Cole Parmer IBS-200 Manual

Bench scale
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IBS-200 Bench Scale

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IBS-200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cole Parmer IBS-200

Summary of Contents for Cole Parmer IBS-200

  • Page 1 IBS-200 Bench Scale...
  • Page 2 Easy Reference: Model name of the scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place:...

  • Page 3: Table Of Contents

    CONTENTS P.N. 3.02.6.6.15974, Rev A, uly 2022 INTRODUCTION ..................2 SPECIFICATIONS ..................3 SAFETY PRECAUTIONS ................. 3 SET UP ......................4 ASSEMBLING OF SCALE ..............4 WEIGHING ....................4 BEFORE WEIGHING ................4 WEIGHING ....................5 USER FUNCTIONS ................5 5.3.1 PARTS COUNTING FUNCTION ................

  • Page 4: Introduction

    INTRODUCTION • The IS Plus H models are supplied with a power supply adapter, to charge the internal rechargeable battery. • Four models: 3 kg x 0.1g 6 kg x 0.2g 15 kg x 0.5g 30 kg x 1g • Large LCD with backlight •...

  • Page 5: Specifications

    2.0 SPECIFICATIONS IBS-200-3H IBS-200-6H IBS-200-15H IBS-200-30H Model Capacity 15Kg 30Kg Readability 0.1g 0.2g 0.5g Repeatability 0.2g 0.4g Linearity ± 0.2g 0.4g Units kg / g / lb / oz / lb:oz Stabilization time 2 seconds Operating 0º C to 40º C temperature 32º...

  • Page 6: Set Up

    Notice: • Avoid extremes of temperature, do not place in direct sunlight or near air conditioning vents. • Battery should be removed if the scale is not used for a long period of time. • Do not stack material on the scale when it is not in use. •...

  • Page 7: Weighing

    WEIGHING • Press [On/Off] to turn on the scale. The display will show the software revision then show the model “CAP XX”. Then it will begin its self-checking test from 0 to 9. When reading is stable, the display will show ", stable symbol, zero symbol, and the weighing unit used the last time the scale was used.

  • Page 8: Percentage Weighing

    • Press the [Tare/↵] key once the stability indicator comes on to confirm the entered value. The display will show the number of pieces placed on the pan. • If more items are put on the pan, the increased count value will be shown. •...

  • Page 9: Hold Function

    • the scale will show “xxxxx.x” with the ‘HI’ LED lit. Otherwise the scale will show “xxxxx.x” with the ‘OK’ LED lit. • Press the [FUNC/ ↑ ] key to exit and go back to weighing mode. 5.3.4 HOLD FUNCTION •...

  • Page 10: Backlight Setting Mode

    • To continue to other function settings, press [Tare/↵] to confirm the current setting and show the next mode. • The display will then show “BK Off”, “BK AU”, or “BK on” these are the backlight function settings. 6.3 BACKLIGHT SETTING MODE •...

  • Page 11: Check Weighing Function

    6.6 CHECK WEIGHING FUNCTION • Press [FUNC/ ↑ ] to switch on or off this function. • "CHK of”：check weighing function is off. • "CHK on"：check weighing function is enabled. • Press the [Tare/↵] key to confirm and move to the next setting. The calibration mode has been entered when “HOD on”...

  • Page 12: Calibration

    The display will now show the calibration mass expected. ”CAL 01 kg” (or “CAL 01 Lb”). Press the [FUNC/ ↑ ] key to change the calibration values if necessary. Each model has 3 different kg and lb calibration selection values. Calibration selectable values for all model: IBS-200-3H IBS-200-6H IBS-200-15H IBS-200-30H...

  • Page 13: Error Message

    • If it is outside of the previous calibration value by more than 5%, it will show “FAIL L” or “FAIL H” indicating the new calibration weight was too low (FAIL L) or too high (FAIL H) in respect to the previous calibration value. 8.0 ERROR MESSAGE A/D counts are too high --AdO...
  • Page 14 WEEE 2012/19/EU This device may not be disposed of in domestic waste. This also applies to countries outside the EU, per their specific requirements. Disposal of batteries (if fitted) must conform to local laws and restrictions. Cet appareil ne peut être éliminé avec les déchets ménagers. L’élimination de la batterie doit être effectuée conformément aux lois et restrictions locales.
