Getting Started
Unpacking, general machine precautions, wiring,
installation
Operations & Maintenance Manual
WARNING: FOR YOUR SAFETY READ AND UNDERSTAND THIS MANUAL
PRIOR TO USING THE SAW. REVIEW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS FREQUENTLY.
This manual is provided for your convenience in the use
and care of your saw. These instructions include opera-
tion, precautions, preventative maintenance and other
pertinent data to assist you in assuring long life and de-
pendable service from your saw.
Horizontal Beam Saw
TYPE 3
16" models
20" models
22.5" models
For Serial number 20230350092 forward
(May 2023)
Made in USA
3691-01-03
3691-01-05
3691-01-07
Original Saw Company
465 Third Ave SE
Britt, IA 50423 USA
PH 641-843-3868
