INSTALLATION MANUAL
Variable Speed ECM
Modular Multi-position Air Handlers
Models: JMVT Series 208/230 V
- Single-Phase and Three-Phase
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Unit installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Ductwork and connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Electric heater installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Line power connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Low voltage control connections . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Return air duct attachment and component location . . . . . . . . . . . . . 2
Dimensions and duct connection dimensions . . . . . . . . . . . . . . . . . . 3
Typical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Coil and air handler attachment details . . . . . . . . . . . . . . . . . . . . . . . 4
Duct system - modular blower - right hand . . . . . . . . . . . . . . . . . . . . 4
Gasket location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
- that require the drain pan extension . . . . . . . . . . . . . . . . . . . . . . . . 6
- that do not require the drain pan extension . . . . . . . . . . . . . . . . . . . 6
Duct attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Ductwork transition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Line power connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Control board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cooling models with and without electric heat wiring . . . . . . . . . . . . . 9
- conventional wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Low voltage connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Stage delay switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Pushbutton operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Fault codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Fault list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Heat relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Continuous fan switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Comfort setting selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Physical and electrical data - cooling only . . . . . . . . . . . . . . . . . . . . 16
Electrical data - cooling only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
for single-phase heat kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Section I: General
The modular air handler series provides the flexibility for installation in
any position. This unit may be used for upflow, downflow, horizontal
right, or horizontal left applications.
These units may be located in a closet, utility room, attic, crawl space,
or basement. These versatile models may be used for cooling or heat
pump operation with or without electric heat or indoor coil.
Top or side power and control wiring, color coded leads for control wir-
ing, easy to install drain connections, and electric heaters all combine to
make the installation easy and minimize installation cost.
Electric heat kits are available as field installed accessories. Single-
phase kits are available from 2.5 kW to 25 kW. 208/230V three-phase
kits are available from 10 kW to 25 kW.
Johnson Controls Ducted Systems
List of sections
Required control set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Airflow and comfort setting selection . . . . . . . . . . . . . . . . . . . . . 16
Unit data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Air system adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Start-up sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
List of figures
- conventional wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
- conventional wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
- conventional wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Air handler with communicating AC or HP . . . . . . . . . . . . . . . . . . . . 10
Multi-wire terminal connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Variable speed board S1 jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
DIP-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
DIP-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Variable speed board dip switch locations - heat kit . . . . . . . . . . . . . 17
Duct static measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Wiring diagram - ECM - single-phase heat kits . . . . . . . . . . . . . . . . 22
Wiring diagram - 8HK three-phase heat kits 208/230 V . . . . . . . . . . 23
List of tables
Electrical heat: minimum fan CFM for three-phase heat kits . . . . . . 17
Electrical heat only: default fan speeds for FER compliance . . . . . . 18
Aux heat configuration - stage 1 kW dip switch settings . . . . . . . . . . 18
Application factors - rated CFM versus actual CFM . . . . . . . . . . . . . 18
Electrical data for multi-source power supply: 208/230-1-60 . . . . . . 19
Electrical data for multi-source power supply: 208/230-3-60 . . . . . . 20
Aux heat configuration - heat kit selection . . . . . . . . . . . . . . . . . . . . 20
Airflow data (CFM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Section II: Safety
This is a safety alert symbol. When you see this symbol on labels
or in manuals, be alert to the potential for personal injury.
Understand and pay particular attention to the signal words
DANGER, WARNING, or CAUTION.
DANGER indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation, which, if not
avoided may result in minor or moderate injury. It is also used to alert
against unsafe practices and hazards involving only property damage.
®
6146293-UIM-A-0522
