PRODUCT DESCRIPTION

The transmitters Wx8xxP for SIGFOX network are designed to measure temperature, relative humidity, dc voltage and to pulse
counting. The devices are available in a compact design or with connectors for the connection of external probes. The transmitters
of relative humidity also provide a value of dew point temperature. A large-capacity internal replaceable batteries are used for power.
The measured values are sent over an adjustable time interval via radio transmission in the SIGFOX network to the cloud data store.
The cloud allows you to view current and historical data through a regular web browser. The device performs a measurement every
1 minute. For each measured variable it is possible to set two alarm limits. Every change in the alarm status is sent by an extraordinary
radio message to the Sigfox network, from which it is to send to the user via e-mail or SMS message.
Device setup is done either locally by connecting your device to the computer with installed the COMET Vision software, or remotely via
cloud web interface.
Device type
Measured value
přístroje
W0810P T
W0832P T (1+2x)
W0854P T + BIN
W0870P T + U
W3810P T + RV + DP
W3811P T + RV + DP
f

TURNING ON AND SETTING UP THE DEVICE

The devices are supplied with the battery installed, but in the off state
Unscrew the four screws at the corners of the case and remove the cover. Avoid damaging the light guide that is part of the
•
cover.
Press the CONF button for about 1 s. The green indicator LED lights up and then flashes briefly every 10 s.
•
Cloud is an internet storage of data. You need a PC with internet connection and a web browser to work with. Navigate to the
•
cloud address you use and sign in to your account - if you use COMET Cloud by a device manufacturer, enter
www.cometsystem.cloud
device. Each transmitter is identified by its unique address (device ID) in the Sigfox network. The transmitter has an ID printed
on the nameplate along with its serial number. In the list of your device in the cloud, select the device with the desired ID and
start viewing the measured values.
Check in the cloud, whether the messages are correctly received. In case of problems with the signal, please refer to the manual
•
for devices in the "Download" section at
Change the device settings as needed.
•
Make sure that the seal in the cover groove is clean. Carefully tighten the cover of the device.
•
Device setting from the manufacturer – message sending interval of 10 minutes, alarms deactivated, the input for voltage
measurement is set without user recalculation for the newly registered device in the COMET Cloud and is displayed with 3 decimal
places, remote device setup enabled (only for devices purchased with a prepaid COMET Cloud).

MOUNTING AND OPERATION

The transmitter housing is provided with a pair of holes for fixing (for example, with screws or cable ties). The W0810P transmitter can
also stand freely on its bottom base without fastening.
Always install the devices vertically (with the antenna cap facing up) at least 10 cm away from all conductive objects
•
Do not install the devices in underground areas (the radio signal is generally unavailable here). In these cases, it is preferable to
•
use the model with an external probe on the cable and place the device itself, for example, one floor above.
The devices and probe cables should be place away from electromagnetic interference sources.
•
If you install the device at a greater distance from the base station or in locations where the radio signal difficult to penetrates,
•
follow the recommendations on the other side of this manual
The devices do not require special maintenance. We recommend verifying the measurement accuracy regularly by calibration.

SAFETY INSTRUCTIONS

- Read carefully the Safety information for IoT SENSOR before operating the device and observe it during use!
- Installation, electrical connection and commissioning should only be performed by qualified personnel
in accordance with applicable regulations and standards
- Devices contain electronic components, it needs to liquidate them according to currently valid conditions.
- To complement the information in this data sheet read the manuals and other documentation, which are
available in the Download section for a particular device at
Specifications are subject to change without notice.
W0810P • W0832P • W0854P • W0870P • W3810P • W3811P
Construction
Internal temperature sensor
Internal temperature sensor and connectors for two external Pt1000/E
probe
Internal temperature sensor and pulse counter
Internal temperature sensor and input for dc voltage ± 30V
Internal temperature and relative humidity sensor
Connector for external Digi/E probe connection
T...temperature, RH...relative humidity, U...dc voltage, DP...dew point temperature, BIN ... two-state quantity
and follow the instructions in the COMET Cloud registration document that you received with your
www.cometsystem.com
IoT Sensor power for the SIGFOX network
www.cometsystem.com
QUICK START MANUAL
IE-WFS-N-Wx8xxPower-02
