Parameter Position
Indicator
present error 0A0
previous error 0A1
clear last error 0A2
reset 0A3
unlock parameter 0A4
protocol+sw-no. 0C2
4) If MODE_BLK refuses to be changed to AUTO, an error is present. Control all parameters, perform the required changes and try again to change MODE_BLK
to AUTO.
Endress+Hauser
11.6

Diagnostic Block

11.6.1 Operation
The diagnostic block contains the error messages of the device. These parameters can also be
addressed by using the VU331 display module. The diagnostic block is opened by clicking on the
"diagnostic" line. Parameter changes from the tool are made off-line while the device is operating.
The changes are downloaded by first setting MODE_BLK = OOS then pressing the WRITE
CHANGES button. Press the READ ALL button to check the values stored in the device. In order
to resume operation, change MODE_BLK to AUTO
11.6.2 Block administration parameters
Parameter
MODE_BLK
TAG_DESC
BLOCK_ERROR
11.6.3 Methods
The FOUNDATION Fieldbus specification provides for the use of so-called methods to simplify the
operation of the device. A method is an interactive sequence of steps that must be followed in order
to obtain a particular function from the device.
The Levelflex M has got the following methods:
• Set to customer default
• Diagnostics
Most of these methods are identical to the respective function group in the operating menu.
A detailed description of them can be found in the BA00245F/00/EN "Description of Instrument
Functions".
11.6.4 Device specific parameters
rel. Variable Name
Index
13 PARACTUALERROR
14 PARLASTERROR
15 PARCLEARLASTERROR
16 PARRESET
17 PAROPERATIONCODE
18 PARPROTSOFTVERSIONSTRING
4)
.
Description
See description in Resource block. The possible operating modes of the Sensor block are:
– AUTO: the block is operating as normal.
– OOS: the block is out of service.
User description of the intended application of the block.
Shows the error status associated with the block components
– Out-of-Service: the block is in OOS mode.
Size Type
[bytes]
2 Unsigned16
2 Unsigned16
1 Unsigned8
2 Unsigned16
2 Unsigned16
16 VisibleString
Appendix
Access Storage Changeable
Class in Mode
RO dynamic Auto, OOS
RO non-vol. Auto, OOS
RW dynamic Auto, OOS
RW dynamic OOS
RW non-vol. OOS
RO const Auto, OOS
103
