3. Attaching the Fan Blades (cont.)
4. Remove 1 and loosen 2 screws from the motor assembly.
Locate the adapter plate. Attach the light adapter plate to the
motor assembly by re-attaching the 1 removed and tightening the
2 loosened screws. (Fig. 4)
4. Attach motor assembly to decorative
blade bracket/blades
1. Locate the previously assembled blades and blade bracket.
Lift the motor assembly on to the blade bracket. Attach the
blade holder ring to the blade bracket with the included screws.
(Fig. 4A).

5. Hanging the Fan

1. Take out the set screw located in the hanger ball, lower the
hanger ball and remove the cross pin. Remove the hanger ball from
the hanger ball/ downrod assembly (Fig. 5).
2. Remove the clevis pin and cotter pin, and loosen the two collar
screws from the motor collar (Fig. 5).
3. Carefully feed the motor wires and safety cable up through the
downrod. Thread the downrod into the collar.
4. Align the holes of downrod and collar and insert the cotter pin and
clevis pin. Tighten the two collar screws (Fig. 5).
WARNING:
the screws could result in the fan loosening and possibly falling.
14 Aura Instructions
Use Hardware E.
Failure to properly install the cotter pin and/or tighten
FR-W2303-72L
