THE PERFECT BALANCE OF FUNCTION AND STYLE
Freestanding 10kg Heat Pump Tumble Dryer
MHP10SDW
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
LAUNDRY - DISHWASHING - COOKING - COOLING
Installation and Operating Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MHP10SDW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for montpellier MHP10SDW

Summary of Contents for montpellier MHP10SDW

  • Page 1 LAUNDRY - DISHWASHING - COOKING - COOLING Installation and Operating Instructions Freestanding 10kg Heat Pump Tumble Dryer MHP10SDW Please read these instructions carefully before attempting to install or use this appliance. We recommend that you keep these instructions in a safe place for future reference.
  • Page 2 Welcome Thank you for choosing this Montpellier appliance. Our appliances have been designed to provide you with the best combination of style, reliability and performance to give you years of trouble-free use. You may be familiar with a similar product, but please take time to read these instructions carefully before installing or using your appliance to ensure you get the most from your purchase.

  • Page 3: Table Of Contents

    CONTENTS PRIMARY CONSIDERATIONS ................1 1. SAFETY INSTRUCTIONS ................. 4 1.1. Electrical Safety ....................4 1.2. Children's Safety ..................... 5 1.3. Product Safety ....................6 1.4. Correct Use ..................... 8 1.5. Installing On Top Of a Washing Machine............10 2. INSTALLATION ....................11 2.1.
  • Page 4 7. MACHINE SOUND ................... 24 8. TECHNICAL SPECIFICATIONS ..............25 9. TROUBLESHOOTING ..................26 10. AUTOMATIC FAULT WARNINGS AND WHAT TO DO ......... 28 11. ENVIRONMENTAL PROTECTION AND PACKAGING INFORMATION ..29 11.1. Packaging Information ................. 29 12. DESCRIBING THE ENERGY LABEL AND SAVING ENERGY ....29 12.1.

  • Page 5: Primary Considerations

    PRIMARY CONSIDERATIONS • This tumble dryer is intended only for household and indoor use. The warranty will be void in case of commercial use. • Use this product only for laundry with a label that indicates it is suitable for drying. •...
  • Page 6 • This appliance is not a built-in appliance so it must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side of the tumble dryer, in such a way that blocks the full opening of the tumble dryer door.
  • Page 7 • Be careful when carrying the product since it is heavy. Always wear safety gloves. • Do not place the dryer onto the power cable. • Keep pets away from the dryer. • Fabric softeners or similar products should be used in accordance with the manufacturers instructions.

  • Page 8: Safety Instructions

    1. SAFETY INSTRUCTIONS This section contains safety instructions that will help protect you from risk of personal injury or property damage. Failure to follow these instructions will void any warranty. 1.1. Electrical Safety • The appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility.

  • Page 9: Children's Safety

    • The plug socket must be freely accessible at all times before, during and after installation. To avoid the risk or fire or electric shock, do not use extension cords, multi sockets or adapters to connect the dryer to the mains power. 1.2.

  • Page 10: Product Safety

    • Keep packaging material away from children. • Poisoning and irritation may occur if detergent and cleaning materials are consumed or come into contact with the skin and eyes. • Keep cleaning materials out of the reach of children Electrical products are dangerous for children. •...
  • Page 11 • Laundry that has residues of hair sprays, nail polish remover and similar substances. • Laundry on which industrial chemicals have been used for cleaning (such as chemical cleaning). • Laundry that has any kind of foam, sponge, rubber or rubber-like parts or accessories. These include latex foam sponge, shower caps, waterproof fabrics, fitted clothes, and foam pillows.

  • Page 12: Correct Use

    1.4. Correct Use ATTENTION: Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated. ATTENTION: Make sure that pets do not enter the dryer. Check the inside of the dryer before using it.
  • Page 13 • This appliance is designed to be used inside domestic residences only, and should be placed on a straight and stable surface. • Do not lean against or sit on the door of the dryer. The dryer may tip over. ATTENTION: Never use the dryer without a lint filter or with a damaged lint filter.

  • Page 14: Installing On Top Of A Washing Machine

    1.5. Installing On Top Of a Washing Machine ATTENTION: A washing machine cannot be placed on the dryer. Pay attention to the warnings below when installing the dryer on a washing machine. ATTENTION: The dryer can only be placed on washing machines that have a same capacity and above.

  • Page 15: Installation

    2. INSTALLATION 2.2. Adjusting the Feet 2.1. Connection to Water • For the dryer to work with less noise and Outlet (with optional drain vibration, it must be stable and balanced on its feet. Adjust the feed to ensure that hose) the product is balanced.

  • Page 16: Overview

    3. OVERVIEW Drawer Cover Lint filters Type plate Plinth cover Adjustable feet Ventilation grill Loading door Control panel Upper tray EN - 12...

  • Page 17: Preparing The Laundry

    4. PREPARING THE LAUNDRY 4.1. Sorting the Laundry to be Dried Follow the instructions on the labels of the laundry to be dried. Only dry items that have a statement/symbol that indicates "they can be dried in a dryer". • Do not operate the product with load amounts and laundry types other than those given in 4.3.

  • Page 18: Preparing The Laundry To Be Dried

    4.3. Load Capacity IMPORTANT: Delicate fabrics, embroided fabrics, woolen/silk fabrics, Follow the instructions in the "Programme clothes made of delicate and expensive selection and consumption table". (See: fabrics, airtight clothes and tulle curtains 5.2 Programme selection and are not suitable for drying in the dryer. consumption table).

  • Page 19: Using The Tumble Dryer

    5. USING THE TUMBLE DRYER 5.1.2. LED Indicator and Additional Functions 5.1. Control Panel 1. Programme Selection Knob 2. LED indicator and additional functions Display symbols: Time delay indicator 5.1.1. Programme Selection Knob Water tank warning indicator Use the programme selection knob to select the desired drying programme Heat exchanger cleaning warning indicator...

  • Page 20: Programme Selection And Consumption Table

    5.2. Programme Selection and Consumption Table Press the Start/Pause button to start the programme. The Start/Pause LED that indicates that the programme has started and the remaining the of the program is seen on the display. Approximate Washing amount of Duration Programme Load (kg)

  • Page 21: Auxiliary Functions

    5.2.1. Auxiliary Functions The table that summarises the options that can be selected in programmes is given below. Option Description Delicate Drying Delicate fabrics are dried for a longer time at a low temperature. The humidity level obtained after drying can be increased by 3 levels. This way, level of required dryness can be selected.

  • Page 22: Starting The Programme

    5.2.2. Starting the Programme The Start/Pause LED will flash during programme selection. Press the Start/Pause button to start the programme. The Start/Pause LED that indicates that the programme has started and the drying LED will come on. Programme Description This programme dries thick and multi-layer fabrics, such as cotton Cotton Extra Dry towels, bedsheets, pillowcases, bathrobes, at a high temperature to allow you to place them in a closet.

  • Page 23: Selection Stand By

    It turns itself off automatically after a short period of time. www.montpellier-appliances.com/contact- • It is not an adjustable option to be able to have it on or off. • Please do not try to replace or modify the LED Light.
  • Page 24 OPTIONS PROGRAMMES Delay Buzzer Time Drying Child Lock Delicate Anticrease Start Cancel Drying Level Cotton Extra Dry Cotton Cupboard Dry Cotton Iron Dry Synthetics Cupboard Synthetics Iron Dry Delicate (default) Time drying Baby Care Duvet Sport Wool Refresh Refresh Express 34' Shirts 20' Not selectable Selectable...

  • Page 25: Cleaning And Care

    6. CLEANING AND CARE 1. Open the loading door. 2. Pull up the lint filters to remove them IMPORTANT: Do not use industrial both. chemicals to clean your dryer. Do not use a 3. Open the outer filter. dryer that has been cleaned with industrial chemicals.

  • Page 26: Emptying The Water Tank

    6.2. Emptying the Water Tank If the drying process is completed, open the loading door and wait for it to cool down. 1. Pull the drawer cover and carefully take out the tank. 2. Empty the water in the tank. 3.

  • Page 27: Cleaning The Humidity Sensor

    5. Once the exchanger is clean replace the IMPORTANT: CLEAN THE METAL SURFACES OF THE SENSOR 4 TIMES A cover as shown. YEAR. 6. Lock the exchanger cover by turning the IMPORTANT: Do not use metal tools to locking catches in the direction shown with clean the metal surfaces of the sensor.

  • Page 28: Machine Sound

    7. MACHINE SOUND SOURCE OF SOUND DEFINITION Pump Sound Pump is activated when the machine starts to work and during the operation at certain intervals. It is normal to hear pump and water sound during this process. Compressor Sound It is normal to hear a metallic sound from the compressor from time to time while the machine is running.

  • Page 29: Technical Specifications

    8. TECHNICAL SPECIFICATIONS Brand MONTPELLIER Model name MHP10SDW Height Min: 845 mm / Max: 855 mm* Width 596 mm Depth 609 mm Capacity**(max.) 10 kg Net weight 45,3 kg 220-240 V Voltage 1000 W Power *Min. height: Height with the adjustable feet not used. Max. height: Height with the adjustable feet extended to the maximum.

  • Page 30: Troubleshooting

    9. TROUBLESHOOTING Your dryer is fitted with systems that continuously perform checks during the drying process to take the necessary measures and warn you in case of any malfunction. WARNING: If the problem persists even if you have applied the steps in this section, please contact the your dealer or an Authorised Service Provider.
  • Page 31 PROBLEM REASON SOLUTION Check the care labels on the Clothes have shrunk, felted or The programme used might not be laundry items, select a suitable deteriorated. suitable for the type of laundry. programme for the type of laundry. There might be lint accumulated on Clean the inner surfaces of the the inner surfaces of the loading Water leaking from the loading door.

  • Page 32: Automatic Fault Warnings And What To Do

    10. AUTOMATIC FAULT WARNINGS AND WHAT TO DO Your tumble dryer is equipped with a built-in fault detection system, indicated by a combination of flashing operation lights. The most common failure codes are shown below. ERROR CODE SOLUTION Contact the nearest authorised service agent. Empty the water tank, if problem does not solved, E03/ contact the nearest authorised service agent.

  • Page 33: Environmental Protection And Packaging Information

    11. ENVIRONMENTAL 1. Trademark PROTECTION AND 2. Model PACKAGING 3. Energy Class INFORMATION 4. Annual Power Consumption 5. Noise During Drying 11.1. Packaging Information 6. Dry Laundry Capacity The packaging of this product is made 7. Cotton Cupboard Dry Cycle Time of recyclable materials.

  • Page 34: Energy Efficiency

    13. PRODUCT INFORMATION SHEET PRODUCT FICHE Complying Commission Delegated Regulation (EU) No 392/2012 Supplier name or trademark MONTPELLIER Model name MHP10SDW Rated capacity (kg) Type of Tumble Dryer Heat Pump Energy efficiency class Annual Energy Consumption (kWh) Automatic of Non-automatic...
  • Page 35 Your 2 year Manufacturer's guarantee THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS. Your new Montpellier appliance carries a free guarantee which protects you against the cost of repairs during the first 24 months from date of purchase provided that: Any claim is accompanied by evidence of the model reference, model serial number and proof of purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24 months prior to the date of claim.

  • Page 36: Here For You

    Montpellier Domestic Appliances Ltd. Unit 1, Tewkesbury Retail Park, Northway Lane, Tewkesbury, Gloucestershire GL20 8JU www.montpellier-appliances.com The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
