- Page 1 DM 3158...
- Page 2 DM 3158...
- Page 3 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 4: Table Of Contents
CONTENTS 1 INSTRUCTIONS Upper basket multipurpose service rack .26 Adjusting the height of the upper basket .27 FOR SAFETY AND Collapsible upper basket wires ....28 ENVIRONMENT Height setting with empty basket .....28 General safety ...........4 Ceiling cutlery basket ......29 Intended use ..........5 Ceiling cutlery basket ......29 Children’s safety ........5 5 OPERATING THE... -
Page 5: Instructions For Safety And Environment
INSTRUCTIONS FOR SAFETY AND ENVIRONMENT This section contains safety • Never wash the product by instructions that will help to spreading or pouring water get protected from risk of onto it! There is the risk of personal injury or property electric shock! damage. -
Page 6: Intended Use
instructions for safety and environment running unless necessary. hazards involved. Children Be careful for the rush of shall not play with the hot vapour when you need appliance. Cleaning and to open the door. user maintenance shall not be made by children Intended use without supervision. -
Page 7: Transportation Of The Product
instructions for safety and environment Transportation of the electronic equipment. Please consult your local authorities to product learn about these collection If you need to move centers. the product, do it in Compliance with RoHS upright position and Directive hold from the rear side. -
Page 8: Dishwasher
DISHWASHER Overview 1. Upper basket 2. Upper impeller 3. Lower impeller 4. Silverware basket 5. Door 6. Rating Label 7. Control panel 8. Detergent dispenser 9. Lower basket 10. Filters 11. Salt reservoir lid 12. Upper basket rail 13. Upper cutlery basket (depends on model) 14. -
Page 9: Fan Drying System
Dishwasher Technical specifications Compliance to standards and test data / EC declaration of conformity This product complies with the following EU directives; Development, production and sales stages of this product comply with the safety rules included in all pertaining European Community regulations. 2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242 Power input 220-240 V, 50 Hz (see rating label) -
Page 10: Installation
INSTALLATION Appropriate installation Refer to the nearest Authorised location Service Agent for installation of your product. To make the product ready • Place the product on a solid and for use, make sure that the electricity, flat floor that has sufficient load tap water supply and water drainage carrying capacity! The product must systems are appropriate before calling... -
Page 11: Connection To The Drain
Installation Permitted water temperature: up to drainage. The length of this connection 25°C must be min. 50 cm and max. 100 cm The dishwasher may not be connected to from the floor. A discharge hose longer open warm water devices or flow-through than 4 meters causes dirty washing. -
Page 12: Aquasafe
Installation Aquasafe+ Electrical connection (depends on model) Connect the product to a grounded The Aquasafe+ system protects against outlet protected by a fuse complying water leaks that may occur at the hose with the values in the “Technical inlet.Water contact with the valve box of specifications”... -
Page 13: Initial Use
Installation If the product has a failure, it should not be operated unless it is repaired by the Authorised Service Agent! There is the risk of electric shock! Initial use Before starting to use the product, make sure that all preparations are made in accordance with the instructions in sections “Important safety instructions”... -
Page 14: Preparation
PREPARATION Tips for energy saving Following information will help you use the product in an ecological and energy- efficient manner. Wipe away any coarse food remnants on the dishes before putting them in the product. Operate the product after filling it completely. -
Page 15: Adjusting The Water Softening System
Preparation Adjusting the water softening system Cleaning, rinsing and drying performance of your dishwasher will increase when water softening system is adjusted properly. Adjust the new water hardness level according to the Water hardness level instruction in this booklet. Use the test strip supplied with the product according to the steps given below to determine hardness level of your supply water. -
Page 16: Adding Salt
Preparation 1. Firstly, take the lower basket out to use salt under this condition, salt will not add softening salt. be consumed and the Salt indicator will not illuminate. 2. Turn the salt reservoir lid counter- clockwise to open it (A, B). If you move your house, it is necessary to readjust water hardness level of your... -
Page 17: Detergent
Preparation 4. Fill the salt reservoir with salt by Detergent using the salt funnel (D). To speed You can use powder, liquid/gel or tablet up dissolution rate of salt in water, detergents in the machine. stir it with a spoon. Only use in the machine the detergents produced particularly for use... -
Page 18: Tablet Detergents
Preparation 2. Put suggested amount of powder, 3. Push the lid of the detergent liquid/gel or tablet detergent in the dispenser to close it. A "click" will be reservoir. heard when the lid is closed. Inside the detergent dispenser there are level markings that help you use appropriate amount of powder detergent. -
Page 19: Rinse Aid
Preparation level (21°dH). Water softening salt and 3. After the empty washing cycle, rinse aid must also be used together review the user manual and with the detergent if the water hardness readjust the water hardness level so level is above the mentioned level. as to suit the water supply. -
Page 20: Items Not Suitable For Washing In The Dishwasher
Preparation 3. Slightly press the point (B) of the Decorative prints of reservoir lid to close it. chinaware as well as aluminum and silver items may get discoloured or tarnished after washing in the dishwasher just as it happens in handwashing as well. - Page 21 Preparation To prevent possible injuries, always place the sharp and pointed dishes such as service fork, bread knife, etc. upside down so as their pointed ends will face down or they will lie horizontally in the dish basket. Unload dishes in the lower basket first and then the dishes in the upper basket.
- Page 22 Preparation Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Improper Loading Of Dishware 21 / 47 EN DISHWASHER / USER INSTRUCTIONS...
-
Page 23: Cutlery Basket
Preparation Cutlery basket Cutlery basket (depends on model) (depends on model) Cutlery basket is designed to wash your Cutlery basket is designed to wash your dishes such as knife, fork, spoon, etc. in dishes such as knife, fork, spoon, etc. in an efficient manner. -
Page 24: Collapsible Lower Basket Tines
Preparation Collapsible lower basket tines Bringing the tines to the horizontal position by holding (depends on model) them from the tips may cause There are foldable tines (A) located at them to bend. Therefore, it the lower basket of the machine are will be appropriate to bring designed for an easier placement of the tines in the middle to... -
Page 25: Tray Wash Supports
Preparation SoftTouch Accessory (depends on model) The SoftTouch Accessory found in the lower basket of your machine enables a safe washing for your fragile glasses. Bringing the tines to the horizontal position by holding them from the tips may cause them to bend. -
Page 26: Lower Basket Multipurpose / Height Adjustable Service Rack
Preparation Lower basket multipurpose / Make sure that the impeller height adjustable service rack does not touch the dishes (depends on model) you placed on the racks. This accessory located at the lower To close the racks: basket of your machine allows you 1. -
Page 27: Upper Basket Height Adjustable Rack
Preparation Upper basket height adjustable rack (depends on model) Use the lower and upper parts of the height adjustable racks in the upper basket of the machine by sliding them down or up according to the heights of the glasses, cups or etc. (A, B, C). You can lift up the upper basket multipurpose service rack to remove it if you do not want to use it. -
Page 28: Adjusting The Height Of The Upper Basket
Preparation Adjusting the height of the To lower the basket, while it is in the uppermost position; upper basket 1. Hold the upper basket wires with (depends on model) both hands, slightly lift up the basket The upper basket height adjustment and simultaneously push and mechanism has been designed for release the latches shown in the... -
Page 29: Collapsible Upper Basket Wires
Preparation Collapsible upper basket Release the latches on both the right and left tracks of the upper basket by wires pushing them outwards (depends on model) Pull out the basket out completely. You can use collapsible wires when you Place the basket back into the tracks at need a larger space for your dishes in the desired height the upper basket of your machine. -
Page 30: Ceiling Cutlery Basket
Preparation Ceiling cutlery basket (depends on model) Ceiling cutlery basket is designed to wash your cutlery items such as forks, spoons and etc. by placing them between the bars on the basket. When the central tray is in the lower position, you can load long/high items such as coffee cups, ladles, etc. -
Page 31: Operating The Product
OPERATING THE PRODUCT 1. Display 5. Function keys 2. On/Off key Half Load Function 3. Start/Pause/Cancel key Fast+ Function 4. Time Delay key SteamGloss Function TrayWash Function 6. Programme Selection keys 7. Programme indicator 12. End of Programme indicator 8. Salt ( ) indicator 13. -
Page 32: Keys
Operating the product Keys indicators light and add salt and/or rinse aid if needed. On / Off key 6. Close the door of the dishwasher. It is used to turn on or off the machine. Press On / Off Key to switch ON. A Programme selection signal is heard and the machine door is turned on. - Page 33 Operating the product /47 EN DISHWASHER / USER INSTRUCTIONS...
-
Page 34: Auxiliary Functions
Operating the product Auxiliary functions Half Load function It is used to operate the machine without Washing programmes of your loading it completely. dishwasher are designed to obtain 1. Load your dishes in the machine as the best cleaning effect, considering you like. -
Page 35: Programming The Washing Time
Operating the product Auto Tablet Feature Floor illumination cannot be Auto Tablet is a feature which detects cancelled by the user. the use of combined tablet detergents automatically. Changing Warning Sound Volume Drying performance of Your machine is equipped with an audio these type of detergents signal to inform warnings audibly. - Page 36 Operating the product Starting the programme increments up to 24 hours every time you press the key. To start your machine after selecting the programme and auxiliary functions, 4. Press Start / Pause / Cancel key press Start / Pause / Cancel key. to start countdown for the Time Once the programme starts a tune is Delay.
-
Page 37: Cancelling The Programme
Operating the product To deactivate the Child Lock: The machine will remain 1. Pres Child (Key) Lock keys silent in pause mode for simultaneously and hold for 3 seconds. some time in order to remove the water in the machine and 2. -
Page 38: End Of Programme
Operating the product Adjusting the amount of rinse Leave your dishes in the machine for about 15 minutes to cool down after they are 1. After turning on the machine, washed. Your dishes will dry press Time Delay and P+ keys in a shorter time if you leave simultaneously. -
Page 39: Innerclean
Operating the product InnerClean This programme is recommended to be operated on each 1-2 months for machine cleaning and necessary hygiene. The programme should be operated while the machine is empty. In order to achieve an efficient result, it is recommended to use together with special machine cleaning agents. -
Page 40: Maintenance And Cleaning
MAINTENANCE AND CLEANING Cleaning the filters Service life of the product extends and frequently faced problems decrease if it Clean the filters at least once a week is cleaned at regular intervals. in order for the machine operates Unplug the product and turn efficiently. -
Page 41: Cleaning The Hose Filter
Maintenance and cleaning Cleaning the hose filter Damages on the machine that may be caused by impurities coming from the urban supply water or your own water installation (such as sand, dirt, rust, etc.) can be prevented by means of the filter attached to the water inlet hose. -
Page 42: Cleaning The Impellers
Maintenance and cleaning Cleaning the impellers Upper impeller Clean the impellers at least once a Check if the holes on the upper impeller week in order for the machine operates (1) are clogged. If they are clogged, efficiently. remove and clean the impeller. Turn its nut to left to remove the upper impeller. -
Page 43: Troubleshooting
TROUBLESHOOTING Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •... - Page 44 Troubleshooting • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine. • Machine is unloaded right after the programme is over. >>> Do not unload your machine right after washing process is completed.
- Page 45 Troubleshooting • Salt leakage exists. >>> Pay attention not to spill salt around the salt filling hole while adding salt. Make sure that the salt reservoir lid is tightly closed after finishing the filling process. Run the prewash programme to remove the salt that spilled inside the machine.
- Page 46 Troubleshooting • Cutlery are made of low quality stainless steel. >>> Corrosion on such items is inevitable; they should not be washed in dishwashers. • Kitchen utensils that are already corroded are washed in dishwasher. >>> Rust on a corroded item can migrate to other stainless steel surfaces and cause corrosion on those surfaces as well.
- Page 47 Troubleshooting • Dishes are not placed orderly in the machine. >>> When placing the glasses and other glassware into the basket lean them not against other dishes but the edges or racks of the basket or the glass support tines. Striking of the glasses to each other or to other dishes due to the impact of water during washing can cause breaks, or scratches on their surfaces.
- Page 48 • Nationwide service • Model code • Problem description • Visit www.cylinda.se • Serial number • Name and address • Call 0771-25 25 00 • Purchase date • Phonenumber Elektroskandia Sverige AB, Cylinda, 191 83 Sollentuna...
