for further questions. Do not put solvents into the detergent dispenser. There is the risk of explosion! 3.
-
Page 18: Tablet Detergents
Tablet detergents 3. After the empty washing cycle, review the user manual and readjust the water In addition to the conventional tablet hardness level so as to suit the water detergents, there are also commercially supply. available detergent tablets that show water 4. -
Page 19: Items Not Suitable For Washing In The Dishwasher
3. Slightly press the point (B) of the Decorative prints of chinaware as well reservoir lid to close it. as aluminium and silver items may get discoloured or tarnished after washing in the dishwasher just as it happens in handwashing as well. Some delicate glass types and crystals may become dull in time. - Page 20 Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Improper Loading Of Dishware 20/EN...
-
Page 21: Cutlery Basket
Cutlery basket Cutlery basket (depends on model) (depends on model) Cutlery basket is designed to wash your Cutlery basket is designed to wash your dishes such as knife, fork, spoon, etc. in an dishes such as knife, fork, spoon, etc. in an efficient manner. -
Page 22: Collapsible Lower Basket Tines
Collapsible lower basket tines Collapsible lower basket tines (depends on model) (depends on model) There are foldable tines (A) located at There are foldable tines (A) located at the lower basket of the machine are the lower basket of the machine are designed for an easier placement of large designed for an easier placement of large pieces such as pans, bowls, etc. -
Page 23: Tray Wash Supports
SoftTouch Accessory Tray Wash Supports (depends on model) (depends on model) The SoftTouch Accessory found in the Use the supports to wash trays in the lower basket of your machine enables a bottom basket. safe washing for your fragile glasses. See the Auxiliary functions section for appropriate programme and function selection. -
Page 24: Lower Basket Multipurpose / Height Adjustable Service Rack
Lower basket multipurpose / To close the racks: 1. Fold the rack (A). height adjustable service rack 2. Slide the rack up (B). (depends on model) This accessory located at the lower basket 3. Put the rack in vertical position (C). of your machine allows you to easily wash 4. -
Page 25: Lower Basket Bottle Wire
Lower basket bottle wire Upper basket multipurpose service rack (depends on model) The bottle wire is designed for easier (depends on model) washing of long pieces with wide mouths. This accessory located at the upper basket You may take out the bottle wire from the of your machine allows you to easily wash basket when not in use by pulling it out pieces such as extra long ladles and bread... -
Page 26: Adjusting The Height Of The Upper Basket
Adjusting the height of the upper To lower the basket, while it is in the uppermost position; basket 1. Hold the upper basket wires with both (depends on model) hands, slightly lift up the basket and The upper basket height adjustment simultaneously push and release the mechanism has been designed for you to latches shown in the figure (B). -
Page 27: Adjusting The Height Of The Upper Basket
Adjusting the height of the upper Repeat the same operation if the height is not adequate. basket (depends on model) Upper basket height adjustment mechanism is designed so that you can create wide spaces on the upper or lower compartment of the machine by adjusting the basket upwards or downwards either while it is empty or full. -
Page 28: Upper Basket Multi-Function Service Rack
Upper basket multi-function Tray Washing Support (depends on model) service rack You may use the tray washing supports (depends on model) if you want to wash a tray on your lower Thanks to the upper basket multi-function basket. service rack on the upper basket of your Refer to the Additional Functions section to appliance, you may load and wash long select the proper program and function. -
Page 29: Collapsible Upper Basket Wires
Collapsible upper basket wires Height setting with empty basket (depends on model) (depends on model) You can use collapsible wires when you In this model, the height setting of the need a larger space for your dishes in the upper basket may be changed using the upper basket of your machine. -
Page 30: Ceiling Cutlery Basket
Ceiling cutlery basket (depends on model) Ceiling cutlery basket is designed to wash your cutlery items such as forks, spoons and etc. by placing them between the bars on the basket. When the central tray is in the lower position, you can load long/high items such as coffee cups, ladles, etc. -
Page 31: Operating The Product
Operating the product 2. Refer to the table of "Programme data Read “Safety Instructions” section first! and average consumption values" Read “Quick Quide” before this to determine a washing programme section. suitable for your dishes. Keys 3. Press Programme Selection keys until the number of the programme you On / Off key selected appears on the Programme... - Page 32 Half Load function Super Rinse Function (Depends on model) (Depends on model) It is used to operate the machine without Depending on the type of the detergent loading it completely. used, if a detergent dissolving issue is 1. Load your dishes in the machine as encountered it will remove the resulting you like.
- Page 33 Auto Tablet Feature Interior Lighting (Depends on model) (depends on the model) Auto Tablet is a feature which detects Some models have interior lighting to the use of combined tablet detergents illuminate the interior when the door is automatically. opened. Drying performance of these type of 1.
-
Page 34: Programming The Washing Time
Changing SelfDry Settings 3. Set the desired time by pressing the 1. Press the Delay and P/P+ key Time Delay key. Time will increase with simultaneously after turning on your increments of 30 minutes up to 6 hours machine. Keep pressing until the and after that in 1 hour increments up countdown on the screen displayed as to 24 hours every time you press the... -
Page 35: Child (Key) Lock
2. "3", "2", "1" is displayed on Display Once the programme starts a tune is Information Line and key lock is played and the estimated time remained to activated. the end of the programme will appear on the Display Information Line. Start / Pause / Child Lock prevents the selected Cancel indicator starts lighting continuously. -
Page 36: End Of Programme
End of programme Salt indicator ( ) Please check the salt indicator on the End of Programme indicator will light up display to see whether there is adequate once the washing programme is over. amount of softening salt in the dishwasher 1. -
Page 37: Innerclean
InnerClean (depends on model) This programme is recommended to be operated on each 1-2 months for machine cleaning and necessary hygiene. The programme should be operated while the machine is empty. In order to achieve an efficient result, it is recommended to use together with special machine cleaning agents. -
Page 38: Maintenance And Cleaning
Maintenance and Cleaning the filters cleaning Clean the filters at least once a week in order for the machine operates efficiently. Read “Safety Instructions” section first! Check if food residues are left on the filters. Unplug the product and turn off the If there are food residues on filters, take tap before attempting any cleaning them out and clean well under running... -
Page 39: Cleaning The Hose Filter
Cleaning the hose filter Damages on the machine that may be caused by impurities coming from the urban supply water or your own water installation (such as sand, dirt, rust, etc.) can be prevented by means of the filter attached to the water inlet hose. Check the filter and the hose regularly and clean them if necessary. -
Page 40: Cleaning The Impellers
Cleaning the impellers Do not try to rotate the impeller by Clean the impellers at least once a week in holding its ends. Trying to rotate the order for the machine operates efficiently. end sections may cause the gear system within the impeller to break. Lower impeller Upper impeller Check if the holes on the lower impeller (1) -
Page 41: Troubleshooting
Troubleshooting Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •... - Page 42 • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine. • Machine is unloaded right after the programme is over. >>> Do not unload your machine right after washing process is completed.
- Page 43 There is a different odour in the machine A new machine has a peculiar odour. It will fade out after a couple of washes. • Filters are clogged. >>> Check if the filter system is clean. Clean the filter system regularly as illustrated in section “Cleaning and Care”.
- Page 44 • Opening of the detergent dispenser lid is prevented during washing. >>> Place the dishes in a way that will not prevent the detergent dispenser lid from opening and the water going into the machine from impellers. • Detergent is stored under unsuitable conditions. >>> If you are using powder detergent, do not store the detergent package in humid places.
- Page 45 Foam forms in the machine. • Dishes are washed with hand-wash detergent by hand but not rinsed before placing them into the machine. >>> Hand-wash detergents do not contain antifoam. There is no need to hand-wash the dishes before placing them into the machine. Removing the coarse soil on the dishes under tap water, with a tissue paper or fork will be sufficient.
- Page 46 Service Nationwide service in Sweden Visit www.cylinda.se Call 0771-25 25 00 Declare Model code Serial number Purchase date Problem description Name and address Phone number Contact us www.cylinda.se 46/EN...
