Levelflex M FMP43 FOUNDATION Fieldbus
Endress+Hauser
40 Process Connection:
-- Threaded boss --
U1J Thread M24, 316L, install > accessory weld-in adapter
-- Clamp connections --
TCJ Tri-clamp ISO2852 DN25-38 (1 to 1-1/2"), 316L, 3A, EHEDG
TDJ Tri-clamp ISO2852 DN40-51 (2"), 316L, 3A, EHEDG
TFJ Tri-clamp ISO2852 DN70-76.1 (3"), 316L, 3A, EHEDG
-- Hygienic connections --
T7J SMS 1-1/2" PN25, 316L, EHEDG
TXJ SMS 2" PN25, 316L, EHEDG
MAJ DIN11864-1 A DN25 tube DIN11850, 316L, slotted-nut, EHEDG
MQJ DIN11851 DN40 PN40, slotted-nut, 316L, EHEDG
MRJ DIN11851 DN50 PN40, slotted-nut, 316L, EHEDG
S1J NEUMO BioControl DN25 PN16, 316L, EHEDG
-- ANSI flanges --
AEJ 1-1/2" 150 lbs RF, 316L flange ANSI B16.5
AFJ 2" 150 lbs RF, 316L flange ANSI B16.5
YY9 Special version, TSP-No. to be spec.
50 Power Supply; Output:
B
D 2-wire; PROFIBUS PA
F
G 4-wire 90-250 VAC; 4-20mA SIL HART
H 4-wire 10.5-32 VDC; 4-20mA SIL HART
Y
60
70
80
90
100
995
FMP43-
1)
OVP = overvoltage protection
2-wire ; 4-20mA SIL HART
2-wire; FOUNDATION Fieldbus
Special version, TSP-No. to be spec.
Operation:
1 W/o display, via communication
2 4-line display VU331
3 Prepared for FHX40
9 Special version, TSP-No. to be spec.
Type of Probe:
1 Compact, basic version
5 Compact, detachable
6 Remote, cable 3 m, detachable
7 Remote, cable 6 m, detachable
9 Special version, TSP-No. to be spec.
Housing:
A F12 Alu, coated IP68 NEMA6P
B F23, 316L, IP68, NEMA6P
C T12 Alu, coated IP68 NEMA6P, separate conn. compartment
D T12 Alu, coated IP68 NEMA6P + OVP
Y Special version, TSP-No. to be spec.
Cable Entry:
2 Gland M20 (EEx d > thread M20)
3 Thread G 1/2
4 Thread NPT 1/2
5 Plug M12
6 Plug 7/8"
9 Special version, TSP-No. to be spec.
Additional Option:
A Basic version
B EN10204-3.1 material (316L wetted parts) inspection certificate
H 5-point linearity protocol, see additional spec.
J 5-point, 3.1, 5-point linearity protocol, see additional spec.,
EN10204-3.1 material (316L wetted parts), inspection certificate
P CoC-ASME BPE, EN10204-3.1 material (316L wetted parts) inspection
certificate
R 5-point, CoC-ASME BPE, 3.1, 5-point linearity protocol, see additional spec.,
EN10204-3.1 material (316L wetted parts), inspection certificate
Y Special version, TSP-No. to be spec.
Marking:
1 Tagging (TAG), see additional spec.
2 Bus address, see additional spec.
Complete product designation
Identification
1)
, seperate terminal compartment
