DO NOT RETURN
TO THE STORE!
If you discover missing or damaged parts,
or if you have questions about the building process,
please reach out to us directly for the fastest service.
24/7 Support
help.backyardproducts.com
Call a Recruiter Today! 734-365-7000
Flexible schedule
*based on number of completed installations
STOP
Answers to frequently
asked questions
Technical assistance and
how-to videos
Submit a help request
Request replacement parts
Did you enjoy building your shed?
JOIN OUR TEAM
AND MAKE UP TO $1,500/WEEK*
No selling,
just building
Business Hours
(734) 242-6900
Monday - Friday ........... 8:00am - 6:00pm EST
Saturday - Sunday .................................Closed
Bonus incentives
available
16904

Advertisement

loading
Need help?

Need help?

Do you have a question about the GABLE 8'x10' and is the answer not in the manual?

Questions and answers

Related Manuals for Handy Home Products GABLE 8'x10'

Summary of Contents for Handy Home Products GABLE 8'x10'

  • Page 1 16904 STOP DO NOT RETURN TO THE STORE! If you discover missing or damaged parts, or if you have questions about the building process, please reach out to us directly for the fastest service. 24/7 Support Business Hours help.backyardproducts.com (734) 242-6900 Answers to frequently Monday - Friday ...
  • Page 2 (This page intentionally left blank.)

  • Page 3: Assembly Manual

    16904 12-20-2022 ASSEMBLY MANUAL GABLE 8' x 10' (244 x 302,8 cm) ACTUAL FLOOR SIZE IS 96 x 120" (243,2 x 302,8 cm) KEEP THIS MANUAL FOR FUTURE REFERENCE I M PO RTANT! READ INSTRUCTIONS THOROUGHLY PRIOR TO BEGINNING ASSEMBLY. BEFORE YOU BEGIN • BUILDING RESTRICTIONS AND APPROVALS Be sure to check local building department and homeowners association for specific restrictions and/ or requirements before building. • ENGINEERED DRAWINGS Contact our Customer Service Team if engineered drawings are needed to pull local permits.
  • Page 4 TOOLS Required Optional Phillips Tool Belt/ Utility Knife Screwdriver Nail Pouch Shingle Blades Drill / Driver 1/8" Drill Bit Tin Snips 1/4" Drill Bit Caulk Gun (for drip edge) 5/16" Drill Bit 1/2" Drill Bit Chalk Line #2 Philips Drive Bit Paint Tools Hammer Nail Gun • gun nails Level Safety Glasses Pencil Ladder Tape Measure Gloves...

  • Page 5: Optional Materials

    ADDITIONAL MATERIALS FOUNDATION OR FLOOR MATERIALS • This shed includes a complete floor. • See the FLOOR LEVELING section on page 7 for recommended methods and suggested materials to properly level your floor, as this will vary depending on your specific site. REINFORCED WOOD FLOOR FRAME (OPTIONAL) IMPORTANT! This floor has been designed for general use. Depending on your specific use you may want to construct a heavy duty floor frame by adding additional floor joists (shown below as shaded). Below is a list of additional materials (not included): 2 x 4 x 8' (5 x 10 x 243,8 cm) Treated Lumber Cut to (2) 2 x 4 x 89-5/8" (5 x 10 x 227,6 cm) ea.

  • Page 6: Parts List

    PARTS IDENTIFICATION AND SIZES Part identification letters WOOD SIZE CONVERSION CHART are stamped on some parts. Nominal Board Size Actual Size Treated lumber is stamped: 2 x 4....1-1/2" x 3-1/2" (3,8 x 8,9 cm) 1 x 4....3/4" x 3-1/2" (1,9 x 8,9 cm) 2 x 3....1-1/2" x 2-1/2" (3,8 x 6,3 cm) Check these locations for 1 x 3....
  • Page 7 PARTS LIST continued... WALL PANELS & DOORS Wall panels are 3/8" (1,0 cm) thick. NOTE: Panel parts are not stamped. 3/8 x 15-7/8 x 72" 3/8 x 23-7/8 x 72" 3/8 x 48 x 72" LEFT DOOR RIGHT DOOR (1 x 40,3 x 182,9 cm) (1 x 68,3 x 182,9 cm) (1 x 121,9 x 182,9 cm) 35-3/4" x 72"...
  • Page 8 PARTS LIST continued... FASTENER/HARDWARE BAG NOTE: x155 1-1/2" (3,8 cm) If you are using a nail gun, nails may be used where screws are x120 2" (5,1 cm) shown for quicker assembly. 3" (7,6 cm) Length of nail must match screw length. 2"...
  • Page 9 COMPONENT SECTION INDEX Description Section Page Floor Walls Wall Tie Plates Strap Ties Rafters Hurricane Ties Gable Units Roof Clips Roof Panels Trim 41-43 Doors Door Hardware Corner Trim Collar Ties Earth Augers Shingles...
  • Page 10 FLOOR LEVELING OPTIONS There are multiple ways to level your floor frame. Our recommended leveling method is shown below. Leveling materials are not included in this kit. PREFERRED METHOD - 4x4 TREATED RUNNERS • 3" Screws angled into 4x4. • (2) at each point frame • and 4x4 touch. 12" (30,5 cm) Measurements to centers of 4x4's. MATERIAL REQUIRED 12" 4 x 4 x 10' (10 x 10 x 304,8 cm) Treated Lumber (30,5 cm) Fasteners for Frame to 4 x 4.
  • Page 11 CONCRETE FOUNDATION If you choose to install your kit on a concrete slab refer to the diagram below. Treated Sill Plate Caulk between sill plate and concrete. 3-1/2" (8,9 cm) 4" (10,2 cm) Building Size Actual Floor Size 120" (305 cm) 8'x 10' (243,8 x 304,8 cm) 10' (295,9 x 235 cm) 96" (243,8 cm) 113" (287 cm) Requires: 2 x 4 x 10' (5,1 x 10,2 x 304,8 cm) MUST be treated lumber.
  • Page 12 FLOOR FRAME PARTS REQUIRED: Look for 3" (7,6 cm) TREATED 2 x 4 x 93" (5,1 x 10,2 x 236,2 cm) Stamp 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm) BEGIN Arrange parts as shown on fl at surface. Measure and mark.
  • Page 13 LEVEL AND SQUARE FLOOR FRAME Before installing fl oor decking, it is important to level and square the fl oor frame. A level and square fl oor frame is required to correctly construct your shed. BEGIN See page 7 for the preferred fl oor leveling method. Use level and check the frame is level before applying fl oor panels. Check for frame squareness by measuring diagonally across corners. If the measurements are the same, the frame is square. The diagonal measurement will be approximately 153-11/16" (390,4 cm). When the frame is level and square, secure one side of frame to the 4x4 runners with one fastener at ends of each runner. Move to the opposite end of the frame. Secure the frame to 4x4 runners with (1) fastener at ends of each runner making sure the frame remains square (Fig. A).
  • Page 14 FLOOR PANELS PARTS REQUIRED: Floor panels are 5/8" (1,6 cm) thick. 2" (5,1 cm) 3/4" GAUGE BLOCK 48" x 96" (121,9 x 243,8 cm) Install all floor panels with the painted grid lines facing up. BEGIN Install (1) 48" x 96" panel on the wall frame, as shown. Use the gauge block to mark the 3/4" side measurement floor joist.
  • Page 15 FLOOR PANELS PARTS REQUIRED: x167 23-7/8" x 96" 2" (5,1 cm) (60,6 x 243,8 cm) 48" x 96" 3/4" GAUGE (121,9 x 243,8 cm) BLOCK Install (1) 48" x 96" panel fl ush to installed panel. Secure with 2" nails spaced 6" apart on edges and 12" apart inside panels. Install (1) 23-7/8" x 96" panel fl ush to installed panel.
  • Page 16 IMPORTANT! Ensure the floor frame is level after installing floor panels. Re-level if needed. We recommend installing Earth Augers to anchor the floor before installing any walls. Auger installation will be much easier by installing at this time. See page 55 for Earth Auger installation instructions. 30" Earth Auger HINT: • The floor should be used as a stable work surface for wall construction. • Organize your assembly procedure during the build process to avoid over-handling of the walls. Back Wall Right Wall Front Wall Left Wall...
  • Page 17 SIDE WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 24" (5,1 x 10,2 x 61 cm) 2 x 4 x 68" (5,1 x 10,2 x 172,7 cm) 2 x 4 x 96" (5,1 x 10,2 x 243,2 cm) Build two identical side walls.
  • Page 18 SIDE WALL FRAME PARTS REQUIRED: 1-1/2" (3,8 cm) H 2.5 Tie Plate Install (4) H 2.5 tie plates at the bottom of four wall studs. Secure with 1-1/2" nails (Fig. A). Nail all nail holes. Fig. A H 2.5 1-1/2" (3,8 cm) Nails Turn wall over to the opposite side before installing wall panels. (H 2.5 tie plates will be on inside of building.)
  • Page 19 SIDE WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 48" x 72" (121,9 x 213,4 cm) Install all panels with the primed side facing up. Install (1) 48" x 72" panel on the wall frame, as shown. Use the gauge block to mark the 3/4" side measurement on the wall stud. Secure panel with (2) 2" nails in the corners (Fig. A). Move to the opposite end.
  • Page 20 SIDE WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 23-7/8 x 72" 48 x 72" (68,3 x 182,9 cm) (121,9 x 213,4 cm) Install (1) 48" x 72" panel fi rst. Second, install the 23-7/8" x 72" panel. Secure with 2" nails spaced 6" apart on edges and 12" apart inside panel. Flush 6"...
  • Page 21 BACK WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 68" (5,1 x 10,2 x 172,7 cm) 2 x 4 x 89" (5,1 x 10,2 x 226,1 cm) BEGIN Arrange parts on edge on floor. Measure and mark. Secure with (2) 3" nails at each mark. 89" (226,1 cm) 68 1/2"...
  • Page 22 BACK WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 48" x 72" (121,9 x 182,9 cm) Install all panels with the primed side facing up. Install (2) 48" x 72" panels, as shown. Secure panels with 2" nails spaced 6" apart along edges and 12" apart on inside of panel. BEGIN HERE 3-1/2"...
  • Page 23 FRONT WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 12-1/2" (5,1 x 10,2 x 31,8 cm) 2 x 4 x 68" (5,1 x 10,2 x 172,7 cm) 2 x 4 x 89" (5 x 10,2 x 226,1 cm) BEGIN Arrange parts on edge on floor. Measure and mark. HINT: For easier nailing Secure with (2) 3" nails at each conjunction and as shown. stand on frame. 89" (226,1 cm) 12-1/2" 12-1/2"...
  • Page 24 FRONT WALL FRAME PARTS REQUIRED: 1-1/2" (3,8 cm) LSTA9 Strap Tie Install (4) LSTA9 strap ties centered at the top and bottom of front inner door studs, as shown. Secure with 1-1/2" nails (Fig. A). All holes must be nailed. Flush Strap Ties to frame. 1-1/2" (3,8 cm) Nails LSTA9 Strap Tie Turn wall to the opposite side and secure tie straps on opposite side of wall.

  • Page 25: Front Wall

    FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 72" (5,1 x 7,6 x 182,9 cm) TEMPORARY SUPPORT 2" (5,1 cm) 15-7/8 x 72" (40,3 x 182,9 cm) Install all panels with the primed side facing up. Install (2) 15-7/8" x 72" panels onto wall frame, as shown. Secure panel with 2"...
  • Page 26 RIGHT SIDE WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 72" (5,1 x 7,6 x 182,9 cm) TEMPORARY SUPPORT 3" (7,6 cm) 2" (5,1 cm) BEGIN Center right side wall on fl oor. 1" (2,5 cm) overlap is to the bottom. Install OY as a temporary brace. Secure with (2) 3"...

  • Page 27: Back Wall Installation

    BACK WALL INSTALLATION PARTS REQUIRED 2" (5,1 cm) 3" (7,6 cm) 2" (5,1 cm) 1-1/2" (3,8 cm) 3" (7,6 cm) Fig. B BEGIN Secure back wall with (1) 2" screw into side wall bottom plate (Fig. A) and top plate (Fig. B). 2" (5,1 cm) Screw Flush ENSURE PANEL CORNERS ARE FLUSH. 2" (5,1 cm) Screw Fig. A...
  • Page 28 LEFT SIDE WALL INSTALLATION PARTS REQUIRED: 2" (5,1 cm) BEGIN Install left wall, securing with (1) 2" screw through back wall panel into side wall bottom and top plates (Fig. B, Fig. A). Fig. B 2" (5,1 cm) Screw ENSURE PANEL CORNERS ARE FLUSH. Flush Fig. A 2" (5,1 cm) Screw...
  • Page 29 LEFT SIDE WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) 3" (7,6 cm) 1-1/2" (3,8 cm) Nail side wall panels to fl oor frame with 2" nails spaced 6" apart. Angle nails into fl oor frame (Fig. C). 3" (7,6 cm) Secure wall bottom plates to fl oor Nails with 3" nails (Fig. C). 6" (15,2 cm) Nail 2" nails fi rst. 3" (7,6 cm) 2" (5,1 cm) Nails...
  • Page 30 FRONT WALL INSTALLATION PARTS REQUIRED 2" (5,1 cm) 3" (7,6 cm) 2" (5,1 cm) 3" (7,6 cm) 1-1/2" (3,8 cm) 2" (5,1 cm) Screw Fig. B BEGIN Secure front wall with 2" screws into top and bottom plates (Fig. A, Fig. B). Flush ENSURE PANEL CORNERS ARE FLUSH. Flush 2" (5,1 cm) Screw Nail panels to fl oor with 2" nails spaced 6"...
  • Page 31 FRONT WALL HEADER PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 76" (5,1 x 7,6 x 193 cm) ¸ BEGIN Center PBZ on SZ fl ush to edge of panel (Fig. A). Fig. A Secure with (5) 3" screws spaced evenly, as shown. Flush Angle screws into header. Flush to panel edge Front wall...
  • Page 32 RAFTERS PARTS REQUIRED: x120 TEMPORARY SUPPORT 2" (5,1 cm) OSB OR WOOD GRAIN 2 x 4 x 21" (5,1 x 10,2 x 53,3 cm) 6 x 24" (15,2 x 61 cm) 2 x 4 x 54-1/16" (5,1 x 10,2 x 137,3 cm) You will build Six assemblies. (4) with two gussets, and (2) with one gusset. ¸ BEGIN Place two rafter halves fl ush in corners of 2nd studs from back wall and fl ush to side wall panels. Place temporary support SBA beneath rafters at peak. 2nd Rafter 2nd Rafter BACK WALL...
  • Page 33 RAFTER INSTALLATION PARTS REQUIRED: 3" (7,6 cm) Preassembled (1) GUSSET Preassembled ¸ BEGIN Secure rafters to top plate with (2) 3" screws in each rafter end (Fig. A, Fig. B). - Note single-gusset rafters at front & back walls with gusset facing inward. Secure single-gusset rafters to top plate with (1) 3" screw in each rafter end (Fig. C). MEASUREMENTS ARE TO CENTER OF RAFTER Fig. A...
  • Page 34 RAFTER INSTALLATION PARTS REQUIRED: 1-1/2" (3,8 cm) H 1 Hurricane Tie Working inside, install (8) H1 Hurricane Ties at the base of the four inner rafters. Ensure H1 ties are fl ush up to bottom of rafter. Secure with 1-1/2" nails (Fig. A). Fig. A 1-1/2" (3,8 cm) Nails Flush Hurricane Tie Repeat to install (4) H1 Hurricane Ties on opposite side. FINISH Your rafters and hurricane ties are now installed.
  • Page 35 BACK GABLE UNIT PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 4 x 21" (5,1 x 10,2 x 53,3 cm) Install all panels with the primed side facing up. BEGIN Place left gable panel on SBA as shown. Secure with 1-1/2" nails as shown. 1-3/4" (4,5 cm) 1-1/2" (3,8 cm) Nails SBA (on fl at) 1-3/8"...
  • Page 36 BACK GABLE UNIT INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 1-1/2" (3,8 cm) Back Gable Unit ENSURE GABLE IS CENTERED ON WALL BEFORE NAILING. BEGIN Measure 1-3/8" down from top plate and mark at each side, as shown. Set gable unit on top plate. Secure with (1) 1-1/2" nail on each side. Continue nailing lower edge of panels into top plate with 1-1/2" nails spaced 6" apart. Secure panels to rafter with 1-1/2" nails spaced 6" apart. 6" (15,2 cm) 1-3/8" 1-3/8" NAIL FIRST NAIL FIRST (3,5 cm) 1-1/2" (3,5 cm) 1-1/2" (3,8 cm) Measure and (3,8 cm) Measure and Mark Mark Fig. A 3" (7,6 cm) Screws Working inside, secure gable unit with (2) 3"...
  • Page 37 FRONT GABLE UNIT PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 4 x 4-7/8" (5,1 x 10,2 x 12,4 cm) Install all panels with the primed side facing up. BEGIN Install left gable panel on parts CLA, as shown. Secure with 1-1/2" nails, as shown. 1-3/4" (4,4 cm) 1-1/2" (3,8 cm) Nails CLA (on fl at) Flush 1-3/8" (3,5 cm) 1-3/4" (4,4 cm) Install right gable panel fl ush to left panel. Secure with 1-1/2" nails, as shown. 1-1/2" (3,8 cm) Nails Flush...
  • Page 38 FRONT GABLE UNIT INSTALLATION PARTS REQUIRED: 1-1/2" (3,8 cm) 3" (7,6 cm) Front Gable Unit ENSURE GABLE IS CENTERED ON WALL BEFORE NAILING. BEGIN Measure 1-3/8" down from top plate and mark at each side as shown. Set gable unit on wall header. Secure with (1) 1-1/2" nail on each side. Secuer lower edge of panels to top plate and header with 1-1/2" nails spaced 6" apart. Secure panels to rafter with 1-1/2" nails spaced 6" apart. 6" (15,2 cm) 1-3/8" (3,5 cm) 1-3/8" (3,5 cm) Measure and Measure and NAIL FIRST NAIL FIRST Mark Mark 1-1/2" 1-1/2" (3,8 cm) (3,8 cm) Fig. A 3"...
  • Page 39 ROOF PANELS ROOF CLIP INSTALLATION INSTRUCTIONS During installation of roof panels, it is important to install Roof Clips between all panels. Roof Clip PSCL7/16" Install all roof panels with the rough side facing up (painted grid lines side). Fig. A Install PSCL7/16" roof clips in locations shown. Install roof clips with narrow tabs up. Ensure roof clips are oriented as shown in Fig. A. Install roof clips on all seams.
  • Page 40 ROOF PANELS PARTS REQUIRED: 7/16 x 9-3/4 x x " 23-7/8 (1,1 x 24,8 x 60,6 cm) 2" (5,1 cm) 7/16 x 9-3/4 x 96" (1,1 x 24,8 x 243,2 cm) 7/16 x 23-7/8 x 48" 3/4" GAUGE (1,1 x 60,6 x 121,9 cm) BLOCK 7/16 x 48 x 96" (1,1 x 121,9 x 243,2 cm) Install all roof panels with the rough side facing up (painted grid lines side).
  • Page 41 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) Install 9-3/4"x 23-7/8" roof panel flush Flush at peak to installed panel and flush at rafter peak 9-3/4" x 23-7/8" Fig. B (Fig. B). Secure with (2) 2" nails into panel corners, as shown. Two Nails Move to the opposite end of panel. Maintain panel flush at peak (Fig. B). Use GAA gauge block for 3/4" measurement along outside edge of gable panel (Fig. C). Secure panel with (2) 2"...
  • Page 42 ROOF PANELS PARTS REQUIRED: x118 2" (5,1 cm) Roof Clip PSCL7/16" Install PSCL7/16 roof clips between all panels. MEASUREMENTS Maintain spacing between the center BETWEEN RAFTERS To outside of To outside of of the rafters. gable panel gable panel 24-3/4" 24" 24" 24" 24-3/4"...
  • Page 43 GABLE FASCIA - FRONT PARTS REQUIRED: 2" (5,1 cm) 19/32 x 3-1/2 x 58-7/8" (2,5 x 8,9 x 149,5 cm) 19/32 x 3-1/2 x 58-7/8" (2,5 x 8,9 x 149,5 cm) Install all trim boards with the primed side facing out. BEGIN Install BSL and BSR fl ush at rafter peak and fl ush to top of OSB roof panels. Fasten trim with 2" fi nishing nails in pattern shown. Flush at peak 2" (5,1 cm) Finishing Nails Flush to top of OSB Flush to top of OSB roof panels roof panels Repeat steps to install the back gable trim. FINISH Your front and back gable trim is now installed.
  • Page 44 EAVE SOFFIT PARTS REQUIRED: 1-1/4" (3,2 cm) 2 x 3 x 49-1/2" (5,1 x 7,6 x 125,7 cm) 2 x 3 x 72" (5,1 x 7,6 x 182,9 cm) BEGIN Place parts OY and EFC fl ush to bottom of roof overhang and wall panel as shown (Fig. A). Secure with 1-1/4" screws in the pattern shown. 1-1/4" (3,2 cm) Screws Flush 1-1/4" (3,2 cm) Fig. A Screw Flush FINISH You have fi nished installing your eave soffi ts.
  • Page 45 EAVE FASCIA PARTS REQUIRED: 2" (5,1 cm) 2 x 2-1/2 x 28-1/2" (5,1 x 6,3 x 72,4 cm) 19/32 x 2-1/2 x 93" ( 2,5 x 6,3 x 236,2 cm) Install all trim boards with the primed side facing out. ¸ BEGIN Install eave fascia boards ROR and DKB, as shown (Fig. A). Secure with 2" fi nishing nails.
  • Page 46 DOORS PARTS REQUIRED: Temporary Spacer 2" (5,1 cm) 3/8 x 1-3/4 x 71-1/2" (1 x 4,4 x 181,6 cm) 2 x 4 x 72-3/8" (5,1 x 10,2 x 182,9 cm) PVC 35-3/4" x 72" (90,8 x 182,9 cm) Piano Hinge Install right and left door hinges and hinge boards to doors. BEGIN Stand right door on edge, as shown. Measure and mark location from top of door. Install hinge with knuckle facing up.
  • Page 47 DOORS PARTS REQUIRED: 2" (5,1 cm) Stand left door on edge, as shown. Measure and mark location from top of door. Install hinge with knuckle facing up. Secure with (12) 2" screws. Top is stamped TOP Outside Face of Door HINGE SIDE Hinge knuckle in upward position.

  • Page 48: Door Installation

    DOOR INSTALLATION PARTS REQUIRED: 3" (7,6 cm) Temporary Spacer 3/8 x 1-3/4 x 71-1/2" (1 x 4,4 x 181,6 cm) Temporary Support 7/16" BIT (11 mm) 2 x 4 x 72-3/8" (5,1 x 10,2 x 182,9 cm) PVC BEGIN Hold DBA in place, centered over door opening and flush along the upper edge of top plate. Pre-drill four evenly spaced 7/16" screw holes through DBA into header. Mark center of door opening on top plate - this mark will be used later. CENTER CENTER 7/16" (11 mm) Pre-drilled holes H E A D E R T O P...
  • Page 49 DOOR INSTALLATION PARTS REQUIRED: Door - Hinge Board Assembly 3" (7,6 cm) RIGHT Mark the outside center of the door opening. Measure 3/16" either side of the center mark; the 3/16" mark will be the reference mark to align the door edges. Set right door on support DBA and align upper corner to the 3/16" reference mark. Ensure hinge board DBA is flush against wall panel. Secure (1) 3" deck screw into the wall framing (top plate). Install the TOP screw first. CENTER Measure and Mark 3/16"...
  • Page 50 DOOR INSTALLATION PARTS REQUIRED: Door - Hinge Board Assembly 3" (7,6 cm) LEFT Set left door on support DBA and align upper corner to the 3/16" reference mark. Ensure hinge board DBA is flush against wall panel. Secure (1) 3" deck screw into the wall framing (top plate). Install the TOP screw first. CENTER 3/16"...
  • Page 51 DOOR INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 72-3/8" (5,1 x 10,2 x 182,9 cm) PVC 1-1/4" (3,2 cm) 1/2 x 2-7/8 x 68-3/4" (1,3 x 7,3 x 174,6 cm) PVC 7/16" (11 mm) 3" (7,6 cm) Screws Pre-drilled holes Remove temporary support DBA and install it centered over door opening, fl ush on top of hinge boards. Use the four pre-drilled screw holes. Secure with (4) 3" screws. Reinforce hinge boards with (18) 3"...

  • Page 52: Door Hardware

    DOOR HARDWARE PARTS REQUIRED: 1-1/4 (3,2 cm) 3/8" BIT (9,5 mm) ¸ BEGIN Install top spring bolt to the upper end of PVC weatherstrip (Fig. A). Secure with (4) 1-1/4" screws. Mark spring bolt pin location on over door frame. Drill a 1-1/2" deep hole using a 3/8" drill bit. Install bottom spring bolt to the lower end of PVC weatherstrip (Fig. B). Secure with (4) 1-1/4" screws. Mark spring bolt pin location on fl oor. Drill a 1-1/2" deep hole using a 3/8" drill bit. Fig. A 3/8" drill for bolt: 1-1/2" deep. OVER DOOR FRAME 1-3/16" Flush Weatherstrip 1-1/4" (3,2 cm) Fig. B LEFT DOOR 1-1/4" (3,2 cm) Weatherstrip Flush 1-3/16" FLOOR 3/8" drill for bolt: FINISH...
  • Page 53 DOOR HARDWARE PARTS REQUIRED: 3/32" (3 mm) Drill Bit 1" (2,5 cm) 1/2" (13 mm) Drill Bit 1-1/4" (3,2 cm) BEGIN Measure and mark location of hole on outside of right door as shown (Fig. A). Pre-drill hole with 1/4" drill. Re-drill hole with 1/2" drill (Fig. B). Keep drilled hole square. RIGHT DOOR 1-1/2" (3,8 cm) Fig. B 1/2" 1,3 cm 35-3/4" 90 cm SIDE VIEW Secure back plate with 1" screws and handle with 1-1/4" screws as shown. 1" (25 mm) x2 1-1/4" (32 mm) x2...
  • Page 54 CORNER TRIM PARTS REQUIRED: 2" (5,1 cm) 3/8 x 1-3/4 x 71-1/2" (1 x 4,4 x 181,6 cm) BEGIN Front and back 71-1/2" corner trim is fl ush under gable panel (Fig. A) and fl ush along the face of side wall panel. Secure with 2" fi nishing nails, spaced evenly. Install 71-1/2" side corner trim is fl ush under soffi t board and fl ush along edge of front and back corner trim. Secure with 2" fi nishing nails, spaced evenly. Repeat steps to install trim to all four corners. 71-1/2"...
  • Page 55 GABLE VENT, COLLAR TIES and DOOR THRESHOLD PARTS REQUIRED: 2" (5,1 cm) 1 x 4 x 60" (2,5 x 10,2 x 152,4 cm) 63-7/8" Metal Threshold 3/4" (1,9 cm) x11 1" (2,5 cm) Bagged separately / special coating ¸ BEGIN Caulk behind vent fl anges. Install vent in front gable. Secure with 1" screws. Fig. A Flush to roof Install collar tie to the rafter with (3) 2"...
  • Page 56 WALL VENTS PARTS REQUIRED: 1/2" (1,3 cm) 8 x 16" (20,3 x 35,6 cm) You can place your side wall vent on either side of shed ¸ BEGIN Locate and mark for vents in side walls. Install (1) vent near the fl oor and (1) vent near the eave. Caulk behind vent fl anges. Secure with 1/2" screws. Upper Side Wall Vent 3"– 5" (7,6 – 12,7 cm) Caulk 4-1/4"...
  • Page 57 AUGER STAKES PARTS REQUIRED: 5/8" x 2-1/2" (16 mm x 6,3 cm) 30" Earth Auger Lag Screw Flat Washer 1/2" x 2" x 2" Ratchet Handle (13 mm x 50,8 mm) & Socket Large Screwdriver BEGIN After the fl oor is in the fi nal location, install (6) augers as shown, at measured locations. Secure the augers to bond boards with 2-1/2" lag screws and 2" fl at washers (Fig. A). Min. 1-1/4" (3,2 cm) for siding clearance. Fig. A Floor Deck Bond Board 2-1/2"...
  • Page 58 PAINT & CAULK - NOT INCLUDED - • Use acrylic latex caulk that is paintable. Caulk at all horizontal and vertical seams, between the trim and walls, and all around the door trim. • Use a high quality exterior acrylic latex paint. When painting your building, there are a few key areas that can be easily overlooked that must be painted: • Bottom edge of all siding and trim • Inside of doors and all 4 edges Note: Prime all un-primed exterior wood before painting. (Follow directions provided by manufacturer.) ROOF FELT - NOT INCLUDED - • Install felt flush to all roof edges overlapping 3". Use minimal amount of roofing nails to hold in place. OK to overlap at ridge.
  • Page 59 SHINGLES - NOT INCLUDED - • Follow directions provided by manufacturer and these instructions. Familiarize yourself with a 3-Tab Shingle. Notch Notch SHINGLE NAIL PATTERN 1/2" 1" Sealing Strip 1" (1,3 cm) (2,5 cm) (2,5 cm) Half A Rain Slot Full Rain Slot NAILS NEVER DRIVE FASTENERS INTO OR ABOVE SEALING STRIPS. BEGIN Install first starter row upside down and color up with a 1" overhang at back and bottom of roof panel. Use (4) nails per shingle. Starter row must be straight and level all the way across with lower edge of roof deck. NOTE: If you have installed drip edge install shingles flush to drip edge. FRONT OF BACK OF SHED SHED (4) Nails TABS UP 1" (2,5 cm) overhang or...
  • Page 60 SHINGLES continued... Beginning at front of shed, install first row of shingles with notch at 1" past roof edge or flush with drip edge. Roof Deck FRONT OF BACK OF SHED SHED 1" (2,5 cm) Flush with starter row. Notch - or - Drip Edge Flush with starter row. Notch Install second row of shingles flush at top of first row's rain slots. Ensure 1" overhang or flush to drip edge at front, stagger each row. FRONT OF BACK OF SHED SHED 1" (2,5 cm) Notch Flush with rain slots. Flush with rain slots.
  • Page 61 SHINGLES continued... Continue installing rows of shingles to the peak. At the peak make sure there is a maximum of 5" or less to the rain slot, as shown below. If shingles overlap at ridge cut to peak with a utility knife. 5"...
  • Page 62 SHINGLES - RIDGE CAP • You will finish off the top of the roof with a ridge cap made from shingles. BEGIN Cut shingles into THREE pieces. Hint: Use cut-off pieces first. 2" 2" (5 cm) (5 cm 2" 2" 2" 2" (5 cm) (5 cm) (5 cm) (5 cm) Score shingle, then snap-off angled cut. Weather Seal Top of slot. 27 to 29 Note: • You will need about 27 - 29 cut pieces. Pieces Install first ridge cap flush to shingles at front, as shown.
  • Page 63 SHINGLES - RIDGE CAP continued... Continue installing ridge cap to back of roof. Make sure there is 4" between the shingle-color and edge of shingles. 4" (10 cm) Trim cap off fl ush to shingles When you have 4" minimum of shingle color cut one piece to cap your roof. Cut at top of rain slot.
