Mounting
Installation in plastic containers
Please note that the "guided level radar" measurement principle requires a metallic surface at the
process connection!
When installing rod or robe probes in plastic silos, whose silo cover is also made of plastic or silos
with wood cover, the probes must either be mounted in a ≤ DN 50 / 2" metallic flange, or a
metal sheet with diameter ≥ 200 mm must be mounted under the screw-in piece.
10
Levelflex M FMP43 with FOUNDATION Fieldbus
metal sheet or metal flange
silo roof of plastic
or wood
metal sheet or metal flange
Wall thickness for GFK/PP
< 15 mm
L00-FMP4xxxx-17-00-00-en-018
Endress+Hauser
