Make sure all propellers are in good condition before each flight. DO NOT use aged, chipped, or
broken propellers.
Stay away from the rotating propellers and motors to avoid injuries.
Place the aircraft correctly when storing. It is recommended to use a propeller holder to fix the
propellers. DO NOT squeeze or bend the propellers during transportation or storage.
Make sure the motors are mounted securely and rotating smoothly. Land the aircraft immediately if a
motor is stuck and unable to rotate freely.
DO NOT attempt to modify the structure of the motors.
DO NOT touch or let your hands or body come in contact with the motors after flight as they may be
hot.
DO NOT block any of the ventilation holes on the motors or the body of the aircraft.
Make sure the ESCs sound normal when powered on.
Intelligent Flight Battery
The DJI Mini 2 Intelligent Flight Battery is a 7.7 V, 2250 mAh battery with smart charging and discharging
functionality.
Battery Features
1. Balanced Charging: during charging, the voltages of the battery cells are automatically balanced.
2. Auto-Discharging Function: to prevent swelling, the battery automatically discharges to approx. 96%
of the battery level when it is idle for one day, and automatically discharges to approx. 72% of the
battery level when it is idle for nine days. It is normal to feel moderate heat being emitted from the
battery during the discharging process.
3. Overcharge Protection: the battery stops charging automatically once fully charged.
4. Temperature Detection: To prevent damage, the battery only charges when the temperature is
between 5° and 40° C (41° and 104° F). Charging stops automatically if the temperature of the
battery exceeds 50° C (122° F) during the charging process.
5. Overcurrent Protection: the battery stops charging if an excess current is detected.
6. Over-discharge Protection: discharging stops automatically to prevent excess discharge when the
battery is not in flight use. Over-discharge protection is not enabled when the battery is in flight use.
7. Short Circuit Protection: the power supply is automatically cut if a short circuit is detected.
8. Battery Cell Damage Protection: DJI Fly displays a warning prompt when a damaged battery cell is
detected.
9. Hibernation Mode: if the battery cell voltage is lower than 3.0 V or the battery level is less than 10%,
the battery enters Hibernation mode to prevent over-discharge. Charge the battery to wake it from
hibernation.
10. Communication: information about the voltage, capacity, and current of the battery is transmitted to
the aircraft.
DJI Mini 2 User Manual
©
2021 DJI All Rights Reserved.
21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dji Mini 2

Summary of Contents for dji Mini 2

  • Page 1 DJI Mini 2 User Manual Make sure all propellers are in good condition before each flight. DO NOT use aged, chipped, or broken propellers. Stay away from the rotating propellers and motors to avoid injuries. Place the aircraft correctly when storing. It is recommended to use a propeller holder to fix the propellers. DO NOT squeeze or bend the propellers during transportation or storage. Make sure the motors are mounted securely and rotating smoothly. Land the aircraft immediately if a motor is stuck and unable to rotate freely. DO NOT attempt to modify the structure of the motors. DO NOT touch or let your hands or body come in contact with the motors after flight as they may be hot. DO NOT block any of the ventilation holes on the motors or the body of the aircraft. Make sure the ESCs sound normal when powered on. Intelligent Flight Battery The DJI Mini 2 Intelligent Flight Battery is a 7.7 V, 2250 mAh battery with smart charging and discharging functionality. Battery Features 1. Balanced Charging: during charging, the voltages of the battery cells are automatically balanced.

  • Page 2: Checking Battery Level

    DJI Mini 2 User Manual Refer to the DJI Mini 2 Disclaimer and Safety Guidelines and the stickers on the battery before use. Users take full responsibility for all usage and operations. Specifications of the Intelligent Flight Battery for the Japanese version are different. Refer to the Specifications section for more information. The battery features are the same for all versions of the DJI Mini 2 Intelligent Flight Battery. Using the Battery Checking Battery Level Press the power button once to check the battery level. LED1 LED2 LED3 LED4 Power Button Battery Level LEDs The battery level indicators display the power level of the flight battery during charging and discharging. The statuses of the indicator are defined as follows: LED is on.
  • Page 3 DJI Mini 2 User Manual to 41° F). It is recommended to hover the aircraft in place for a while to heat the battery. Make sure to fully charge the battery before takeoff. 2. To ensure the optimal performance of the battery, keep the battery temperature above 20° C (68° F). 3. The reduced battery capacity in low-temperature environments reduces the wind speed resistance performance of the aircraft. Fly with caution. 4. Fly with extra caution at high sea levels. In cold environments, insert the battery into the battery compartment and turn on the aircraft to warm up before taking off. Charging the Battery Fully charge the Intelligent Flight Battery before using for the first time. 1. Connect the USB charger to an AC power supply (100-240V, 50/60 Hz). Use a power adapter if necessary. 2. Attach the aircraft to the USB charger.

  • Page 4: Installing/Removing The Battery

    DJI Mini 2 User Manual The table below shows the battery level during charging. LED1 LED2 LED3 LED4 Battery Level 0% < battery level ≤ 50% 50% < battery level ≤ 75% 75% < battery level < 100% Fully charged The blinking frequency of the battery level LEDs will be different when using different USB chargers. If the charging speed is fast, the battery level LEDs will blink quickly. If the charging speed is extremely slow, the battery level LEDs will blink slowly (once every two seconds). It is recommended to change the USB-C cable or USB charger. If the battery is not correctly inserted into the aircraft, LED 3 and 4 blink simultaneously. Insert the Intelligent Flight Battery again and make sure that it is securely mounted. The four LEDs blink simultaneously to indicate the battery is damaged. Battery Protection Mechanisms The battery LED indicators can display battery protection notifications triggered by abnormal charging conditions. Battery Protection Mechanisms LED1 LED2 LED3 LED4 Blinking Pattern...

  • Page 5: Gimbal And Camera

    -90° Use the gimbal dial on the remote controller to control the tilt of the camera. Alternatively, enter the camera view in DJI Fly. Press the screen until a circle appears and drag the circle up and down to control the tilt of the camera.
  • Page 6 Do not remove the microSD card from the aircraft while it is powered on. Otherwise, the microSD card may be damaged. To ensure the stability of the camera system, single video recordings are limited to 30 minutes. Check camera settings before use to make sure the configurations are correct. Before shooting important photos or videos, shoot a few images to test the camera is operating correctly. Photos or videos cannot be transmitted from the microSD card in the aircraft using DJI Fly if the aircraft is powered off. Make sure to power off the aircraft correctly. Otherwise, the camera parameters will not be saved and any recorded videos may be damaged. DJI is not responsible for any failure of an image or video to be recorded or having been recorded in a way that is not machine-readable. © 2021 DJI All Rights Reserved.

  • Page 7: Remote Controller

    Remote Controller This section describes the features of the remote controller and includes instructions for controlling the aircraft and the camera. © 2021 DJI All Rights Reserved.

  • Page 8: Remote Controller Profile

    Android devices. For iOS devices, first make sure that charging is enabled in DJI Fly. Charging for iOS devices is disabled by default and needs to be enabled each time the remote controller is powered on. Compliance Version: The remote controller is compliant with local regulations. Control Stick Mode: The control stick mode determines the function of each control stick movement. Three pre-programmed modes (Mode 1, Mode 2, and Mode 3) are available and custom modes can be configured in DJI Fly. The default mode is Mode 2. Using the Remote Controller Powering On/Off Press the power button once to check the current battery level. If the battery level is too low, recharge before use. Press once, then press again and hold to power the remote controller on or off. Charging the Battery Use a USB-C cable to connect the USB charger to the USB-C port of the remote controller. It takes approx. four hours to fully charge the remote controller. Controlling the Gimbal and Camera 1. Shutter/Record Button: press once to take a photo or to start or stop recording. 2. Photo/Video Toggle: press once to switch between photo and video mode. © 2021 DJI All Rights Reserved.

  • Page 9: Controlling The Aircraft

    DJI Mini 2 User Manual 3. Gimbal Dial: use to control the tilt of the gimbal. 4. Press and hold the customizable button in order to be able to use the gimbal dial to adjust the zoom in video mode. Gimbal Dial Shutter/Record Button Customizable Button Photo/Video Toggle Controlling the Aircraft The control sticks control the orientation (pan), forward/backward movement (pitch), altitude (throttle), and left/right movement (roll) of the aircraft. The control stick mode determines the function of each control stick movement. Left Stick Right Stick Mode 1...
  • Page 10 DJI Mini 2 User Manual Three preprogrammed modes (Mode 1, Mode 2, and Mode 3) are available and custom modes can be configured in DJI Fly. The default mode is Mode 2. The figure below explains how to use each control stick, using Mode 2 as an example. Stick Neutral/Center Point: Control sticks are in the center position. Moving the control stick: The control stick is pushed away from the center position. Remote Controller Aircraft Remarks (Mode 2) Indicates Nose Direction) Throttle Stick: Moving the left stick up or down changes the altitude of the aircraft. Push the stick up to ascend and down to descend. The more the stick is pushed away from the center position, the faster the aircraft will change altitude. Push the stick gently to prevent sudden and unexpected changes in altitude.
  • Page 11 Flight Pause/RTH Button Press once to make the aircraft brake and hover in place. If the aircraft is performing a QuickShot, RTH, or auto landing, press once to exit the procedure before braking. Press and hold the RTH button until the remote controller beeps to start RTH. Press this button again to cancel RTH and regain control of the aircraft. Refer to the Return to Home section for more information about RTH. Customizable Button To customize the function of this button, go to System Settings in DJI Fly and select Control. Customizable functions include recentering the gimbal and toggling between the map and live view. Remote Controller Alert The remote controller sounds an alert during RTH. The alert cannot be cancelled. The remote controller sounds an alert when the battery level is low (6% to 15%). A low battery alert level can be cancelled by pressing the power button. A critical battery level alert (less than 5%), however, cannot be cancelled. © 2021 DJI All Rights Reserved.

  • Page 12: Optimal Transmission Zone

    DJI Mini 2 User Manual Optimal Transmission Zone The signal between the aircraft and the remote controller is most reliable when the antennas are positioned in relation to the aircraft as depicted below. Weak Strong Weak Optimal Transmission Zone Linking the Remote Controller The remote controller is linked to the aircraft before delivery. Linking is only required when using a new remote controller for the first time. Follow these steps to link a new remote controller: 1. Power on the remote controller and the aircraft. 2. Launch DJI Fly. 3. In camera view, tap and select Control and Pair to Aircraft (Link). The remote controller will beep...
  • Page 13 DJI Fly App This section introduces the main functions of the DJI Fly app. © 2021 DJI All Rights Reserved.
  • Page 14 Create contains Templates and Pro. Templates automatically edit imported footage. Pro allows users to edit footage manually. SkyPixel Enter SkyPixel to view videos and photos shared by users. Profile View the account information, flight records, DJI forum, online store, Find My Drone feature, and other settings. Trimmed Download is not supported in the following situations: The duration of the video is less than 5 seconds. There is no cached video in the mobile device corresponding to the original video. Make sure to download using the mobile device that was used for shooting. © 2021 DJI All Rights Reserved.

  • Page 15: Camera View

    DJI Mini 2 User Manual The difference in duration between the cached video in the mobile device and the original video from the microSD card of the aircraft is too large. This may occur due to the following reasons: a) Exited DJI Fly while recording such as to answer a phone call or to reply to a message. b) Video transmission disconnected while recording. Camera View N Mode In Flight 7.9m/s 1.6m/s 4K 30 4K 30 625m 1:30:26 +1.0 +1.0 1. Flight Mode N Mode: displays the current flight mode. 2. System Status Bar In Flight: indicates the aircraft flight status and displays various warning messages. Tap to view more information when a warning prompt appears.
  • Page 16 DJI Mini 2 User Manual quickly. “Anytime” indicates that the motors can be stopped mid-flight anytime once the user performs a combination stick command (CSC). Stopping the motors mid-flight will cause the aircraft to crash. If accessories such as the propeller guard are mounted to the aircraft, it is recommended to enable Payload mode for enhanced safety. After takeoff, Payload mode is enabled automatically if a payload is detected. The flight performance will be reduced accordingly when flying with any payload. Note that the max service ceiling above sea level is 2,000 m and the max flight speed and flight range are limited when Payload mode is enabled. The Find My Drone feature helps to find the location of the aircraft on the ground. Control Aircraft Settings: tap to set the measurement system. Gimbal Settings: tap to set the gimbal mode, allow upward gimbal rotation, recenter the gimbal, and to calibrate the gimbal. Advanced gimbal settings include speed and smoothness for pitch and yaw. Remote Controller Settings: tap to set the function of the customizable button, to calibrate the remote controller, to enable phone charging when an iOS device is connected, and to switch control stick modes.
  • Page 17 DJI Mini 2 User Manual to view the available capacity of the microSD card. 12. Flight Telemetry D 12m, H 6m, 1.6m/s, 1m/s: displays the distance between the aircraft and the Home Point, height from the Home Point, aircraft horizontal speed, and aircraft vertical speed. 13. Attitude Indicator Displays information such as the orientation and tilt angle of the aircraft, position of the remote controller, and position of the Home Point. Aircraft orientation Remote controller position Aircraft tilt angle Home Point Switch to Attitude Switch to minimap Indicator Collapse 14. Auto Takeoff/Landing/RTH / : tap the icon. When the prompt appears, press and hold the button to initiate auto takeoff or landing. Tap to initiate Smart RTH and have the aircraft return to the last recorded Home Point. 15. Back : tap to return to the home screen. Press the screen until a circle appears and drag the circle up and down to control the tilt of the gimbal. Make sure to fully charge your mobile device before launching DJI Fly.
  • Page 18 Flight This section describes safe flight practices and flight restrictions. © 2021 DJI All Rights Reserved.

  • Page 19: Flight Environment Requirements

    Unmanned aerial vehicle (UAV) operators should abide by the regulations from self-regulatory organizations such as the International Civil Aviation Organization, the Federal Aviation Administration, and local aviation authorities. For safety reasons, flight limits are enabled by default to help users operate this aircraft safely and legally. Users can set flight limits on height and distance. Altitude limits, distance limits, and GEO zones function concurrently to manage flight safety when GPS is available. Only altitude can be limited when GPS is unavailable. Flight Altitude and Distance Limits The flight altitude and distance limits can be changed in DJI Fly. Based on these settings, the aircraft will fly in a restricted cylinder as shown below: Max Radius Max Flight Altitude Home Point Height of aircraft when powered on © 2021 DJI All Rights Reserved.

  • Page 20: Aircraft Status Indicator

    DJI Mini 2 User Manual When GPS is available Aircraft Status Flight Limits DJI Fly App Indicator Max Altitude of the aircraft cannot exceed Warning: height limit Altitude the specified value reached Blinks green and red alternatively Max Flight distance must be within the Warning: distance limit Radius max radius reached When GPS is weak Aircraft Status Flight Limits DJI Fly App...

  • Page 21: Pre-Flight Checklist

    2. Make sure the Intelligent Flight Battery and the propellers are mounted securely and the propellers are spread. 3. Make sure the aircraft arms are unfolded. 4. Make sure the gimbal and camera are functioning normally. 5. Make sure that there is nothing obstructing the motors and that they are functioning normally. 6. Make sure that DJI Fly is successfully connected to the aircraft. 7. Make sure that the camera lens and Downward Vision System sensors are clean. 8. Use only genuine DJI parts or parts certified by DJI. Unauthorized parts or parts from non-DJI certified manufacturers may cause system malfunctions and compromise safety. Auto Takeoff/Landing Auto Takeoff Use auto takeoff when the aircraft status indicator blinks green. 1. Launch DJI Fly and enter the camera view. 2. Complete all steps in the pre-flight checklist.
