dejavoo QD Terminal Line Quick Reference Manual

QUICK REFERENCE GUIDE
QD Terminal Line
This terminal uses
MANUALLY ENTERED SALE
1. From the idle screen, enter the amount of the
transaction you want to process and press OK.
2. The default transaction will be Sale.
3. Choose the payment type the customer will use.
Options are Card (credit) EBT Food, EBT Cash.
4. When prompted to tap, swipe or insert card, tap on
the screen and key in card number and follow further
screen prompts.
5. Transaction will be processed and once approved, a
receipt will print out.
These steps have been provided to assist you with your Android payment device with DvPay
(AURA) software. IMPORTANT: As well as the payment icons (ie Card, PIN Debit, EBT Food,
EBT Cash and Cash), the terminal's idle screen also displays the following icons:
Access to the FAVORITES menu
Access to the CORE menu
CALL ME feature
Retail
with True Cash Discount
CHIP/CONTACTLESS SALE
1. From the idle screen, enter the amount of the
transaction you want to process and press OK.
2. The default transaction will be Sale.
3. Choose the payment type the customer will use.
Options are Card and PIN Debit.
4. When prompted, tap or insert the card. If required
(debit), enter PIN number.
5. Transaction will be processed and once approved, a
receipt will print out.
CREDIT CARD RETURN
1. From the idle screen, enter the amount of the
transaction you want to process and press OK.
2. The default transaction will be Sale. Tap on the
top of the screen to select Return.
3. Choose the payment type the customer will use.
Options are Card and PIN Debit.
4. Confirm the amount of the Return. If prompted, input
Manager Password (default password is 1234).
5. When prompted, tap, insert or manually enter the
card number.
6. Transaction will be processed and once approved, a
receipt will print out.
VOID BY TRANSACTION NUMBER
1. From the idle prompt, tap the
Favorites menu.
2. Tap Void Transaction.
3. If prompted, input Manager Password (1234 default).
4. Tap By Transaction #.
5. Input Transaction # to be voided and press OK.
6. Confirm the void transaction by tapping Select.
7. If prompted, confirm the void amount by tapping OK or
Cancel. Conditional on the terminal's configuration.
8. If prompted, input Manager Password (1234 default).
9. The void is processed. Void receipts will print with
details of the transaction.
>
at the
icon to access the
