  • Page 1 KVC7000 & KVL8000 series Disassembly procedures...
  • Page 2 Task Slides to Follow PCB: Main PCB 3, 4, 5, 6 Control Knob Assembly: Control knob assembly 3, 4, 5, 6, 7, 8 Hinge Lever / Hinge Lock / Hinge Pin: 3, 4, 5, 6, 7, 8, 9 Body Cover / Head Release Latch: Body cover 3, 4, 5, 6, 7, 8, 9, 10, 12 Head release latch...
  • Page 3 Unfasten the four screws where indicated. Remove the PCB cover.
  • Page 4 Disconnect all of the connectors, which are circled. NOTE: Ensure you take note of how the cables are clamped in the red circles, this is important when reassembling.
  • Page 5 Unfasten the five screws where indicated. Lift off PCB and housing. Remove cable guide & power cable.
  • Page 6 Unfasten the four screws where indicated, and you can then lift off the PCB assembly from it’s housing. Ensure you are using suitable ESD precautions.
  • Page 7 Release the motor cable from the cable guide. This will reveal screw underneath to allow removal of the speed controller.
  • Page 8 To remove the control knob assembly, remove the four TX20 screws indicated. Lift the head up to allow space to push the speed controller out. The control knob assembly can then be removed by feeding it through it’s hole in the pedestal from the inside to the out.
  • Page 9 1. Remove the ‘E’ clip circled from the hinge pin. 2. Then remove the hinge pin by pushing on the shoulder, using a flat bladed screwdriver. As pictured. 3. Once the hinge pin has been removed, the pedestal can be lifted away.
  • Page 10 With the pedestal separated, you can now take out the head release assy and latch assembly. Unfasten the three indicated screws with a yellow arrow to remove the latch assembly. Unfasten indicated screws with a red arrow to remove the head release assy.
  • Page 11 Unfastening the three indicated screws will allow you to lift off (high-speed) spigot, spigot seat plate from the top cover assembly.
  • Page 12 1. Unfasten the four screws to release the body shaped cover. Remove the body shaped cover to allow access to the motor and chassis.
  • Page 13 1. Remove the small screw indicated. 2. Push the air vent away from the machine to release and remove.
  • Page 14 Unfasten the four screws where indicated. This will release the chassis from the body casting. Next remove the body casting.
  • Page 15 1. Remove the planet hub nut. (8mm spanner) and remove the planet hub & cover. 2. Unfasten two TX20 to release the head undercover. 3. Remove head undercover. NOTE – There are wires attached to the head undercover, REMOVE WITH CARE.
  • Page 16 Cut the cable ties that are securing the light guide wires. Make a note of these as during reassembly they will need to be re- cable tied. Remove the head undercover completely. Lift the chassis out of the top casting.
  • Page 17 Unfasten the four screws indicated holding the capacitive button in place. Push from outside to in, to release the button from the casting.
  • Page 18 To remove the motor assembly from the chassis and gearbox assembly: (1) Remove the washer from the small pulley. (2) Lift off the drive belt (3) Lift of the shedder ring (4) Unfasten the three circled motor retaining screws...
  • Page 19 Unfasten the indicated screw to remove the head release latch plate.
  • Page 20 Unfasten the three bolts where indicated, and you can then lift off the gearbox assembly from the chassis.
