- Page 1 Instructions for use W0810P W0832P W0870P W3810P W3811P Temperature, relative humidity and voltage transmitters for the SIGFOX network...
- Page 2 © Copyright: COMET SYSTEM, s.r.o. This manual is forbidden to copy and make changes of any nature without the express consent of COMET SYSTEM, s.r.o. All rights reserved. COMET SYSTEM, s.r.o. constantly developing and improving its products. Therefore, it reserves the right to make technical changes to the device / product without prior notice.
-
Page 3: Table Of Contents
Content CONTENT ....................3 INTRODUCTION ..................4 SAFETY PRECAUTIONS AND PROHIBITED HANDLING......5 INSTALLATION ..................6 Mounting ..................6 Switching the device on ..............8 Displaying the device data ............8 Device usage and settings ............9 Alarm functions ................11 MANUFACTURED MODELS .............. -
Page 4: Introduction
Introduction The Sigfox network is used to transmit very short data messages and is optimized for low power consumption. It operates in the unlicensed radio band, which brings cheaper traffic, but also legislative restrictions - messages can not be sent faster than with a 10 minute interval. Ideal applications for transmitters working in the Sigfox network are those where it is sufficient sending measured values with longer intervals (eg 1 h or longer). -
Page 5: Safety Precautions And Prohibited Handling
Safety Precautions and Prohibited Handling Read the following safety precautions carefully before using the appliance, and keep it in mind during use! • The device includes a radio transmitter operating in the non-license frequency band with the power specified in the Technical Parameters. This band and performance are used in the countries of the European Union. -
Page 6: Installation
Installation Installation, commissioning and maintenance must only be carried out by a qualified person in accordance with applicable regulations and standards. Mounting For the optimum operation of the Wx8xxP Series, it is necessary to ensure their vertical position. Models without external probes or sensors may loosely stand on their bottom base as required, other... - Page 7 Optimal positioning of the transmitter in terms of radio range: All materials absorb radio waves if they must pass through them. The most significant in terms of radio wave propagation are metal objects, concrete, reinforced concrete and walls. If you install the device at a greater distance from the base station or in locations where the radio signal difficult to penetrates, observe the following recommendations: •...
-
Page 8: Switching The Device On
Switching the device on The device is supplied with installed battery, but in off state. To turn on: • Unscrew the four screws at the corners of the box and remove the cover. Avoid damaging the light guide that is part of the cover. •... -
Page 9: Device Usage And Settings
Cloud is an internet storage of data. You need a PC with internet connection and a web browser to work with. Navigate to the cloud address you use and sign in to your account - if you use COMET Cloud by a transmitter manufacturer, enter www.cometsystem.cloud... - Page 10 The function can only be used once every 24 hours. If you use COMET Cloud and you want to be informed about the change of alarm status, eg by e-mail, it is necessary to set at least one alarm profile correctly.
-
Page 11: Alarm Functions
Alarm functions The transmitter sends the measured values in regular messages, according to the set sending interval. In addition, the transmitter can also send extraordinary alarm messages when a new alarm is generated on a tracked channel or the alarm in progress is extinguished. This feature allows you to extend the battery life by setting a longer sending interval for regular messages, and the user is informed about changes in the alarm status by extraordinary messages according to the current situation. - Page 12 Examples of sent alarm messages triggered by changes in the measured value (eg temperature) Device configuration: - sending interval: 30 min - alarm for channel teparature: ON - alarm will be activated if: value is greater than limit - limit of alarm: any value - delay of alarm: none - hysteresis: 0 °C After a new alarm is triggered, an extraordinary alarm message is sent...
-
Page 13: Manufactured Models
Manufactured models COMET's Wx8xxP transmitters differ in the type of measured quantities (temperature, relative humidity, DC voltage) and the location of the sensors (compact design with internal sensors or external probes on the cable). The enclosure covers electronic circuits, internal sensors, and a battery. - Page 14 The input can also be used to connect sensors of various quantities with a standard output, eg 0-10 V. In the COMET Cloud (after entering the conversion relationship) the measured voltage signal is recalculated and displayed directly in the values of the measured quantity.
- Page 15 Digi/E probes The transmitter measures the temperature, relative humidity and dew point temperature from the COMET Digi/E external probe (the probe is not part of the instrument). Response to jump-change of temperature and relative humidity is significantly faster than models with internal sensor.
-
Page 16: Application Notes
Application notes Operation of transmitter in various applications____________ Prior to commissioning, it is first necessary to assess whether its use is appropriate for the purpose, to determine its optimum setting and, if it is part of a larger measuring system, to prepare a metrological and functional control. -
Page 17: Operating And Maintenance Recommendations
Problems with measurement accuracy ___________________ Incorrect measured values of temperature and relative humidity are most often caused by inadequate probe position or measurement methodology. Some notes on this issue are listed in the chapter Operation of transmitter in various applications. Another group of problems are random peaks in the measured values. - Page 18 In this case, it is not necessary to change the battery. A critically weak battery that can fail at any time is indicated by a blank battery symbol in the COMET cloud and on the front panel of the device by double flashing of the LED with an interval of 10 s.
- Page 19 Service Recommendations ____________________________ Technical support and service are provided by the distributor of this device. Contact is provided in the warranty sheet supplied with the device. WARNING - Improper handling or use of the device results in a loss of warranty! End of operation ____________________________________...
-
Page 20: Technical Parameters
Technical parameters Power supply The device is powered by an internal lithium battery, accessible after unscrewing the cover (see the section How to replace the battery). Power batteries __________________________________ Battery type: Lithium battery 3.6 V, C size, 8500 mAh Recommended type: Tadiran SL-2770/S, 3.6 V, 8500mAh Battery life: Message sending interval... -
Page 21: Radio Part
Radio part Working frequency: Transmission is in the band 868.130 MHz Reception is in the band 869.525 MHz Maximum transmission power: 25 mW (14 dBm) Antenna: Internal, gain 2 dBi Minimum receiver sensitivity: -127 dBm @600bps, GFSK Sigfox radiation class: Radio configuration zone: Typical range from base station: 50 km in open field, 3 km in urban area... -
Page 22: Mechanical Properties
190 g W0832P 190 g W0870P 250 g (including cable) Case material: Protection: W0810P, W0832P, W0870P, W3811P: IP65 W3810P: IP65, sensors under the cap IP40 Transmitter Input Parameters W0810P________________________________________ Measured variable: Temperature from the built-in sensor Range: (-30 to +60) °C Accuracy: ±... - Page 23 0.1 °C Recommended calibration interval: 2 years W0832P________________________________________ Measured variable: 1 x internal temperature (input No. 3) 2 x temperature from external probe COMET Pt1000/E Range: (30 až +60) °C Temperature internal: (-200 až +260) °C, Temperature external: sensor Pt1000/3850 ppm Accuracy of internal sensor: ±...
- Page 24 W0870P________________________________________ Measured variables: 1x temperature from the built-in sensor 2x voltage input Range: Temperature: (-30 to +60) °C Voltage: (-30 to +30) V DC Accuracy: Temperature: ± 0.4 °C Voltage: ± 0.03 V Response time of internal sensor: t90 < 10 min (temperature change 20 °C, air flow approx.
- Page 25 Range: Temperature: (-30 to +60) °C Relative humidity: (0 to 100) %RH without permanent condensation Dew point temperature: -60 to +60 °C Accuracy: Temperature: ± 0.4 °C Relative humidity: - sensor accuracy ± 1.8 %RV (at 23 °C in the range of 0 to 90 %RV) <...
-
Page 26: Dimensional Drawings
Dimensional drawings W0810P W3811P ie-wfs-Wx8xxPower-01... - Page 27 W0832P W3810P ie-wfs-Wx8xxPower-01...
-
Page 28: Declaration Of Conformity
W0870P Declaration of Conformity The transmitter complies with the requirements of Directive 2014/35 / EU. The original Declaration of Conformity can be found at www.cometsystem.com. ie-wfs-Wx8xxPower-01... -
Page 29: Appendices
Appendices Appendix 1: Connecting the Pt1000/E probe connector Appendix 2: Connection of the Digi/E probe connector Appendix 3: Accuracy of dewpoint temperature measurement ie-wfs-Wx8xxPower-01... - Page 30 Appendix 4: W0870P input wiring details ie-wfs-Wx8xxPower-01...
